40km 1.25g Wdm SFP Module Singlemode Sc Connector
| Price: |
US $ 10-100/Piece |
| Trade Terms: |
FOB,CFR,CIF |
| Min Order: |
10/Piece |
| Pay Type: |
L/C,T/T,Paypal,Western Union |
| Prod Model: |
1.25G WDM SFP Module SM-SC-SF 40KM |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Fiber Counts: |
Single Fiber |
| Fiber Type: |
Single Mode |
| Connector: |
Sc |
| Distance: |
40km |
| Data Transfer Rate: |
1.25g |
| Maximum Supply Voltage: |
-0.5~ 4.0 V |
| Relative Humidity: |
0~ 85 % |
| Case Operating Temperature: |
0~70ºC |
| Storage Temperature: |
-40~ 100ºC |
| Certification: |
RoHS |
| Condition: |
New |
| Support Network: |
Ethernet |
| Type: |
Wireless |
| Information Content: |
Data |
| Usage: |
Gigabit Ethernet |
Product Description
1. Description of 40KM 1.25G WDM SFP Module Singlemode SC Connector
* WDM SFP Module
*1.25G
* WDM
* 1310T/1550R and 1310R/1550T
* Single Mode
* SC Connector
* Single Fiber
* 40KM
* They are RoHS compliant and lead-free.
2. Feature of 40KM 1.25G WDM SFP Module Singlemode SC Connector
* Single SC receptacle optical interface compliant
* Hot-pluggable SFP footprint
* 1310nm FP laser transmitter
* RoHS compliant and Lead Free
* Up to 20km on 9/125um SMF
* Metal enclosure for lower EMI
* Single 3.3V power supply
* Lowpower dissipation <600mW
* Commercial operating temperature range: 0°C to 70°C
3. Application of 40KM 1.25G WDM SFP Module Singlemode SC Connector
* Gigabit Ethernet
* 1.06Gb/s Fiber Channel
4. Absolute Maximum Ratings
Parameter |
Symbol |
Min |
Typ |
Max |
Unit |
Ref |
Maximum Supply Voltage |
Vcc |
-0.5 |
|
4.0 |
V |
|
Storage Temperature |
TS |
-40 |
|
100 |
ºC |
|
Case Operating Temperature |
TOP |
0 |
|
70 |
ºC |
|
Relative Humidity |
RH |
0 |
|
85 |
% |
1 |
5. Electrical Characteristics(Top=25ºC,Vcc=3.3V)
Parameter |
Symbol |
Min |
Typ |
Max |
Unit |
Ref |
Supply Voltage |
Vcc |
3.00 |
|
3.60 |
V |
|
Supply Current |
Icc |
|
180 |
300 |
mA |
|
Transmitter |
|
|
|
|
|
|
Input differential impedance |
Rin |
|
100 |
|
Ω |
2 |
Single ended data input swing |
Vin, pp |
250 |
|
1200 |
mV |
|
Transmit Disable Voltage |
VD |
Vcc – 1.3 |
|
Vcc |
V |
|
Transmit Enable Voltage |
VEN |
Vee |
|
Vee+ 0.8 |
V |
|
Transmit Disable Assert Time |
|
|
|
10 |
us |
|
Receiver |
|
|
|
|
|
|
Single ended data output swing |
Vout, pp |
300 |
400 |
800 |
mV |
3 |
Data output rise time |
tr |
|
|
300 |
ps |
4 |
Data output fall time |
tf |
|
|
300 |
ps |
4 |
LOS Fault |
VLOS fault |
Vcc – 0.5 |
|
VccHOST |
V |
5 |
LOS Normal |
VLOS norm |
Vee |
|
Vee+0.5 |
V |
5 |
Deterministic Jitter Contribution |
RXΔDJ |
|
|
80 |
ps |
6 |
Total Jitter Contribution |
RXΔTJ |
|
|
122.4 |
ps |
|
