48V 6000va Pure Sine Wave High Frequency Inverter

Name: 48V 6000va Pure Sine Wave High Frequency Inverter
Brand: all-electronics-online.com
SKU: 721950205
Availability: InStock
Rating: 4.7 (61 reviews)

Price:	US $ 960/Piece
Trade Terms:	FOB,CFR,CIF
Min Order:	10/Piece
Pay Type:	L/C,T/T,Western Union

Contact Supplier

Showroom Product Company Profile

Prod Model:	TH6000
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Feature:	Telecom Use
Color:	Black/Whilte
Power Factor:	0.8
Display:	LED LCD
CE:	Yes
ISO:	Yes
Warranty:	1 Year
DC:	48V/110V/220V
Power Range:	500va~6000va
Type:	DC/AC Inverters
Phase:	Single
Output Power:	501 - 1000W
Power Source:	Telecom

Product Description

TH series pure sine wave Inverter/Power Inverter/Inverter Power Supply is a new device which can invert the DC to AC, especially design for the telecommsystem.

Main Features:

1. Full range protection: High /low voltage, over-charge, low -discharge, over-load, Over heat

2.1000va/2000va/3000va/5000va/6000va available

3. Powr factor: 0.8, when most of other inverters 's PF 0.6 r 0.7

4. Thermo - control fan 4. Intelligent Fan

5. Can connect with pure sensibility load

6. Efficiency: 93%

7. Pure sine wave

8. Three layers composite filter& magnetism shielded which can reduce input noise, pefect electromagnetism compatibility

Choose us, as --

1. Swift delivery -- at most 15 days for container order

2. Defect is lower than 0.2%

3.18 months warranty

Remark: We could tailor according to your special request.

Model		TH500	TH1000	TH2000	TH3000	TH5000
Rated capacity (VA)		500VA	1000VA	2000VA	3000VA	5000VA
Rated output power (W)		400W	800W	1600W	2400W	3500W
DC Input	Rated input	48V
	voltage (Vdc)
	Rated input	10	25	50	75	125
	current (A)
	Shut down	40V~60V
	voltage range
	Start-up	46V~57V
	voltage range
	Reflect noise	≤ 10%
	current
AC input	Allowed bypass	220± 15%
	voltage (Vac)
	Rated input	2.3	4.5	9.1	13.6	22.7
	current (A)
	Bypass switch	≤ 5ms
	time (ms)
AC output	Rated output	220Vac, 50Hz
	voltage and
	frequency
	Waveform	Pure sine wave
	Rated output	1.8	3.6	7.2	10.8	16
	current (A)
	Output voltage	220± 1.5%
	precision (V)
	Output frequency	50Hz± 0.1%
	precision (Hz)
	Waveform	≤ 3% (liner load)
	distortion (THD)
	Dynamic	5% (load 0← → 100%)
	respond time
	Power factor (PF)	0.7/0.8
	Over loading	120%, 30seconds
	capability
	Invert	≥ 85%
	efficiency
Operation	Insulating intensity	1500Vac, 1 minute
Situation	Noise (1m)	≤ 40dB
	Operation temperature	-25 C Degree~+50 C degree
	Humility	0~90%, non condensing
	Operation altitude (m)	≤ 1000
	Cooling mode	Forced wind cooling
Inverter status		Mains supply is normal, invert normal, battery under voltage, output overloading
External	19inch Rack(2U)	48288250	48288300		48288380
dimension	Weight	5Kg	7 Kg	8 Kg	11 Kg	13 Kg
	Stand-alone(WHD)	/	175275452		222328452
	Weight	/	8 Kg	9 Kg	12 Kg	15 Kg
	Color	White (grey)
Protection function		Input under/over voltage, output overloading, short circuit, city power high-low voltage protection
Output mode		Socket or terminal block			terminal block

Shenzhen Must Energy Technology Co., Ltd. Established in Shenzhen in 1998, Which is leading manufacturer of power protection produtcs & service solutions including UPS, power inverters, Solar inverters, charge controllers, Batteries, AVR for more than ten years, with a strong R&D team, internal automation equipment design and manufacturing capability, as well as continuous quality improvement, Santakups Electronic Company has become the leading supplier for long backup time power solution in the new world of information technology.

We' Ve kept our defect rate well under 0.5 percent. Logo printing service is available on request.
