| Prod Model: |
TSM2 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Rated Insulating Voltage: |
500V, 800V |
| Rated Current: |
6-1600A |
| Number Of Poles: |
3, 4 |
| Ultimate Short Circuit Breaking Capacity: |
25-125ka |
| Breaking Capacity: |
Low Voltage Circuit Breakers |
| Operation: |
Electric Type |
| Speed: |
Normal Type Circuit Breaker |
| Arc-extinguishing Medium: |
Vacuum |
| Installation: |
Fixed |
| Structure: |
MCCB |
| Poles Number: |
3 |
| Certification: |
CE |
Product Description
Product Description(circuit breaker)Moulded Case Circuit Breaker can also be used for un-frequent start, overload, short-circuit and voltage absent protectionCM1 Series moulded case circuit breaker (hereafter reffered to as simply breaker), whose insulatedVoltages 800V, suitable for conversion and starting a motor not frequently in the circuitof 50Hz AC (or60Hz) rated working voltage 690V, rated working current up to 1250A, The breaker have overload,Short circuit and under-voltage protection device, which protects the circuit and power equipment against damage.According to level of the breaking capacity of rated maximal short circuit, the breaker can be classifiedInto two types, Type L(Standard type), Type M(Higher breaking type), Such breaker possesses theFeatures such as compactness, high breaking capacity, short arc-cover and shock resistance, etc.The breaker can be installed vertically (upright) as well as horizontally (crosswise).The breaker has disconnecting function, its corresponding symbolis hownasNormal application environment Altitude ≤ 2000mAmbient temperature -5~+40Tolerance of the influence of humid air.Tolerance of the influence of salt mist and oil mist.Maximal gradient is 22.5Kept in the media without explosive hazard.There is no conductive dust or gas which is able to erode metal or destroy insuationKept in the place where no sleet will attack.
Specification of circuit breaker | Type | Rated current(A) | Number of Poles | Rated
Insulating Voltage (V) | Arcing
Distance (mm) | Ultimate
Short Circuit Breaking Capacity(kA) | Service
Short Circuit Breaking Capacity | Operation
performance |
| ON | OFF |
| TSM2-63L | 6,10,16,20,
25,32,40,50,63 | 3,4 | 500V | 0 | 25 | 18 | 1500 | 8500 |
| TSM2-63M | 0 | 35 | 22 |
| TSM2-100L | 10,16,20,
25,32,40,50,
63,80,100 | 800V | 0(≤50) | 35 | 22 |
| TSM2-100M | 0(≤50) | 50 | 35 |
| TSM2-100H | 0(≤50) | 85 | 50 | 1000 | 7000 |
| TSM2-225L | 100,125,
160,180,
200,225 | ≤50 | 35 | 22 |
| TSM2-225M | ≤50 | 50 | 35 |
| TSM2-225H | ≤50 | 85 | 50 | 1000 | 4000 |
| TSM2-400L | 225,250,
315,350,400 | ≤50 | 50 | 35 |
| TSM2-400M | ≤100 | 65 | 42 |
| TSM2-630L | 400,630 | ≤100 | 50 | 35 |
| TSM2-630H | ≤100 | 100 | 65 |
| TSM2-800M | 630,700
800 | 3 | ≤100 | 75 | 50 |
| TSM2-800H | ≤100 | 100 | 65 |
| TSM2-1250M | 1000,1250 | ≤100 | 100 | 65 |
| TSM2-1250H | ≤100 | 125 | 75 |
| TSM2-1600M | 1600 | ≤100 | 125 | 80 |
Packing of our Circuit Breaker
IF YOU ARE INTERESTED IN OUR CIRCUIT BREAKER, PLEASE CONTACT WITH US. THANK YOU.
