4p 100mA RCCB Residual Current Circuit Breaker (DZL5)

Name: 4p 100mA RCCB Residual Current Circuit Breaker (DZL5)
Brand: all-electronics-online.com
SKU: 685019445
Availability: InStock
Rating: 4.6 (140 reviews)

Price:	Negotiable/Piece
Trade Terms:	FOB
Min Order:	1/Piece
Pay Type:	L/C,T/T,D/P,Paypal

Contact Supplier

Showroom Product Company Profile

Prod Model:	DZL5
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Number Of Poles:	2p, 4p
Rated Current (a):	25, 40, 63, 80, 100
Rated Residual Operating Current (in)(Ma:	10, 30, 100, 300, 500
Voltage Un(V):	240(220) 415(380)
Arc-extinguishing Medium:	Air
Breaking Capacity:	Low Voltage Circuit Breakers
Certification:	CCC
Operation:	Manual Type
Installation:	Insert
Speed:	Normal Type Circuit Breaker
Structure:	Residual Current Circuit Breaker
Poles Number:	2. 4

Product Description

Why choose us?

1.20 years - Andeli Group Co., Ltd is founded in 1993.
2.12 share holding companies - Andeli have owns 12 share holding companies in Shanghai, Hunan, Zhejiang, UAE.
3.300 cooperating companies - We have over 300 cooperating companies.
4.3000 workers - We have over 3000 workers.
5. USD150, 000, 000 - The total assets is USD150, 000, 000.
6.235, 000 square meters - The area of Andeli is 235, 000 square meters.
7. Certification - We have passed ISO9001: 2000 Quality Management System and CCC, ROHS, CE, CB, SIMKO, KEMA...

Application

DZL5 residual current breaker is used in circuits up to single phase 230V, three phase 400V 50/60 Hz. RCCB is not suitable for use on DC pulse system. The RCCB can cut off the fault circuit immediately on theoccasion of shock hazard or earth leakage of trunk Thus it is suitable to avoid the shock hazard and firecaused by earth leakage. The RCCB is mainly suitable for use in variety of plants and enterprises, buildingconstruction, commerce, guesthouses and families. It conforms with the standards of IEC61008.

Type	DZL5
Pole	2P, 4P
Rated current In(A)	25, 40, 63, 80, 100
Rated residual operating current (InA)	10, 30, 100, 300, 500
Rated non-operating current for earth leakage In(A)	0.5In
Voltage Un(V)	240(220) 415(380)
Residual current off-time:	< 0.1s
Minimum value of rated making and breaking capacity	1KA
Rated conditional short-circuit current (Inc)	In=25, 40A Inc=1500A In=63A Inc=3000A

Established in 1993, ANDELI Group Co., Ltd. is a specialized manufacturer of low voltage electrical equipment. ANDELI Group owns 12 share-holding companies in Shanghai, Hunan, Zhejiang, UAE and over 300 member enterprises. "ANDELI" trademark is identified as one of the Chinese well-known trademarks. ANDELI Group ranks among top 500 in electric industry in China and our products are granted the title of the national products exempt from inspection.

With a workshop covering more than 27, 000 square meters, we are able to supply various circuit breaker, MCB, MCCB, RCCB, contactors, relays, fuse, transformer, voltage stabilizer, switching power supply, meters, solar products, welder and other electric products.

Moreover, with over 60 series and more than 2, 000 specifications, the annual output volume has reached USD24, 000, 000 in 2013. ANDELI regards quality of products as life. Our company is certified with ISO9001 and we have obtained CCC (China Compulsory Certification), RoHS, CCEE, CE, CB, SIMKO and KEMA certificates.

Through outstanding performance and excellent reputation, ANDELI has won many national awards and been recognized as one of the distinguished brand name in its local market. In the future, ANDELI will continue ensuring that our products meet the expectation of our customers with respect to product quality, and pursuing advance to integrative value of enterprise and sustainable growth.

Providing quality products, excellent service, competitive price and prompt delivery, we are now looking forward to even greater cooperation with overseas customers based on mutual benefits. Please feel free to contact us for more details.
