4000W DC to AC Pure Sine Wave Power Inverters

Product Description

Product Description
Converts the DC electricity from sources such as batteries or fuel cells to AC electricity. The electricity can be at any required voltage; in particular it can operate AC equipment designed for mains operation, or rectified to produce DC at any desired voltage.


Products Features
1. Input & output fully insolated
2. High Surge: High surge current capability starts difficult loads such as TVs, camps, motors and other inductive loads
3. Soft start: Smooth start-up of the appliances.
4. Pure sine wave output waveform: Clean power for sensitive loads.
5. AC output identical to, and in some cases better than the power supplied by your utility
6. Cooling fan in the inverter is thermally activated and comes on when the inverters becomes warm, and turns off automatically after the inverter has cooled.
7. Low total harmonic distortion: Below 3%
8. Two LED indicators on the front panel shows the working and failure state.


Protection Function
1. Low voltage alarm & Shutdown
2. Over-voltage protection
3. Overload protection
4. Over-temperature protection
5. Short circuit protection
6. Soft start
7. Auto. Reset after being in protected
8. Grounding protection


Technical Specifications


Model		CZ-600S
Input	DC voltage	12V	24V	48V	110V
	Voltage range	10-16VDC	20-33VDC	40-63VDC	90-130VDC
	No load current draw	0.5A	0.3A	0.2A	0.1A
	Efficiency	> 90%
	DC connection	Cables With Clips or Car Adaptor
Output	AC voltage	100/110/120VAC or 220/230/240 VAC
	Continuous power	600W
	Surge power	1200W
	Waveform	Pure sine wave
	Frequency	50Hz or 60Hz
	AC regulation	3%
Protection	Low voltage alarm	10.5DC±0.5V	21DC±1V	42VDC±1V	96VDC±3V
	Low voltage shut down	10DC±0.5V	20DC±1V	40VDC±1V	90VDC±3V
	Short circuit	Shut off output automatically
	Over load	Shut off output
	Over voltage shut down	16±0.5V	33±1V	63±1V	130±3V
	Over thermal	Shut off output automatically
Environment	Working temperature	Between -10ºC and +50ºC
	Working humidity	20%~90%RH
	Storage temperature	Between -30ºC and +70ºC
Package	Machine size(mm)	265*165*85
	Packing size(mm)	365*230*148
	Net weight(kg)	2.5
	Gross weight(kg)	3
	Packing mode	Carton packaging
Other	Start	Soft start
	Cooling ways	Intelligent cooling fan
