4-Core 0.6/1kv PVC Insulated and PVC Sheathed Power Cable

4-Core 0.6/1kv PVC Insulated and PVC Sheathed Power Cable
Price: US $ 0.1-100/Meter
Min Order: 1/Meter
Pay Type: L/C,T/T,D/P,Western Union
Prod Model: VV22/VLV22
Delivery Length: Accord with The Request
No. Of Cores: 4 Core
Experience: 20 Years
Factory Area: 100000m2
Application: Power Station
Voltage: Low and Medium Voltage Cable
Current: DC & AC
Insulation Material: PVC
Certification: CE
Wire Core Material: Alumininum/Cooper
Model: VV22/Vlv22
Brand: Huatong

Product Description

Product Description

4-Core 0.6/1kv PVC Insulated and PVC Sheathed Power Cable

1.Application Properties
Rated volatege U0/U:0.6/1kV,1.8/3kV
Cable Conductor long-term permission operatin temperature:PVC insulation is 70ºC,the short-circuits (the longest time does not surpass 5S),the max.temperature of conductor does not surpass 160ºC.
The ambient temperature at cable laying should not be lower than 0ºC:when is lower than 0ºC,the cable should be preheated ,the cable laying will not be limited by dropping variance level.
Bending radius of cable laying :
Single core cable >20times of outer diam.of cable
Multi-core >15times of outer than diam,of cable
The neutrality of five-core cable is distinct with the earth wire and the system operation tend to be more stable.

2.Product Usage
The product applies to the line of 0.6/1kV rated voltage :The products is mainly used for electric transmission and transportation in highbuidings,subways,power stations,entertainment places,industrial entertainment places ,industrial enterprises and sea pertrol platform etc,where a high intensity of cable laying and a strong flame-retardant ability are required.

3.Length of Delivery
Usually power cables area delivered in drums.The total lengthc of a delivery is not shorter than 100m:A short length (not less than 20m)delivery is permitted but amount should exceed 10% of the whole length of delivery.In addition ,we can deliver the goods at any length accroding to the negotiation between seller and buyer .The inaccuracy of length measuring is ±0.5%.

4.Standard:
IEC,BS,VDE,AS/NZS,ICEA,JIS and so on,designing and manufacturing special power cable according to the other standards required by the customer

5.Type and Description
TypeDescriptionApplication
CuAl
VVVLVPVC insulated and sheathed power cableCan be laid in indoor,tunnels and pipelines.Cable can not bear outer mechanical force.
VYVLYPVC insulated and PE sheathed power cable
VV22VLV22PVC insulated ,steel tape armored and PVC sheathed power cableCan be laid in indoor,outdoor,tunnels and pipelines.Cables can bear outer mechanical force.
VV23VLV23PVC insulated ,steel tape armored and PE sheathed power cable
VV32VLV32PVC insulated,thin steel wire armored and PVC sheathed power cableCan be laid in indoor and outdoor,the tunnel,the pipeline,the shaft,the water or dropping variance area,cable can bear outer mechanical force and considerable pulling force.
VV33VLV33PVC insulated,thin steel wire armored and PE sheathed power cable

TypeNominal Cross Section mm2
single Two coreThree coreFour coreFive core
VVVLV1.5-8001.5-8001.5-8001.5-8001.5-800
VYVLY
VRV
VV22VLV22-4-3004-4004-4004-400
VV23VLV23
VV32VLV3210-80010-80010-80010-80010-800
VV33VLV33

No of CoreInsulated core dichroic and number mark
Main Core,Neutral CoreGrounding Wire CoreNeutral Core (No.5Core)
1Random color --
2red1blue0
31,2,3 yellow,green,red-
3+1blue0
4
3+21,2,3,4 yellow,green,red,blueblack 0
4+1-black 0

In air


conductor
Nom .cross-section of conductor mm²

Unarmored cableArmored cable
Single-core2-core3-core
4-core
5-coreSingle-core2-core3-core
4-core
5-core








Copper conductor
1.51925191718-----
2.52431252122-----
43241332730--363031
64052423546--433637
1055705851526574595237
1674977666678597806768
25951209885871081221018787
35115150120105107136154124107107
50140180145127129163185151129131
70180230182160163207236186163166
95220280232204208253286237208211
120255325270232237294333276236240
150295375308270276338384314275277
185340430352308314388440359312316
240405515-369376460523-375381
300470600-413421528600-420426
400550700---624706---
500635810---722820---
630735942---831942---
8008301086---9581086---








Aluminum conductor
2.52225201717-----
42933262222--262222
63943353930--352930
1050564638.5405056463922
1666756152536675615230
2586987766678698776640
35103118958184103118958153
50127144116991011271441169967
7015817914412712915817914412784
95195220182154157195220182154129
120226256210182186226256210182186
150262298237210213262298237210213
185303342276237241303342276237241
240356404-286292356404-286292
300410465-325331410465-325331
400487553---487553---
500570645---570645---
630668757---668756---
800777880---777660---

Huatong Cable Inc. has made outstanding contribution to STATE GRID, China SOUTH POWER GRID and the construction of domestic and foreign power market since foundation in 1993. The honors should be attributed to more than 20 years of constant R&D, market service and strong will.

Huatong Cable Inc. has set up overhead conductor division, power cable division and division of wire and cable for equipment. The division respectively takes charge of manufacture and marketing of overhead conductor, power cable and wire and cable for equipment. In 2002, our company set up the cable industry design and technology R&D department, providing technical support for product design and production. Our company makes independent innovation, and seeks cooperation with academic institutions including Shanghai Electric Cable Research Institute and China Electric Power Research Institute so as to meet the customized demands of customers and production needs of special cable. Now our company owns 25 exclusive rights to use trademark registered at home and abroad and 14 independent intellectual property patents. ACSR-720/50 aluminum cable steel reinforced has passed the technical appraisal of China Electricity Council. 500KV or above extra-high voltage conductor was put into production, came into service and had good operation record.

In 2013, Huatong Brand was awarded WELL KNOWN MARK OF China by the Trademark Office of the State Administration of Industry and Commerce, enjoying a high reputation in domestic market. The honor and legal status reflect the recognition of customers and support of the State Administration of Industry and Commerce. It is the only enterprise in cable industry in Henan that was awarded WELL KNOWN MARK OF China and Huatong brand will serve the society in the future.
