400A BS88 J Fuse Used Pole Mounted Fuse Cutout

Name: 400A BS88 J Fuse Used Pole Mounted Fuse Cutout
Brand: all-electronics-online.com
SKU: 753857895
Availability: InStock
Rating: 4.9 (141 reviews)

Price:	US $ 12/Piece
Trade Terms:	FOB,CFR,CIF
Min Order:	50/Piece
Pay Type:	L/C,T/T,Western Union

Contact Supplier

Showroom Product Company Profile

Prod Model:	CE-400A-MPC
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Breaking Capacity:	High
Type:	Current Fuse
Usaga:	Low Voltage
Shape:	Box
Standard:	BS

Product Description

*Strong and rugged DMC Housing
*Sufficient room for termination Al. and Cu. cables upto 300mms
*Adequate Clearance & Creepage distances.
*Suitable for wedge type fuse links to BS88 with 82mm Fusing center
*IP43 degree of protection
*Top cover is removable for ease of installation and cabling
*Secure mounting with single bolt arrangement

Overhead Distribution
Fuse Service Equipment

This version can be pole, cross arm or wall mounted, its compact size allowing optimised arrangements resulting in less obtrusive installations.

Mechanical terminals with shear head bolts replace the studs usually associated with this type of cutout, eliminating the need for additional connecting lugs and specialised tools to ensure a simple, safe and effective joint.

The terminals will accept solid or stranded aluminium and solid copper conductors in the range 70 to 300mm². An adaptor is available for 25/35mm² copper or aluminium conductors. The fuse carrier accepts 'J' type fuselinks to BS88 rated up to 400A. With the PVC cable sealing grommets in place, the cutout is IP43 rated and has been designed to fully comply with the performance requirements specified in BS7656: 1993 for LV pole mounting fuses.

The enclosure is moulded in our own high performance, glass reinforced polyester,renowned and proven worldwide.

• Compact design for optimised mounting arrangements.
• Mechanical terminals require no additional lugs.
• Shear bolts - needs no special tools.
• Accepts aluminium and copper conductors between 70 and 300mm²
• Designed for IP43 rating and performance compliance with BS7656: 1993

Fuselinks
This fused Cutout is designed to accommodate standard wedge 'J' type fuselinks to BS 88 with
82mm fixing centres.
Standard fuselink ratings range from 20 to 400A

Cable Range	Fuse Link	Fuselink Ampere	Fuse Link Size
up to 300mms	BS88 J fuse	20-400A	82mm
