| Prod Model: |
WNK808B |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Output Signal: |
4~20mA |
| Housing Material: |
Aluminum14 |
| Maximum Static Pressure: |
70 Kpa |
| Structure Type: |
Micro Differential Pressure |
| Accuracy Grade: |
0.2, 0.5 |
| Pressure Range: |
-100kpa~+60kpa |
Product Description
WNK808B Micro Low Differential Pressure Transmitter for Wind PressureMetro wind pressure and environment wind pressure test, air duct pressure, pressure of fan, boiler air ,indoor ventilation, mine ventilation,secondary air measuring,wind speed & flow measurement. It is widely used in various industrial fields as well as intelligent building and other construction projects, such as power plant boiler primary air,WNK808B intelligent pressure transmitter is assembled with aluminum housing and stress isolation technology. Integrated structure design lead to compact layout. With intelligent compensation technology, it is suitable for wind pressure
ApplicationIt is the best micro pressure measurement equipment for textile machinery,natural gas pipeline monitoring,dust removal system, HVAC,clean laboratory and medical equipment etcTechnical Data| Applicable media | Gas |
| Pressure range | -10Pa~100Pa, -100kPa~+60kPa |
| Pressure Measurement | Gauge pressure, Differential pressure |
| Accuracy | 0.1%, 0.2%, 0.5% |
| Stability | 0.8%F.S./Year |
| Maximum static pressure | 70 KPa |
| Max overload | 250% of sensor range |
| Output signals | 4~20mA |
| Housing material | Aluminum14 |
| Induct Pressure Connection: | M 8x1 female or Ø 8 dowel connection |
| Power Supply | Non-explosion: 10.5~45V DC |
| EEX ia:10.5~30 V DC |
| Ambient temperature | -40~85ºC |
| Compensation temperature | -10~70ºC |
| Working temperature | -10~70ºC |
For more information, please contact us for product manual.About us
Delivery5~10 days after order confirmedFAQQ: Are you manufacturer or trading company? A: We are professional pressure/level/temperature measurement manufacturer with more than 13 years of experience. Our factory address is: 4/F,Bldg #6, No.168, Xiangzhang Road, High-tech District, 230088, Hefei, Anhui province, China. Q: What's your quality control system?A: We are an ISO 9001-2015 certified manufacturer, we have strict quality control system. Besides clibartiaon, each set product we also do temperature compensation and aging test before shipment, so the quality is guaranteed. Q: What is the warranty of your products? A: 12 month from shipment date, for non-man-made damages. Q: Can we use our logo on the products? Do you provide customized products? Yes.we can use your logo, we can provide customized products per requirement. OEM/ODM is welcome Q: What is yor MOQ?A: We have no MOQ limits, small quantity order is acceptable. Q: What's the transport? A: Express such as DHL, Fedex, TNT, UPS for freight prepaid, also can use your own couier account to do the freight collect. For more goods we can arrange by air or by Sea.Contact
