4X185sq. mm Copper XLPE Insulated PVC Jacketed Electrical Power Cable

Name: 4X185sq. mm Copper XLPE Insulated PVC Jacketed Electrical Power Cable
Brand: all-electronics-online.com
SKU: 687840732
Availability: InStock
Rating: 4.4 (60 reviews)

Price:	US $ 1.6-8.8/Meter
Trade Terms:	FOB,CFR,CIF
Min Order:	500/Meter
Pay Type:	L/C,T/T,D/P

Contact Supplier

Showroom Product Company Profile

Prod Model:	4X185sq. mm
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Certificate:	Ce, ISO 9001
Standard:	ASTM, AS/NZS, BS, CSA, DIN, IEC...
Application:	Power Station
Voltage:	Low and Medium Voltage Cable
Current:	DC Cable
Insulation Material:	XLPE
Certification:	ISO
Brand:	Jytop

Product Description

4X185sq.mm Copper XLPE Insulated PVC Jacketed Electrical Power Cable

1. Standard
The control cable can be produced according to the standard GB9330-1988,IEC,DIN,BS,and the factory can also manufacture the cables in accordance with other standards.

2.Scope of Application
The control cable are suitable for the wiring of electrical controlling equipments and instrument,monitoring and controlling return circuit,electrical protection and measurement in power distribution unit under the circumstance that the rated voltage is up to 450/750V AC.

3.Service Conditions
(1)The long-time working temperature of conductor of PVC insulated cable is 70oC
The long-time working temperature of conductor of XLPE insulated cable is 90oC
(2)The temperature for laying the cables can not be lower than 0oC.Permissible bending radius(r):unarmoured cable:r≥6D;(D: outer diameter of the cable);armoured or copper-tape screened cable:r≥12D;shielded flexible cable:r≥6D

Main technical data of 0.6/1KV, 4 core, Copper conductor, XLPE insulated and PVC or PE sheath cables
Note: RE= round conductor RM = stranded conductor SM=sectional conductor

Cable size	Conductor type	Nominal thickness of XLPE insulation(mm)	Nominal thickness of PVC or PE sheath(mm)	Approx. cable overall diameter (mm)	Max. D.C resistance @ 20 0 C (Ω/km)
4x1.5mm 2	RE or RM	0.7	1.8	10.5	12.1
4x2.5mm 2	RE or RM	0.7	1.8	11.5	7.41
4x4mm 2	RE or RM	0.7	1.8	12.6	4.61
4x6mm 2	RE or RM	0.7	1.8	13.8	3.08
4x10mm 2	RM	0.7	1.8	16.9	1.83
4x16mm 2	RM	0.7	1.8	19.5	1.15
4x25mm 2	SM	0.9	1.8	21.3	0.727
4x35mm 2	SM	0.9	1.8	23.4	0.524
4x50mm 2	SM	1.0	1.9	26.8	0.387
4x70mm 2	SM	1.1	2.0	30.6	0.268
4x95mm 2	SM	1.1	2.1	34.9	0.193
4x120mm 2	SM	1.2	2.3	38.4	0.153
4x150mm 2	SM	1.4	2.4	42.5	0.124
4x185mm 2	SM	1.6	2.6	47.4	0.0991
4x240mm 2	SM	1.7	2.8	53.4	0.0754
4x300mm 2	SM	1.8	3.0	59.0	0.0601

Zhengzhou JINYUAN Wire and Cable Co., Ltd, as a professional cable manufacturer. We have get ISO9001 and CE certificates. Our Professional and complete cable solutions make JYTOP Cables become to the partner of choice for international companies around the world,

PRODUCTS & STANDARDS & International Market:

1). Bare Conductor:

All Aluminum Conductor (AAC),

All Aluminum Alloy Conductor (AAAC),

Aluminum Conductor Steel Reinforced (ACSR),

Aluminum Alloy Conductor Steel Reinforced (AACSR),

Aluminum Conductor Aluminum Coated Steel Reinforced (ACSR/AW),

Aluminum Conductor Aluminum Alloy Reinforced (ACAR),

Aluminum Conductor Steel Supported (ACSS),

Aluminum Conductor Aluminum Coated Steel Reinforced (ACSR/AW)

All Copper Conductors(ACC),

Aluminum Coated Steel Wire(ACS),

Copper Coated Steel Wire(CCS),

Copper Coated Aluminum(CCA),

Galvanized Steel Wire(GSW),

Enameled Wire - Enameled round Aluminum Wire & Enameled round copper Wire

2). Overhead Cable:

Aerial Bundled Cable (ABC).

XLPE Cable,

Flexible Cable,

Single Core Cable,

2 Core Cable,

3 Core Cable,

4 Core Cable.

3). Building wire and cable:

THHN /THWN Cable

TW/THW Cable

PVC Insulated Wire,

XLPE Insulated cable.

4. Power Cable:

Armored /Non-armored Power cable

AWA Cable

SWA Cable

Standards: IEC, ASTM, AS/NZ, SANS, BS, DIN, NF, JISC, etc.

We can meet customers' special requirements, and provided OEM service.

Mainly Oversea Marketing: Southeast Asia, The Middle East, Africa, South America, so on.

We will be recognized as a professional Manufacturer in cable industry, through continuous improvement of our product quality, after sales service. We can give you the reliable solution for cable wires.

Company website: www.jytopcable.com
