| Prod Model: |
PS4K-4000W |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Surge Power: |
4500W for Few Seconds |
| Casing Color: |
Red |
| Frequency: |
50 or 60Hz Selectable |
| Phase: |
Single |
| Power Source: |
DC Power Source |
Product Description
PS4K-4000W air conditioner specialized
CARSPA - PS series new pure sine wave power inverter, it is featured as high reliability, and lower failure rate. It is better for use with air conditioner, motor, Air compressor, fridge etc. inductive loads.
Products Features:
1. Input& Output fully insolated
2. 100% pure sine wave output waveform: clear power for sensitive loads.
3. Small and light: with the technology of CPU centralized control and SMD inside.
4. Save the power and improves the working efficiency.
5. Low noise but high efficiency while working.
6. True sine wave output (THD less 2% typ.)
7. Advanced microprocessor.
8. Input polarity reverse/under voltage alarm/under voltage shutdown/over voltage protections.
9. Output short circuit/ overload, over temperature, earth leakage protections.
10. Remote control: by external switch.
Usage:
Ideally suitable for Journeys, camping, Tents, boat trip, working on the way and everywhere, where is no electricity! Simply connect our PS series power inverter with 12/24/48V batteries, for example as in a car, motorcycle, and camper, trucker, boat and use 100-120V or 220-240V electrical appliances.
|
Model |
PS4KU-121 |
PS4KU-241 |
PS4K-481 |
PS4KU-122 |
PS4KU-242 |
PS4K-482 |
|
Input voltage |
12V |
24V |
48V |
12V |
24V |
48V |
|
Input voltage range |
DC11-15V |
DC22-30V |
DC44-60V |
DC11-15V |
DC22-30V |
DC44-60V |
|
Output voltage |
100~120V AC |
220~240V AC |
|
Output frequency |
50/60Hz or 50/60 switch selectable |
|
Output power |
4000W |
|
Surge power |
12000W (for few seconds) |
|
USB port |
5V 500mA (optional) |
For 48V input, No USB |
|
Output waveform |
True sine wave |
|
Unit Size |
37.2* 23* 10.8cm |
|
N.W. / pcs |
8kg |
|
Certification |
CE, ROHS,E8 |
|
Protection |
Over-voltage protection, low-voltage alarm, under-voltage protection, over-heat protection, overload protection, short circuit protection, reverse polarity protection etc. |
Notes: 1. if you need 36V dc input, please tell our sales when place order.
2. We also can offer OEM and ODM service. |
