3X1.0mm Flame Rated Fireproof Cable

Prod Model:	FC140
Color:	Black,Orange,Blue,Grey,etc
Rated Voltage:	300/500V
Type:	Insulated
Conductor Type:	Stranded
Application:	Underground
Conductor Material:	Copper
Insulation Material:	PVC
Certification:	RoHS
Range Of Application:	Gemt
Brand:	Gemt

Product Description

3X1.0mm Flame Rated Fireproof Cable

Specifications
1.Conductor:0.5mm,0.7mm,0.8mm,1.0mm,1.13mm,1.38mm
2.PVC insulation and LSZH jacket
3.OEM is weclome
4.High quality


Fire wire cable
This wire is for indoor use in fire/life safety systems, fire and alarm notification, smoke/heat detection, building control circuits and initiating circuit systems. It is "Data Rated" for telephone and datacommunications applications. Exceeds UL1666 flame test for cables installed vertically in shafts (risers).  Rated 300 volts and -20 degrees Celsius to 75 degrees Celsius in dry locations.


Type	Area(mm2)	Construction Structure(main core)(mm)	Earth core structure(mm)	Thickness of insulation(mm)	Thickness of sheath(mm)	Fiber tape wrapped(cm)	Aluminum foil wound(cm)	Approx overall diameter(mm)
Fire Resistant Cable	2*1.0+E	1*1.13	1*0.85	0.60	0.80	1.50	1.80	7.20
	2*1.5+E	1*1.38	1*1.13	0.70	0.80	1.50	1.80	9.20
	2*2.5+E	1*1.78	1*1.38	0.80	1.00	2.00	1.80	10.60
	3*1.0	1*1.13		0.60	0.90	2.00	1.80	8.20
	3*1.5	1*1.38		0.70	0.9	2.50	1.80	9.60
	3*2.5	1*1.78		0.80	1.00	3.00	1.80	11.50



Ratings:
UL 1424 - type FPLR
UL 13  - Type CL3R


NEC Articles:
760 - Fire Alarm Systems
725 - Remote - Control, Signaling


Construction: 18 AWG solid bare copper,  PVC  insulation, color coded, cabled, aluminum / polyester foil tape plus tinned stranded copper drain(22 AWG), yellow  PVC jacket, surface printed.
This 2 conductor #18 stranded wire has an insulation thickness of 9 (PVC)  mils with the jacket thickness of 15 mils (PVC).  The outside diameter is .162 inches and the net weight of 1000 feet of cable is 22 lbs. The capacitance is 53 picofarads per inch.  The colors of the insulation on the 2 solid copper conductors are black


 FAQ:
Q: Can I have a sample?

A: Yes, we welcome sample order to test and check quality.

Mixed samples are acceptable.
Q: How long is the lead time?

A: Sample needs 1-2 days; mass production needs 15-30 days.
Q: Do you have the MOQ limit?

A: Our MOQ is 100-10000meters, depending on the products;

Sea Port: FOB Shenzhen.

Q: Do you provide OEM or ODM services?

A: Yes, we do.

Q: Do you offer guarantee for the products?

A: Yes, we offer five years guarantee for the product
