38120s 10ah 3.2V LiFePO4 Cells

Name: 38120s 10ah 3.2V LiFePO4 Cells
Brand: all-electronics-online.com
SKU: 733953502
Availability: InStock
Rating: 4.3 (144 reviews)

Price:	US $ 15/Piece
Min Order:	100/Piece
Pay Type:	T/T,Western Union,Paypal

Contact Supplier

Showroom Product Company Profile

Capacity:	10ah
Type:	Lithium-Ion Batteries
Usage:	Lighting
Discharge Rate:	High Discharge Rate
Shape:	Cylindrical Battery
Rechargeable:	Chargeable
Nominal Voltage:	3.2V
Electrolyte:	Lithium Ion

Product Description

Basic Info

Model NO.: 38120

Certification: UL, CE

Socket Type: All

Peak Discharging Current: 100A

Constant Dicharging Current: 30A

Color: Blue

Cycle Life: 2000times

Self-Discharging Current: 3% Per One Month

Usage: Lamp, E-Bike, Motor

Trademark: headway

Specification: ce, msds

Origin: Shenzhen

Product Description

38120S battery, 3.2V 10Ah 10C lifepo4 battery

Specifications:
1.Typical Capacity: 12Ah
2. Nominal Voltage: 3.2V
3. End Voltage: 2.3V
4. Charging Current (Std.): 0.5CA
5. Charging Current (Max.): 1CA
6. Charging Voltage: 3.9V
7. Charging Time (Std.): 6~7.0 hours
8. Charging Time (Max.): 2~3.0 hours
9. Continuous Discharging Current (Max.): 12A
10. Discharging Current (Max.): 120A
11. Soft Pack Internal Resistance (25°C) : <500mΩ
12. Pack Dimension: MAX 38mm*120mm

Application:
1. Telecommunications: cellular phone, interphone, Bluetooth earphone.
2. Video Devices: MP3/MP4/MP5, digital camera, portable DVD, portable television,
3. Portable Devices: GPS, PDA, E-book, PMP, PSP, portable medical device etc.
4. Illuminate Devices: miner lamp, searchlight.
5. Others: toys, rc models.
