Wenzhou Rockwell Transformer Co., Ltd. >> 33kv Medium Voltage Switchgear (Drawable)

33kv Medium Voltage Switchgear (Drawable)

33kv Medium Voltage Switchgear (Drawable)
Price: US $ 1500-18000/Piece
Trade Terms: FOB,CFR,CIF
Min Order: 1/Piece
Pay Type: L/C,T/T,Money Gram
Prod Model: ZS3.2
Markets: North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Material: Epoxy
Type: Gas

Product Description






KYN61-40.5(Z) Metalclad AC Enclosed Switchgear Withdrawable type

1. General Description

1.1 Application: In the system of 50Hz, 40.5kV, for power distribution, circuit control and protection.

1.2 Standards : IEC 62271-200

1.3 Parameters: Rated voltage: 40.5kV

1.4 Rated current: 630-3150A

1.5 Rated short-circuit breaking current: 25-31.5kA



2.Features:

2.1.Compact design

2.2.Easy operation and installation

2.3.Reliable interlock

2.4.Less Maintenance



3.Technical Data

No.

Item

Unit

Data

3.1

Rated voltage

kV

36/40.5

3.2

Rated current of main bus bar

A

1250,1600,2000,2500,3150

Rated current of matched VCB

A

1250,1600,2000,2500,3150

3.3

Rated frequency

Hz

50

3.4



Rated short-circuit breaking current

kA

20,25,31.5

Rated short-time withstand current

kA

20,25,31.5

Rated short circuit continuous time

s

4

3.5

Rated peak withstand current

kA

50,63,80*

Rated short-circuit making current

kA

50,63,80*

3.6

Rated voltage of control circuit

V

DC: 110 220:

AC: 110 220

3.7

Rated power frequency withstand voltage

kV

95/1min

3.8

Rated lightning withstand voltage

kV

170/185

3.9

Protection level

Switchgear shell



IP3X

Compartments(door opened)



IP2X

We also supply the following switchgears:

Rated votlage 40.5KV switchgear(for 33KV system)

KYN61-40.5 withdrawout metal-clad and metal-enclosed switchgear

KYN10-40.5AC drawout metal clad switchgear

KYN1-40.5 AC withdrawable metal-clad enclosed switchgear

XGN-40.5 fixed AC metal-enclosed switchgear

GBC-40.5 Handcar HV switchgear


Rated voltage 24KV switchgear(for 22KV,20KV, 15KVsystem)

KYN-24  withdrawable metal-clad switchgear

HRM6-24 Ring net SF6 circuit breaker switchgear ( for 22KV,20KV, 15KVsystem )



Rated votlage 12KV switchgear(for 11KV,10KV,6.6KV system)

KYN28A-12 withdrawable metal-clad enlosed switchgear

XGN-HKGN8-12 Fixed metal clad enclosed switchgear  (for 11KV,10KV,6.6KV system)

HXGN-12 Ring Net Vacuum circuit breaker switchgear ( for 11KV,10KV,6.6KV system )

XGN15-12  Ring Net SF6 circuit breaker switchgear (for 11,10,6.6KV system)

Rated voltage 0.4KV low voltage switchgear(380V,400V,433v,440V system)

GCK LV withdrawable switchgear

GCS LV withdrawable switchgear

HMNS LV withdrawable switchgear

GGD LV distribution cabinet

XL-21 Power distribution box

MOTO Start swichgear

Modula 630K sersies of standard LV distribution box

plus 2.0 LV switchgear

GZDW series of microcomputer monitoring high-frequency DC switchgear

Soft start switchgear

Residential, customized power distribution box

PZ30, PZ40 distribution box

outdoor mobile box

Capacitance compensation box

The other switchgear (from 0.4KV to 33KV)We can OEM , ODM for you.)


ATTENTION:

1.The payment term: We accept TT,30% deposit and 70% balance against copy of BL.
2.The delivery time: Usually it will take about 15-20 days.
3.The standard of package: Usually use strong plywood case for protection.
4.The material of transformer: We have two types, one is with copper and another one is with aluminum. It depends on your requirement. In fact, those two have difference if normal work well. Only except the long life. Copper is better and also higher price.
5.The logo: If you have good quantity, it absolute no problem to do OEM.
6.Our market: our products are popular in Indonesia, Philippines, Russia, USA, Middle East and so on. Some of them are our regular customers and some of them are developing. We hope you can join us and make mutual benefit from our cooperation..
7.Warranty: in 12 month since BL date.

OUR SERVICE:

1.quick response in before sales period help you got order.
2.excellent service in production time let you know each step we made.
3.reliable quality solve you after sale headache.
4.long period quality warranty ensure you can buy without hesitate.


WHY CHOOSE ROCKWELL:

1. One-stop supplier globally.
2. More than 10 years professional experiences in electrical appliance industry.
3.We offer professional online technology support for perfecting your electrical solution free.
4. Experienced sales service and suggestion.
5. All the products with accessories under strict quality control and final inspection before shipping.
6. We can assure the powerful competitive price and reliable quality products.
7. Most competitive shipping rate from our own shipping forwarder.
8. Warranty assurance: 12 month
9. Whatever big or small order, we can provide you one-to-one service.

CONTACT US:

Contact person: Mr. Chen Chengming
Tel:86-577-27869969
Mobile:86-18668777248


Your Best Choice for Electrical Appliances Industry!!!
Please leave an inquiry to know more details about Price , Packing ,Shipping and Discount.




Wenzhou Rockwell Transformer Co., Ltd. is a high-tech enterprise invested by Rockwill Transmission and distribution Group Co., Ltd. Our company is specialized in developing, manufacturing and marketing Single phase & three phase automatic step voltage regulator, Auto-transformers, power transformers, preventive auto transformer, CT and PT combinated Metering unit, and compact transformer and pad moubted substations.

Our company enjoys a worldwide reputation for our superior quality and service. In addition to the domestic market, our products are exported to America, Australia, Central Europe, Eastern Europe, Southeast Asia, the Middle East, Africa and other regions and countries.

Besides a great variety of products, we also provide you with professional technical solutions and services. If you have any problem, please feel free to contact us and our technicians will find a complete solution for you.

We always embrace the idea of developing together with customers and always try our best to provide users with safer, easier, greener and more energy-saving high and medium voltage electric equipment and components.

Note:

Rockwell's sister company Rockwill is offering manufacturing for MV and LV switchgears, ring main units, vacuum(gas) circuit breakers, reclosers, load break switches and Low voltage metering unit, Current transformer, Voltage transformer.
