48V 200A DC Contactor UK Origin Albight Sw182b-537t

Prod Model:	SW182B-537T
Certificate:	RoHS, Ce

Product Description

Product Description

  1. Reference


Item	Albright DC Contactor
Model	SW182B-537T
Voltage	48V
Current	200A
Size	24 x15 x15 mm
Used in	Electrical Sightseeing Cars
HS code	8536411000
Net Weight	1.64 KGS

2. Product information

The  DC182B-537Tmotor reversing type of contactor has been designed for direct current loads, particularly motors as used on electric vehicles such as industrial trucks. The 182B-537T  is a monoblock construction, resulting in a compact design which is compatible with modern electronic control systems. Developed for both interrupted and uninterrupted loads, the DC 182B-537T  is suitable for switching Resistive, Capacitive and Inductive loads.

• Interrupted current: opening and closing on load with frequent switching (results in increased contact resistance).

• Uninterrupted current: no or infrequent load switching requirements (maintains a lower contact resistance).

The main contact circuit, designed for motor reversing, has a built in failsafe, so that if both coils are energised simultaneously the contact arrangement is open circuit. The 182B-537T  has double breaking main contacts with silver alloy contact tips, which are weld resistant, hard wearing and have excellent conductivity. The 182B-537T  main stud terminals can be configured in a variety of ways in order to suit the application. Coil connections are by means of 6.3mm spades and mounting is via the supplied bracket and can be horizontal or vertical, when vertical the M8 contact studs should point upwards. If the requirement is for downwards orientation we can adjust the contactor to compensate for this.
