33kv Medium Voltage XLPE Insulated Power Cable
| Price: |
US $ 0.16/Piece |
| Trade Terms: |
FOB,CFR,CIF |
| Min Order: |
1000/Piece |
| Pay Type: |
L/C,T/T,Western Union |
| Prod Model: |
MV XLPE Power Cable |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Application: |
Power Transmission |
| Voltage: |
Low and Medium Voltage Cable |
| Current: |
AC Cable |
| Insulation Material: |
PVC |
| Sheath Material: |
Copper |
| Certification: |
IEC BS |
| Model: |
Yjlv |
| Brand: |
Rneda |
Product Description
33KV Medium Voltage XLPE Insulated Power Cable
1 Product StandardThis product is manufactured according to GB/T12706.2, equivalent to IEC60502.2. Or BS, DIN, ICEA standard as customer request.
2 ApplicationThe product is suitable for use in power transmission and distribution lines with rated power frequency voltage 3.6/6kv~26/35kv.
3 Operating characteristics- Rated power-frepuency voltage U0/U: 3.6/6kv~26/35kv.
- Max.admissible operating temperature of the conductor:90ºC.
- Max. short-circurt temperature of conductor shall not exceed 2500C. (5s maximum duration)
- The ambient temperature under installation should not below 00C.
- The bending radius of a single-core cable should not less than 20 times of the cable diameter.
The bending radius of a multi-core cable should not less than 15 times of the cable diameter.
4 Table of the voltage, cores and cross-section| Item | Category A ,B | 3.6/6kV | 6/10kV | 8.7/15kV | 12/20kV | 18/30kV | 21/35kV |
| Category A ,B | 6/6kV | 8.7/10kV | 12/15kV | 18/20kV | - | 26/35kV |
| Single core | mm2 | 25-1200 | 25-1200 | 35-1200 | 50-1200 | 50-1200 | 50-1200 |
| Three core | mm2 | 25-400 | 25-400 | 35-400 | 50-400 | 50-400 | 50-400 |
The cable with Category A rated voltage is used in the situation requiring not over 1 min. of grounding fault lasting time. For the cable with Category B rated voltage, the grounding fault lasting time normally is not over 1 hour, max. lasting time is not over 8 hours, annual ground fault lasting time altogether should not be over 125 hours, Category C includes all the system expect Category A and B.
5 Type and Name| Type | Designation | Applications |
| YJV | Copper conductor,XLPE insulated,
PVC sheathed power cable | For laying indoors,in tunnel or cable trench,
unable to bear external mechanical forces.
Single core cable is not allowed to laid in
magnetic duct. |
| YJLV | Aluminum conductor,XLPE insulated,
PVC sheathed power cable |
| YJY | Copper conductor, XLPE insulated,
PE sheathed power cable |
| YJLY | Aluminum conductor, XLPE insulated,
PE sheathed power cable |
| YJV22 | Copper conductor,XLPE insulated,
steel tape armoured,PVC sheathed power cable | For laying indoors,in tunnel in cable trench,
or direct in ground,able to bear external
mechanical forces.Single core cable is not
allowed to laid in magnetic duct. |
| YJLV22 | Aluminum conductor,XLPE insulated,
steel tape armoured,PVC sheathed power cable |
| YJV23 | Copper conductor,XLPE insulated,
steel tape armoured,PE sheathed power cable |
| YJLV23 | Aluminum conductor,XLPE insulated,
steel tape armoured,PE sheathed power cable |
| YJV32 | Copper conductor,XLPE insulated,steel
wire armoured,PVC sheathed power cable | For laying indoors,in tunnel cable trench,
well or direct in ground,able to bear external
mechanical forces and certain pulling force. |
| YJLV32 | Aluminum conductor,XLPE insulated,
steel wire armoured,PVC sheathed power cable |
| YJV33 | Copper conductor,XLPE insulated,steel wire
armoured,PE sheathed power cable |
| YJLV33 | Aluminum conductor,XLPE insulated,steel
wire armoured,PE sheathed power cable |
Established in 1993, Hebei Huatong Wires and Cables Group Co., Ltd covers an area more than 220, 000 square meters, owning more than 420 sets manufacturing equipment and more than 250 sets of testing equipment or apparatus. Our annual production capacity is 3 billion Chinese Yuan. Now there are more than 800 employers in our company, among which more than 150 are technicians. With the continuous efforts from all the employers, Hebei Huatong Wires and Cables Group Co., Ltd has realized great development to become a modern enterprise and one of the comprehensive, large-scale enterprises in domestic wire and cable industry. Our products are widely used in the field of electric power, coal, metallurgy, petrochemical industry, railway, national defense, construction, aviation and other national key projects. We are JV with Furukawa(Japanese company) for rubber serial cable (minding cables, welding cables. Submersible oil pump cables, . )and also JV with Riken(Japanese company) for elevator cables. Our products have extensive influence and good reputation in both domestic and worldwide market, such as the United States, Holland, Italy, Russia, Britain, Australia, New Zealand, Ethiopia, Ghana, Algeria, South Africa, Congo, Middle East and Southeast Asia countries and so on.
Products: Power Cable, Rubber Cable, UL standard building wire cable
Certificates:
Certificate of UL. CE, KEMA, TUV, Bureau Veritas, Lloyd, IEC, GL, SA, NK, KR and "National Industrial Production License", "Certificate of Recommended Enterprises and Products for National Grid", "Adopting International Standard Certificate", and "High-Tech Enterprise Certificate", "Certificate of High Quality Products", "Certificate of Scientific and Technological Achievements", "Qualified Supplier Certificate", "China Classification Society Certificate of Works Approval", "Det Norske Veritas Type Approval Certificate", "Railway Product Certificate", "Safety Certificate of Approval for Mining Products", "National Mandatory Product Certification", "Certificate for China Compulsary Products Certification" and "Practical New-Type Patent Certificate
