| Prod Model: |
PAB500-220S12-G |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Size: |
200*266*64 |
| Output Type: |
Single |
| Warranty: |
2 Years |
| Input Voltage: |
220V |
| Connection Mode: |
Series Switching Power Supply |
| Starting Mode: |
Separate-excited Switching Power Supply |
| Voltage Regulating Mode: |
Width Modulation Type |
| Power Supplying System: |
Terminal Power Distribution Equipment |
| Certification: |
ISO |
| Output Power: |
500W |
| Brand: |
Pengtu |
Product Description
PAB-G AC/DC Small Volume Module Power Supply Series 500-1000W
Features
Wide range of input voltage
Broadband noise filter of input
Surge suppress circuit of input
Comply witn UL1950, IEC950 safety regulation
Attractive outline design
Terminae connection method
Fast dynamic response
Input Characteristic
Input voltage range...176 ~ 264 VAC Rated value: 220VAC
Output Characteristic
Voltage set-point accuracy...± 1%
Line regulation(main)...± 0.2%
Load regulation(main)...± 0.4%
Temperature coefficient...± 0.01%/º C
Output current limiting...110%(Typ)
Dynamic response...400μ S
Output current...6-50A
Output voltage...12-110V
Power...500-1000W
General Characteristic
Switching frequency...160-200 kHz
Isolation resistance...200 MΩ
MTBF...>500000H
Isolation voltage
Input-output: >1500 VAC/1min(leakage current<5mA)
Input-case: >1500 VAC/1min(leakage current<5mA)
Output-case: >500 VDC/1min
Environmental Characteristic
Case temperature...Industry: -25-+85º C; MilitaryI: -40~ +85º C
Military II: -55~ +85º C
Storage temperature...Industry: -45~ +105º C; Military: -55~ +105º C
| Input Voltage(VDC) | Input Voltage(Range) | Output Voltage(VDC) | Output Current(A) | Pk-pk(mv)
Ripple and noise | Efficiency | Models |
| S | 220 | 176-264 | 12 | 41.67 | 120 | 86% | PAB500-220S12-G |
| 220 | 176-264 | 15 | 33.33 | 150 | 86% | PAB500-220S15-G |
| 220 | 176-264 | 24 | 31.25 | 200 | 86% | PAB600-220S24-G |
| 220 | 176-264 | 28 | 26.78 | 280 | 86% | PAB600-220S28-G |
| 220 | 176-264 | 48 | 16.67 | 400 | 87% | PAB800-220S48-G |
| 220 | 176-264 | 110 | 8 | 800 | 87% | PAB880-220S110-G |
D | 220 | 176-264 | 05& 05 | 30& 30 | 50& 50 | 85% | PAB300-220D05&05-G |
| 220 | 176-264 | 12& 12 | 20& 20 | 100& 100 | 88% | PAB480-220D12&12-G |
| 220 | 176-264 | 15& 15 | 20& 20 | 150& 150 | 88% | PAB600-22015&15-G |
| 220 | 176-264 | 12& 24 | 30& 15 | 150& 200 | 87% | PAB720-220D12&24-G |
| 220 | 176-264 | 24& 24 | 15& 15 | 200& 200 | 88% | PAB720-220D24&24-G |
Nanjing Pengtu Power Supply Co., Ltd was established in 2007, is located in No. 381, Pugang Road, Jiangning District, Nanjing, China. Our company is a manufacturer specializing in power product development, design, production, sales and service company.
Products range are following.
Air cooling type AC/DC module power supply (AC/DC Converter), rate range from 3W to 2KW.
Air cooling type DC/DC module power supply (DC/DC Converter), rate range from 2W to 1KW.
Fan cooling type switching power supply, rate range from 5W to 10KW, including fan cooling and water cooling AC/DC on board battery charger 3.3KW and 6.6KW series.
Our company has not only passed ISO9001-2008 Quality System Certification, and some products through the Measurement of Jiangsu Province Academy of Sciences and National Electric Power Academy of Sciences and other authorities detection. Product safety and electrical properties fully comply with the Ministry of Information Industry YD/T731-2000 High Frequency Switch Rectifier Standard.
Our company is not only passed the IS09001-2008 quality system certification, but also IS014001 quality environmental protection system certification and automotive TS16949: 2009 system certification. Some products also pass electromagnetic compatibility through the "Jiangsu Institute of Metrology" and other authoritative departments of the test. Product safety and electrical performance in full compliance with the Ministry of Information Industry "YD / T731", "YD / T731-2000 high frequency switching rectifier standard", some products through UL, CE demonstration.
Since its establishment, our company adhere to the science and technology as the forerunner, take the technology as the backing, and constantly develop all kinds of hi-tech leading colleague' S new products. Currently we has a number of national patent. The "PengTu" brand power has been widely used in railway, military, aerospace, power, communication, control, instrument, car equipment, ship and major scientific research institutions, etc various fields. We have got high praise from the customers.
We will always remember the"quality first service first" business philosophy, to provide users with convenient one-stop service. With our practical, innovation, refinement spirit of enterprise, we accelerate the company' S technical innovation and product development and at the same time we will with more quality products, more detailed services and more excellent results return to the vast number of customers. Let us work together to create you and I better tomorrow.
