400A J Fuse Pole Mounted Fuse Cutout

Name: 400A J Fuse Pole Mounted Fuse Cutout
Brand: all-electronics-online.com
SKU: 723817405
Availability: InStock
Rating: 4.9 (61 reviews)

Price:	US $ 16/Piece
Trade Terms:	FOB,CFR,CIF
Min Order:	50/Piece
Pay Type:	L/C,T/T,Western Union

Contact Supplier

Showroom Product Company Profile

Prod Model:	CE
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Stud Size:	M12
Fuselink Ampere:	20-400A
Breaking Capacity:	High
Type:	Current Fuse
Usaga:	Low Voltage
Standard:	IEC

Product Description

Overhead Distribution Fuse Service Equipment
Pole Mounted Cutouts
Rated at 400A

Our industry standard unit is a very popular model.Designed with ease of use and simplicity in
mind, this pole mountable fused cutout is the ideal method of providing rural dwellings with a safe protected and reliable Low Voltage power supply.

Manufactured from our own track-resistant grade of Glass Reinforced Polyester, this fused Cutout is unobtrusive in appearance, but robust for outdoor applications. Each fused Cutout includes M12 captive studs with nuts and washers for the reception of cable sockets (lugs) up to 300mm² (compression type only) with copper or aluminium conductors. For ease of mounting to either a wall or a wooden pole, the fused cutout is supplied with an M12 coach screw.
• Robust and tough design using our own formulation of DMC.
• Slide fit front cover for ease of jointing.
• 'Easy fit' studs accept cable sockets (lugs) up to 300mm²
• Designed to accept standard 'J' type fuselinks
• Fully compliant with the requirements of BS 7656:1993
• Fully meeting the design criteria of IP43
Note: Fuselink not included

Fuselinks
This fused Cutout is designed to accommodate standard wedge 'J' type fuselinks to BS 88 with 82mm fixing centres.
Standard fuselink ratings range from 20 to 400A

Cable Range	Fuse Link	Fuselink Ampere	Fuse Link Size
up to 300mms	BS88 J fuse	20-400A	82mm
