| Prod Model: |
TL440 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Dimenstions: |
47(L)*74(W)100(H)Mm |
| Weight: |
0.44kg |
| Color: |
Black/ Grey/ White |
| Terminal: |
F1 |
| Container: |
ABS |
| Charge (Cycle Use): |
4.8~5.0V |
| Charge (Standby Use): |
4.5~4.6V |
| Designed Life: |
3 Years |
| Warranty: |
1year |
| Type: |
Lead-Acid Batteries |
| Usage: |
Alarm System Power Tools |
| Nominal Voltage: |
4V |
| Discharge Rate: |
High Discharge Rate |
| Shape: |
Square Battery |
| Rechargeable: |
Chargeable |
Product Description
TELONG ENERGY TECHNOLOGY CO.,LTD
ABOUT US:
Shenzhen Telong Energy Technology Co.,LTD was founded in 2005, Specialized in researching,develop
ing,producing and sales of lead acid battery, lithium battery and Gel battery. Its worldwide sales network
already covers more than 100 countries and regions, and has a good cooperation partnership with seve
ral excellent operators.
PRODUCTS:
General AGM Lead Acid Battery (2v, 4v, 6v, 12v, 24v)
Deep Cycle Service AGM Battery (6v, 12v)
Front Access Terminal AGM Battery (12v)
GEL AGM Battery (2v, 12v)
OPzV,OPzS Tubular Gel Battery (2v, 12v)
Automotive batteries, Motorcycle batteries, Golf car batteries,etc.
| 1.Specifications |
| Nominal Voltage | 4V |
| Rated capacity (20 hour rate) | 4.0 Ah |
| Dimension | Total Height | 106mm (4.17 inches) |
| Height | 101mm (3.98 inches) |
| Length | 47mm (1.85 inches) |
| Width | 47mm (1.85inches) |
| Weight Approx | 0.44Kg |
| 2.Characteristics |
Capacity
25'C (77'C) | 20 hour rate(0.20A) | 4.00 AH |
| 10 hour rate(0.37A) | 3.70AH |
| 5 hour rate(0.69A) | 3.45 AH |
| 1 hour rate(2.40A) | 2.40 AH |
| Internal Resistance | Full charged Battery at 25 (77 ) | 19 m |
| Capacity affected by Temp | 40'C (104F) | 102% |
| 25'C (77'F) | 100% |
| 0'C (32'F) | 85% |
| (-15'C )5'F | 65% |
Self-Discharge
25'C (77'F) | Capacity after 3 month storage | 91% |
| Capacity after 6 month storage | 82% |
| Capacity after 12 month storage | 64% |
| Terminal | F1 |
Charge
(Constant Voltage) | Cycle | Initial Charging Current less than 1.6A |
| Voltage 4.8-4.9 V |
| Float | Voltage 4.5-4.6 V |
3.Applications
Fire & security systems / Uninterruptible power supplies;
Telecommunication systems / Electronic test equipment;
Television& video recorders / Alarm Systems,
Power Tools / Toys / Emergency Lighting Systems;
Other standby or primary power supplies.
Battery
Type | Nominal
Voltaage
(V) | Nominal
Capacity
(Ah) | Dimension | Weight | Terminal Type |
| Length | Width | Height | Total Height |
| mm | mm | mm | mm | kg |
| TL428 | 4 | 2.8 | 60 | 28 | 82 | 85 | 0.29 | F1 |
| TL435A | 4 | 3.5 | 48 | 48 | 102 | 108 | 0.42 | F1 |
| TL435B | 4 | 3.5 | 91 | 34 | 60 | 66 | 0.4 | F1 |
| TL445A | 4 | 4.5 | 48 | 48 | 102 | 108 | 0.52 | F1 |
| TL445B | 4 | 4.5 | 48 | 52 | 94 | 99 | 0.52 | F1 |
| TL455 | 4 | 4.5 | 48 | 48 | 102 | 108 | 0.64 | F1 |
| TL465 | 4 | 6.5 | 70 | 47 | 101 | 107 | 0.65 | F1 |
| TL475 | 4 | 7.5 | 70 | 47 | 101 | 107 | 0.72 | F1 |
| TL485 | 4 | 8.5 | 70 | 47 | 101 | 107 | 0.75 | F1 |
| TL495 | 4 | 9.5 | 70 | 47 | 101 | 107 | 0.82 | F1 |
| TL4100 | 4 | 10 | 102 | 44 | 95 | 101 | 1.1 | F1 |
| TL4200 | 4 | 20 | 149 | 43 | 154 | 159 | 2.1 | F2 |
