3p 4p Electric 1600A Manual Transfer Switch (MTS)

Prod Model:	JGLZ
Model:	Jglz
Rated Current:	1600A
Pole:	3p/4p
Frequency:	50/60Hz
Standards:	IEC, Ce, ISO, SGS

Product Description

3P 4P Electric 1600A Manual Transfer switch (MTS)


1. Manual Transfer switch Description:
* Suitable for changeover two sets of low voltage electric circuit or the changeover of 2sets of load devices of safety isolation.
*Mode of operation:
  If direct operation: handle is installed on the switch
  If operate outside the board: handle is installted outside the door of power distributioin board.
* Products with observation windowns can be provided accordingly to the demand to observe directiy the on and off state of contact.
*Extended shaft is used for the operation outside the board.
*Two sets of auxiliary contacts can be assembled according to the demand.
*Mechanical performance and electrical performance correspond to the mechanical property of JGLZ 160A to 1600A.
*A bridge can provided to connect the inlet or outlet terminal of the switch
*The electric cable insulating cover can be assembled. Not the bridge connection is chosen, and explanation is needed to indicate the inlet or outlet is connected with it.

2. Dimension:

	A	B	C	D	E	F	J	J1	K	N	P	R	U	θx
125A-160A/3	319	135	125	67	89	24	299	120	65	59	36	20	85	9
125A-160A/4	379	135	125	67	89	24	359	150	65	59	36	20	85	9
200A-250A/3	405	170	134	79	104	25	385	160	90	65	50	25	110	11
200A-250A/4	505	170	134	79	104	25	485	160	90	65	50	25	110	11
315A-400A/3	535	240	166	108	131	37	515	210	140	95	65	32	160	11
315A-400A/4	655	240	166	108	131	37	635	270	140	95	65	32	160	11
500A-630A/3	535	260	166	108	131	37.5	515	210	140	95	65	10	160	13
500A-630A/4	655	260	166	108	131	37.5	635	270	140	95	65	10	160	13
1000A/3	836	310	192	150	163	48	811	353	175	105	120	60	200	13
1000A/4	1076	310	192	150	163	48	1051	473	175	105	120	60	200	13
1250A/3	836	336	192	150	163	48	811	353	175	105	120	60	200	13
1250A/4	1076	336	192	150	163	48	1051	473	175	105	120	60	200	13
1600A/3	836	336	192	150	163	48	811	353	175	105	120	60	200	13
1600A/4	1076	336	192	150	163	48	1051	473	175	105	120	60	200	13

3.Packing: Carton Packing and Wooden box packing

4. Production line and delivery time:
With some stock, JGLZ ATS normally with stock. 1000pcs ATS production time within 7days.
QC quality control for every step, to make sure 100% passed.

5. Other product series:
Manual transfer switch:  1A~1600A, 3P/4P.
Metal Enclosure for Transfer switch:  Metal box, size can color can be customized.
Plstic box:   Different ways, competitive price,  welcome to contact.
Surge protector: B,C,D Class, AC, DC type you can choose. Different types and discharge current you choose.
Power supply: Hot used in Gepenerator system, 120W 12/24V. And other types.
Current transformer: Different size you can choose, quality guarantee, hot used in Generator cabinets.

6. Q&A:
1) Q:Your company ? And products?
     A:   Joymell is factory for ATS, Enclosure, Power supply, Current transformer etc. Providing customers very competitive sources, and can be your sourcing agent in China. Goods are following international standards, IE, CE, ISO9001 ,SGS etc.
2)  Q:   Do you have forwarder?
      A:   Yes, we have good forwarder cooperated over 7years, they help us import and export . For small package orders, suggest to use by Express.
3)   Q:   Your address ?
      A:    Locates in Zhejiang province, Baixiang town, Chandong industrial zone.
4)   What's the ATS guarantee?
       A: 2 years warranty. If customer's problem, then customer burden. If our problem, then we send new goods to customer to replace asap.
5)    What's about MOQ? Delivery time ?
       A: 1pcs for ATS. Normally less than 1000A ATS with stock, quick support.
6)    What's the payment term?
       A: Normally 100% T/T in advanced payment. If big order then about 50% advanced payment, balance before shipment.
7)    What's your contact information ?
         A: Website: www.joymell.com, welcome to contact us anytime.
Welcome your inquiry ^!^
