3636 Brushless DC Planetary Motor BLDC Motor

Name: 3636 Brushless DC Planetary Motor BLDC Motor
Brand: all-electronics-online.com
SKU: 772383535
Availability: InStock
Rating: 5 (49 reviews)

Price:	Negotiable/Piece
Trade Terms:	FOB,CFR,CIP
Min Order:	50/Piece
Pay Type:	L/C,T/T,Paypal,Money Gram

Contact Supplier

Showroom Product Company Profile

Prod Model:	GSBLD36R
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Size:	3636
Power:	15W
Hall:	Yes
Service Life:	>5000 Hs
Internal Drive:	Yes
Application:	Power Tools
Operating Speed:	Constant Speed
Structure And Working Principle:	Brushless
Certification:	Ce
Brand:	GS

Product Description

Technical Parameter

Type	Voltage	Rated Power	Rated Torque	No load Speed	No load Current	Rated Speed	Rated Current	Length	Internal Drive
Type	V	W	N.m	RPM	A	RPM	A	mm	Internal Drive
GSBLD36R15D12	12	15	0.048	3800	< 0.4	3000	1.92	65	YES
GSBLD36R15D24	24	15	0.048	3700	< 0.3	3000	0.96	65	YES
GSBLD36R10D12	12	10	0.032	3800	< 0.3	3000	1.28	55	YES
GSBLD36R10D24	24	10	0.032	3700	< 0.3	3000	0.64	55	YES
GSBLD36R5D12	12	5	0.016	3800	< 0.3	3000	0.64	45	YES
GSBLD36R5D24	24	5	0.016	3700	< 0.3	3000	0.32	45	YES

No. of stage	1 stage	2 stage	3 stage	4 stage	5 stage
Gear Ratio	3.7,5.2	13.7,19.2,26.9	50.9,71.2,99.5,139	188,264,369,516,721	699,977,1367,1911,2672,3736
"L1" Gearbox length mm	25.1	32.3	38.5	44.7	50.9
Max Rated Torque N.m	1.0	2.0	5.0	5.0	5.0
Max Broken Torque N.m	3.0	6.0	15.0	15.0	15.0
Gearing Effciency	90%	81%	73%	65%	59%

About Greensky Mechanical
·         History: Greensky Mechanical is a motor brand of Greensky power company Limited. The brand Greensky Mechanical was founded in 2012 with investing in a 15 year old motor factory in Zhejiang Province. Greensky Power brought new management concept to the new joint company and increase the quality of the motors as Greensky Power always provides stable and good quality and service to the society. The Positioning of the brand is medium & high quality level. Our customers are mainly in Europe. We save cost by increasing the efficiency of production and delivery.
·         Market: Greensky has customers in 30 different countries. Germany, Austria, Japan, USA and Middle-East are our main market .
·         Mission:  "Once and forever" is our goal to serve customers in the world. Once we do business with customer, we will do business forever.

Greensky's Advantage

Price	Average less than 50% of high end European brand.
Quality	100% Quality Check. Germa n Standard.
Delivery	On-time delivery Guaranteed
Services	English, German, Japanese and Chinese sales representatives are available for One-Stop full services.
Positioning	High quality motor with reasonable price from China.

If you have any other questions, please feel free to contact us.

About Greensky Mechanical

History: Greensky Mechanical was founded in 2012 with purchasing of a 15 year old cooperative factory in Zhejiang Province. Greensky Power brought new management concept to the new joint company and increase the quality of the motors as Greensky Power only provides best quality and best service to the society.

Introduce: Greensky Mechanical Co., Ltd is a subsidiary company of Greensky Power which is producing AC and DC gear motor, gearbox and motor, and it has capability to design and develop customized product with high quality.

Philosophy: We save cost by increasing the efficiency of production and delivery. "Once and forever" is our goal to serve customers in the world. Once we do business with customer, we will do business forever.

GS motor makes the cool mechanism human by progress in thchnology and products innovation. GS bases on talents. Products are the morality of man. Wisdom and passion of us are the core power. GS

Motor has made her own stronger through the long-term experience and exerise. GS believes that we raise ourself continuously in future. GS will go on innovating forever.
