3u 19'' Rack-Mount Splitter ODF 3

Name: 3u 19'' Rack-Mount Splitter ODF 3
Brand: all-electronics-online.com
SKU: 725593705
Availability: InStock
Rating: 4.7 (107 reviews)

Price:	Negotiable/Piece
Trade Terms:	FOB,CIF,EXW
Min Order:	10/Piece
Pay Type:	L/C,T/T,Western Union

Contact Supplier

Showroom Product Company Profile

Prod Model:	3u 19'' ODF
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Condition:	New
Application:	Communication
Certification:	RoHS
Type:	Optical Fiber Distribution Box

Product Description

3U 19'' Rack-mount splitter ODF

This optic distribution frame design for standard 3U 19''. Suitable for different kinds of equipment which is
Designed according to 19'' cabinet. Can loaed with 12pcs MPO cassettes.

Features:
Material: Aluminum or cold-roll steel optional.
Standard size, light and reasonable structure
Different adapter interface, SC, FC, ST, LC
Frame size: 482.6x225x133.4mm
MPO cassette size: 129*100*29mm

Application:
Telecommunications subscriber loop
Fiber to the home (FTTH)
LAN/WAN
CATV

Painting:
1. Electrostatic Powder spraying, Black or Hoar color
Optional.
2. Other color according to customer's demand.
Note: If customer no special requirement, we will spray
Hoar color.

Capacity:
MPO cassettes: 12 cores for SC simplex
Adapters. 24 cores for LC duplex adapters.
Total capacity: 144 cores for SC simplex,
288 cores for LC duplex

Specification:

Type	RMF-1U	RMT-2U
Size(mm) LWH	4802501U	4802502U
Max Capacity (Core)	24	48
Outer Carton Dimension(mm)	485425305/5pcs	485675305/5pcs
Outer Carton Volume(m3)	0.063	0.1
Outer Carton Weight(Kg)	14.2/5pcs	21/5pcs

Technical Data:

Model	RMF-1U
Size(mm): LWH	4302501U
Max capacity:	24core(1U)
Optical fiber winding radius:	≥40mm
Fiber length left in tray:	none
Fiber length left in tray:	≥1.6m
Fiber capacity:	48 cores
Working temperature:	- 400°C ~ + 600°C
Lateral pressure-resistance:	500N
Shock-resistance:	750N

Shenzhen Datolink Communication Technology Co., Ltd. Was founded in the January of 2007 by several engineers, who have had many years of working experience in fiber optical as well as in structured cabling industry. Datolink is a high technology oriented company with fiber optical products and structured wiring. We are dedicated to the design, manufacture and sales, meanwhile, we can provide customers with complete cabling solutions in installation and maintenance.

The company has a strict and comprehensive system of quality control and approved the standard ISO9001: 2000. Is well connected with raw materials providers and factories worldwidely, to offer customers a broad line of products with competitive prices and very soon time of delivery.

Our products have been exported to over 20 countries and regions such as Europe, Middle East, Southeast Asia, Latin America, etc. Datolink Ltd is committed to offer the partners high quality products and professional services, we look forward for the successful development with mutual-benefits, for casting the future of fiber optical and structured cabling!
