4 Gang Aluminium LED Waterproof Rocker Switch Panel Circuit Breaker

Name: 4 Gang Aluminium LED Waterproof Rocker Switch Panel Circuit Breaker
Brand: all-electronics-online.com
SKU: 765667255
Availability: InStock
Rating: 4.8 (36 reviews)

Price:	US $ 0.1/Piece
Trade Terms:	FOB,DAP,EXW
Min Order:	200/Piece
Pay Type:	L/C,T/T,Western Union,Money Gram

Contact Supplier

Showroom Product Company Profile

Prod Model:	Circuit Breaker
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Usage:	Vehicle
Standard:	Standard
Lamp:	With Lamp
Color:	Black
Certification:	CE
Condition:	New

Product Description

Quick Details

Place of Origin: Guangdong, China (Mainland)
Brand Name: MAI YU
Model Number: MY-LB4H
Max. Current: 10A\20A
Max. Voltage: DC30V AC250V
Mechanical Life: 10000cycles
Input:: DC12V\24V
Protect Type:: Circuit Breakers
LED Color:: Red
Panel:: Aluminum
Waterproof:: IP68

Packaging & Delivery

Packaging Details:	packing with plastic box and card, 60pcsin a brown carton
Delivery Detail:	15~20days after payment

4 Gang Aluminium LED Waterproof Rocker Switch Panel Circuit Breaker

Good design,perfect for your machine

High quality,Made of Aluminum

Each switch comes with LED indicator

With rubber seal-cap to keep it water-tight,best for marine

Overload protection

UL approved

Competitive price

SplashProof,anti-corrosion

Easy to install,can be installed horizontally or vertically

Specification:

Waterproof LED Backlight 4 Gang Switch Panel
Material Description: Aluminum

Led:red

Installation:Pre-wired
Switches Available:4 Gang
Amp Rating per circuit:15amp Max
Rocker Switch:4

Breaker:4(5A x 2; 10A x 1; 15A x 1)
Loop Circuit:4(ON-OFF);

Switch System: Water-resistant enclosed Rocker switch
Rating: AC 125V 16A,250V 10A; DC 12V 20A,24V 10A
Dielectric Strength:AC 1500V 1minute
Operating Temperature:-25degree to 80degree
Electrical Life:10000 make and break cycles at full load
IP Rating:IP68

UL approved

Dimensions: 4.5" x 5.25" x 3.27"

Included:

- (1) 4-Gang LED Switch Panel

- (40) Labels for Easy Identification of Switches

- (1) Cover Plate

- (1) Silicone Gasket

- (6) Screws

- (4) Breakers
