| Prod Model: |
EKM1-125 |
| Protection Degree: |
IP20 |
| Mechanical Life: |
10000 |
| Electrical Life: |
4000 |
| Export Market: |
Global |
| Breaking Capacity: |
Low Voltage Circuit Breakers |
| Operation: |
Manual Type |
| Speed: |
Normal Type Circuit Breaker |
| Arc-extinguishing Medium: |
Air |
| Installation: |
Fixed |
| Structure: |
MCB |
| Poles Number: |
3 |
| Certification: |
SGS TUV RoHS |
Product Description
3p 100A 240V 415V Mini MCB 6ka 10ka Circuit Breaker
Product Description
Product Description
Free samples can be provided!!!
Product Description
Electrical Features
Rated current In: 63, 80, 100, 125A
Poles: 1P, 2P, 3P, 4P
Rated voltage Ue: 240/415V
Insulation voltage Ui: 500V
Rated frequency: 50/60Hz
Rated breaking capacity: 6000A
Energy limiting class: 3
Rated impulse withstand voltage(1.2/50) Uimp: 4, 000V
Dielectric test voltage at ind. Freq. For 1 min: 2kV
Pollution degree: 2
Thermo-magnetic release characteristic: C, D
Mechanical Features
Electrical life: 4, 000
Mechanical life: 10, 000
Contact position indicator: Yes
Protection degree: IP20
Reference temperature for setting of thermal element: 30º C
Ambient temperature (with daily average≤ 35º C): -5º C...+40º C
Storage temperation: -25º C...+70º C
Installation
Terminal connection type: Pin-type busbar
Terminal size top/bottom for cable: 35mm2
Terminal size top/bottom for busbar: 35mm2
Tightening torque 2.5 N*m
Mounting: On DIN rail EN 60715 (35mm) by means of fast clip device
Connection: From top and bottom
Combination with accessories
Auxiliary contact: Yes
Shunt release: Yes
Under voltage release: Yes
Alarm contact: Yes
Circuit Breaker's Dimensions(mm)
Dimensions (mm)
