433MHz 2CH RF Wireless Remote Controller Yet428PC

Product Description

433mhz 2ch Rf Wireless Remote Controller YET428PC

1. Brief introduction
Our factory design and produce the one channel wireless intellect receiving control what can provide switch signal to the relay, so it can meet many requirements such as: the connection and lock of the switch and other special control programs. This kind of wireless intellect receiving control main apply to auto door, curtain, lifting appliance, gate way, lifter, industrial control and security field.
This kind of wireless receiving control is high confidentiality, large memory space, stable characteristics, low power consume and very convenience, it is unnecessary adopt the traditional wire jumper or dip switch code but only receive and store the wireless signal from the remote control, and The lost learnt control can't work if you delete the memory message of the receiving control, however, it should learning again by the owner if want to obtain the right of use.
2. The way of output
A. Keeps 8 seconds-- "1" connect
B. Self-lock control -- "2" connect
C. Interlock -- "3" connect
D. Inching control--disconnect
(check the Circuit diagram for details)
3. Learning way and steps
  Learning fixed code & learning code:
1. Press learning key of receiver-the pilot lamp light-release learning key and pilot lamp extinguish , indicate enter into the status of learning.
2. Press any button of the remote control, indicate learning success as the pilot lamp flash 5 times and automatically exit learning state. Receiver automatically exit learning state if you do nothing in 32 seconds.  (Can store 30pcs this type remote control)

Learning rolling code:

1. Press learning key of receiver-the pilot lamp light-release learning key and pilot lamp extinguish , indicate enter into the status of learning first time.
2. Press any button of the remote control, indicate first time learning success as the pilot lamp keep flashing slowly.
3. Repeat the operation of step "1", enter into the status of learning second time.
4. Press the same button in step "2", the pilot lamp flash 5 times, learning successful. (Can store 6pcs this type remote control)
