| Prod Model: |
QW-PS500048 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Waveform: |
Pure Sine Wave Inverter |
| Frequency Type: |
Low Frequency Inverter |
| Rated Power: |
5kw |
| Commercial Power Range(VAC): |
220VAC |
| Battery DC Voltage: |
48V |
| Display: |
LCD&LED |
| Output Transfer Time: |
Typical 5ms |
| Housing Color: |
Black/Orange(Option) |
| Size: |
547*345*538mm/45kg |
| Phase: |
Single |
Product Description
48VDC 5000W UPS off-Grid Power Inverter (QW-PS500048)QUEENSWING Low Frequency UPS on-line Series Power Inverter includes:
1.300W~1000W 12V Inverter
2.600W~3000W 24V Inverter
3.1500W~5000W 48V Inverter
4.3000W~10000W 96V Inverter
5.5000W~10000W 192V Inverter
1. Features
1. Solar power or gird power or generator input, Pure sinewave output
2. CPU control and fan temperature control
3. Optional battery or gird power priority manual select
4. Protection of over-voltage,low-voltage, over-temperature and over-load,shout-circuit,
5. Intelligent battery management with protection against over-charged and over-discharged etc.
Application: Intelligent battery management; Provide the battery overcharge, discharge protection exten battery life. Apply to television, refrigerator, battery furnace, fan, microwave oven, air conditioning and other household devices.
2. Specification| Power Star Series | |
| Model No. | PS1000 | PS2000 | PS3000 | PS4000 | PS5000 | PS6000 | |
| Nominal Power | 1000W | 2000W | 3000W | 4000W | 5000W | 6000W | |
| AC Input | |
| Waveform | Pure Sine Wave | |
| Voltage | 120VAC/230VAC | |
| Acceptable Voltage | 194-243VAC\164-243VAC(wide mode) | |
| Line Low Transfer | 85V±4%/184(154 wide mode±4%) | |
| Line Low Return | 95V±4%/194(164 wide mode±4%) | |
| Line high Transfer | 135V±4%/253±4% | |
| Line high Return | 127V±4%/243±4% | |
| Frequency | 50Hz or 60Hz (Auto sensing) | |
| Line Low Transfer | 47Hz for 50Hz, 57Hz for 60Hz | |
| Line high Transfer | 55Hz for 50Hz, 65Hz for 60Hz | |
| AC Output | |
| Waveform | Pure Sine Wave (bypass mode sync to input) | |
| Voltage | 120/220/230/240VAC (bypass mode sync to input) | |
| Voltage Regulation | ±10%rms (bypass mode sync to input) | |
| Frequency | 50Hz±0.3Hz (bypass mode sync to input) | |
| Peak Power | 3 times of rating power | |
| Short Circuit Protection | Yes,shutdown after 10ms | |
| Power Factor | 0.9-1.0 | |
| DC Input | |
| BatteryVoltage | 12V/24V | 12V/24V/48V | 24V/48V | |
| Minimum Start Voltage | 10V for 12V,20V for 24V,40V for 48V | |
| Low Battery Alarm | 10.5V for 12V,21V for 24V,42V for 48V | |
| Low Battery Transfer | 10V for 12V,20V for 24V,40V for 48V | |
| High Voltage Alarm | 16V for 12V,32V for 24V,64V for 48V | |
| Max Charging Current | 35A/70A | |
| Over Charge Voltage | 15.7V for 12V,31.4V for 24V,62.8V for 48V | |
| Transfer Efficiency | |
| Line Mode | > 95% | |
| BatteryMode | >88% | |
| power saver | Available when the load is less than 25 Watts | |
| Indicators | |
| 7-LED Display | From the right to the left,LED1 line mode (green lighting) LED2 inverter mode | |
| (green lighting). LED3 charging mode (yellow lighting)/ LED4 Fully charged | |
| (green lighting). LED5 over heat shutdown(red lighting)/LED6 Overloaded | |
| shutdown(red lighting)/LED7 Saving Mode (green lighting) | |
| 3-LED Display | Charging Mode(green lighting)/inverter mode(green lighting)/ Alarm (red lighting) | |
| Switch selector | Saving Mode is on/off when push the switch forwards/backwards, keeping it horisontal is turning the inverter off. | |
| |
| Audible Alarm | Sounding when the heatsink's tem is over 105Cand shutdown after 30 seconds. | |
| Protections | low battery/over charging/over temp/over load | |
| Communications | RS-232/USB(custom-made) | |
| Enviromental | |
| Operating Environment | 0-40C,0-90%RH(non-condensing) | |
| Audible Noise | <60dB | |
| Physical | | | | | | | |
| Net Weight(KG) | 18 | 20 | 22 | 35 | 38 | 40 | |
| Dimension L*W*H(mm) | 442*218*179mm | 598*218*179mm | |
| *Specification are subject to change without prior notice | |
