3phase 4poles 800V 630A MCCB Moulded Case Circuit Breaker
| Price: |
US $ 1-5/Piece |
| Min Order: |
20/Piece |
| Pay Type: |
L/C,T/T,Paypal |
| Prod Model: |
FNM1-630L |
| Rated Voltage: |
220V/230V,400V/415V |
| Certificate: |
Ce CB ISO9001 |
| Standard: |
IEC60947-2 |
| Working Temperature: |
"-5°"to +40° |
| IP Degree: |
IP20 |
| Breaking Capacity: |
Low Voltage Circuit Breakers |
| Operation: |
Manual Type |
| Speed: |
High-Speed Circuit Breaker |
| Arc-extinguishing Medium: |
Air |
| Installation: |
Fixed |
| Structure: |
MCCB |
| Certification: |
CB |
| Poles Number: |
3p/4p |
| Type: |
Moulded Case |
Product Description
Hot sale 630a 3P/4P Moduled case circuit breaker AC MCCBProduct Description:630a mcb circuit breaker Product Application: FNM1-630 series moulded case circuit breaker is a new type product developed and manufactured by Adopting international advanced technology. It is supplied with rated insulation voltage 800V and used for circuit of AC 50/60Hz, rated operation voltage AC 415V or below rated operation current up to 1600A for infrequent changing over and starting of the motors. Equipped with the protection devices for over-current, short circuit , the product is capable of preventing damage of circuits and supply units. The product conforms to IEC60947-2 standard.
circuit breaker Specifications:| Item | MOULDED CASE CIRCUIT BREAKER |
| Code | FNM1-125 | FNM1-250 | FNM1-400 | FNM1-630 | FNM1-800 | FNM1-1250 |
| Pole | 2P,3P,4P | 2P,3P,4P | 3P,4P | 3P,4P | 3P,4P | 3P,4P |
| Voltage | 690v/800v |
| Current | 6A,10A,16A,
20A,25A,32A,40A,
50A,63A,80A,100A,125A | 100A,125A,140A,
160A 200A,
225A,250A | 250A 400A | 400A 500A
630A | 630A 700A
800A | 800A,1000A,
1250A |
| Standard | IEC/EN60947 |
| Breaking Capacity | 35KA | 35KA | 50KA | 50KA | 75KA | 75KA |
| Characteristic Curve | C |
| Working Temperature | "-5°"to +40° |
| Protection Degree | IP20 |
| Electrical life | More than 8000times |
| Mechanical life | More than 2000times |
| Installation | 35MM DIN RAIL |
| Accessory | YES |
| Installation Altitude | ≤2000M |
Moulded circuit breaker Specifications:
Packaging & Shinpping:250a mcb circuit breaker Packing:1.Standard export box package2.Delivery Time: 10-15 days for batch goods.250a mcb circuit breaker Shipping:1.Shipment port:SHANGHAI/NINGBO2.By Air or by Sea for batch goods,Airport/ Port receiving;3.Customers specifying freight forwarders or negotiable shipping methods!
Our Services1.One to one service,Feedback within 24 hours
2.Design for special packing, Products printing and logo OEM
3.Find the solution for any problems activelyCompany Information
FAQ Q: If I'm interested in your MCCB when I can receive your quotation and detail information after send the enquiry?A:All your enquiry will be replied in 24hours.Q:Your MCCB seems perfect but what's the difference between you and other suppliers?Because I find some cheaper price from others!A: Our MCCB are high quality customized.I think compare the quality first and then compare the price is the best way.Q:Can I get a sample before the order because I really don't how is your MCCB quality?A:Of course!We also think sample order is the best way to build the trust.And in our company we offer free sample service!Please send the enquiry to us and get the free sample!Q:How's the delivery?Because I really need them is urgently?A:For sample order 3~7days will be no problem.And for regular order we promise in 15days.Q:How's the warranty period for your MCCB?A:We offer one year warranty for our customer.
WenZhou Funelec Electrical Co., Ltd., which specializes in manufacturing series of breakers, is a scientific enterprise integrating with scientific research, manufacture, processing and trading business. It has 300 employees with an area of more than 3000 square meter.
The main products in our company are Miniature Circuit Breaker, Residual Current Circuit Breaker, isolator. It consists of 9 series of products with over 60 types. Our products apply into high end of market in the world. With the safe product certificate of EU-CE, Sweden S, Finland F1, Poland B, Argentina IRAM&CB and the certificate of China CCC, ISO9001 International Quality Management System, the qualification of products reaches advanced world level, and the quality is accepted by high end of market. Meanwhile, we have our own intellectual rights for breakers and leakage breakers and have advanced testing and assembly equipment and exquisite manufacture techniques.
It covers worldwide markets, among them European as a leading market with many customers from top 500 enterprises. WenZhou Funelec Electrical Co., Ltd.
