| Prod Model: |
XLPE insulated cable |
| Jacke: |
PVC, PE |
| Product Name: |
Power Supply Cable |
| Standard: |
BS IEC ASTM DIN |
| Core: |
1-5 |
| Rated Voltage: |
1kv to 35kv |
| Nominal Cross-Section: |
1.5-1000 mm2 |
| Armoured: |
Swa Sta Awa Dbt |
| Color: |
Red, Green, Blue, Yellow, Black, etc |
| Conductor Type: |
Stranded |
| Feature: |
4 Core Power Cable |
| Application: |
Industrial |
| Voltage: |
Low and Medium Voltage Cable |
| Current: |
DC Cable |
| Insulation Material: |
XLPE |
| Certification: |
CE |
| Wire Core Material: |
Copper or Aluminum |
| Model: |
Yjv, Yjlv |
| Brand: |
Jinshui |
Product Description
4 core solid core round conductor armoured xlpe power cable
Specification:
a.Construction
Conductor: Copper, Aluminum
Insulation: Cross-linked polyethylene (XLPE)
Filler: Polypropylene filament with lapped binding tape
Binder: Binding tape
Inner sheath: Polyvinyl chloride (PVC)
Amour: Galvanized steel wire armored(SWA) or steel tape armored(STA)
Sheath: Polyvinyl chloride (PVC) or PE
b.Number of cable cores
Single core,two cores,three cores,four cores(Equal-section-area cores or three equal-section-area cores and one smaller section area neutral core),five cores(Five equal-section-area cores or three equal -section-area cores and two smaller section area neural cores).
c.Nominal Section
Area(mm2) :1.5 2.5 4 6 10 16 25 35 50 70 95 120 150 185 240 300 400 500 630 800 1000
d.Features
XLPE insulated power cable do not has excellent electric, mechanical properties,but also has powerful resistance against chemical corrosion,heat resistance and environmental stress resistance. Its structure is simple. The long period operating temperature is +90 °C. It is convenient to use and can be laid with no restriction of different level.
XLPE insulated steel wire armoured power cable: XLPE/PVC insulated power cable has a number of advantages over paper insulated and PVC insulated cable. XLPE cable has high electric strength, mechanical strength, high-aging resisting, environmental stress resisting anti-chemical corrosion, and it is simple construction, using convenient and higher operating of long term temperature. It can be laid with no drop restriction.
Various of flame-retardant and non-flame retardant XLPE cable can be manufactured with three technology(peroxide, silance and irradiation crosslinking). The flame-retardant cable covers all kinds of low-smoke low-halogen, low-smoke halogen free, and non-smoke nonhalogenated and three classes of A, B, C.
e.Standard
IEC60502,and BS6346, VDE, AS/NZS, UL,etc or as customer's request.
f.The Rated Voltage (kv)
1st class 0.6/1 1.8/3 3.6/6 6/10 8.7/15 12/20 18/30 21/35
2nd class 1/1 3/3 6/6 8.7/10 12/15 18/20 - 26/35
g.Application
1)These cables are most suitable for direct burial or for installation on trays or ducts, Where there is a risk of mechanical damage, armoured cables should be used.
2) For laying in ground along route with large difference of level able to bear external mechanical forces.
h.Model and Name
| China Type | Description | Application |
| Cu | Al |
| YJV | YJLV | XLPE insulation PVC sheath power cable (Cu/XLPE/PVC) | To be laid indoors, in tunnel, cable furrow or pipe, the cable couldn't bear mechanical force outside |
| YJY | YJLY | XLPE insulation PE sheath power cable (Cu/XLPE/PE) |
| YJV22 | YJLV22 | XLPE insulation, steel tape armor, PVC sheath power cable
(Cu/XLPE/PVC/STA/PVC) | To be laid underground, the cable could bear certain mechanical force, but it couldn't bear great pulling force. |
| YJV23 | YJLV23 | XLPE insulation, steel tape armor, PE sheath power cable
(Cu/XLPE/PVC/STA/PE) |
| YJV62 | YJLV62 | XLPE insulation, no magnetism steel tape armor, PE sheath power cable |
| YJV32 | YJLV32 | XLPE insulation, thin steel-wire armor, PVC sheath power cable
(Cu/XLPE/PVC/SWA/PVC) | Be applicable to the well, water inside and fall in the bad soil, the cable cans bear the equal dint outside the machine with pull the dint
. |
| YJV72 | YJLV72 | XLPE insulation, have no the magnetism thick steel-wire armor, PVC sheath power cable |
| YJV42 | YJLV42 | XLPE insulation, thick steel-wire armor, PVC sheath power cable | Be applicable to the well, underwater with the bottom of sea, the cable cans bear the bigger pressure with lead to pull the dint. |
| Type | Description | Application |
| Cu Core | Al Core |
YJV
ZR-YJV | YJLV
ZR-YJLV | Cu(Al)Core, XLPE Insulated, PVC Sheathed Power Cable
Cu(Al)Core, XLPE Insulated, PVC Sheathed flame- retardant Power Cable | Can be laid in indoor, outdoor, tunnels, cable channels, reinforced concrete pipelines and loose soil. Cable should not bear outer mechanic force, but can bear a certain tractional force. |
YJV22
ZR-YJV22 | YJLV22
ZR-YJLV22 | Cu(Al)Core, XLPE Insulated, Steel Tape Armored and PVC Sheathed Power Cable
Cu(Al)Core, XLPE Insulated, Steel Tape Armored and PVC Sheathed flame- retardant Power Cable | Laid underground. Cable can bear outer mechanic force, but should not bear large tractional force. |
YJV32
ZR-YJV32 | YJLV32
ZR-YJLV32 | Cu(Al)Core, XLPE Insulated, Steel Wire Armored and PVC Sheathed Power Cable
Cu(Al)Core, XLPE Insulated, Steel Wire Armored and PVC Sheathed flame- retardant Power Cable | Laid in indoor, tunnels and mines. Cable can bear outer mechanic force and fairly large tractional force. |
YJV42
ZR-YJV42 | YJLV42
ZR-YJLV42 | Cu(Al)Core, XLPE Insulated, Steel Wire Armored and PVC Sheathed Power Cable
Cu(Al)Core, XLPE Insulated, Steel Wire Armored and PVC Sheathed flame- retardant Power Cable | Can be laid in vertical section, indoor, tunnels and mines. Cable can bear outer mechanic force and very large tractional force. |
