45W Single Output SMPS DIN Rail Switch Power Supply

Prod Model:	DR-45
Power:	45W
Input:	85 ~ 264VAC 120 ~ 370VDC
Output:	5V/12V/24V
Size:	78X93X56mm
Weight:	0.27kgs
Output Type:	Single
Warranty:	2 Years
Input Voltage:	Full Range
Connection Mode:	Series Switching Power Supply
Starting Mode:	Self-excited Switching Power Supply
Voltage Regulating Mode:	Frequency Modulation Type
Power Supplying System:	Terminal Power Distribution Equipment
Certification:	CCC
Output Power:	45W
Brand:	Deson
Energy Transmission:	Switch Power Supply

Product Description

45W Single Output Din Rail Switch Power Supply

1.Universal AC Input / Full Range
2.Installed on DIN rail TS35/ 7.5 or 15
3.Protection : short circuit/Overload/Over voltage/ Over temperature
4.Cooling by free air convection
5.100% full load burn-in test
6.Din Rail Installation
7.Isolation Class 2
8. 2 years warranty


Product Description


MODEL	DR-45-5	DR-45-12	DR-45-15	DR-45-24
DC VOLTAGE	5V	12V	15V	24V
RATED CURRENT	5A	3.5A	2.8A	2A
CURRENT RANGE	0 ~ 5A	0 ~ 3.5A	0 ~2.8A	0 ~ 2A
RATED POWER	25W	42W	42W	48W
RIPPLE & NOISE (max.)	100mVp-p	200mVp-p	240mVp-p	480mVp-p
VOLTAGE ADJ. RANGE	4.75 ~ 5.5V	10.8 ~ 13.2V	13.5 ~ 16.5V	21.6 ~ 26.4V
VOLTAGE TOLERANCE	±2.0%	±1.0%	±1.0%	±1.0%
LINE REGULATION	±1.0%	±1.0%	±1.0%	±1.0%
LOAD REGULATION	±1.0%	±1.0%	±1.0%	±1.0%
SETUP, RISE TIME	80ms, 60ms/230VAC at full load
HOLD TIME(Typ.)	100ms/230VAC at full load
VOLTAGE RANGE	85 ~ 264VAC 120 ~ 370VDC
FREQUENCY RANGE	47 ~ 63Hz
EFFICIENCY (Typ.)	72%	77%	77%	80%
AC CURRENT	1.5A/115VAC 0.75A/230VAC
INRUSH CURRENT(max.)	COLD START 28A/115VAC 56A/230VAC
LEAKAGE CURRENT	<1mA/240VAC
OVERLOAD	105 ~ 150% rated output power
	Protection type : Constant current limiting,recovers automatically after fault condition is removed
OVER VOLTAGE	5.75 ~ 6.75V	13.8 ~ 16.2V	17.25 ~ 20.25V	27.6 ~ 32.4V
	Protection type : Shut down o/p voltage,re-power on to recover
OVER TEMPERATURE	Tj 135ºC typically (U1) Detect on heat sink of power transistor
	Protection type : Shut down o/p voltage, recovers automatically after temperature goes down
WORKING TEMP.	-10 ~ +60ºC
WORKING HUMIDITY	20 ~ 90% RH non-condensing
STORAGE TEMP., HUMIDITY	-20 ~ +85ºC , 10 ~ 95% RH
TEMP. COEFFICIENT	±0.03%/ºC (0 ~ 50ºC)
VIBRATION	10 ~ 500Hz, 2G 10min./1cycle, 60min. each along X, Y, Z axes
SAFETY STANDARDS	Design refer to UL508,TUV EN60950-1
WITHSTAND VOLTAGE	I/P-O/P:3KVAC I/P-FG:1.5KVAC O/P-FG:0.5KVAC
ISOLATION RESISTANCE	I/P-O/P, I/P-FG, O/P-FG:100M Ohms/500VDC
EMI CONDUCTION & RADIATION	Compliance to EN55022 (CISPR22) Class B
HARMONIC CURRENT	Compliance to EN61000-3-2,-3
EMS IMMUNITY	Compliance to EN61000-4-2,3,4,5; ENV50204, EN55024, Light industry level, criteria A
MTBF	364.6K hrs min. MIL-HDBK-217F (25ºC)
DIMENSION	93*78*67mm (L*W*H)
PACKING	0.31Kg; 48pcs/16.1Kg/1.3CUFT
