Prod Model: |
Sc50M |
Current: |
50A |
Voltage: |
50-1000V |
Part Number: |
Sc50m |
If: |
50A |
Case: |
Copper |
Certificate: |
ISO |
Vf: |
1V |
Samples: |
Free Samples |
Lead Time: |
1-2 Weeks |
Manufacturing Technology: |
Optoelectronic Semiconductor |
Material: |
Element Semiconductor |
Type: |
Intrinsic Semiconductor |
Package: |
SMD |
Model: |
Sc50m |
Batch Number: |
2016+ |
Brand: |
Sy |
Product Description
50A,50-1000V Soza Cell Diode rectifier SC50M
Soza Cell Diode
we can supply 25A, 35A,50A. volt is 50-1000V Soza Cell Diode | Part Number | Voltage |
25 Ampere | SC25A--SC25M | 50-1000V |
35 Ampere | SC35A--SC35M |
50 Ampere | SC50A--SC50M |
Features
1, High surge capability .
2, High current capability .
3, Low leakage .
4, High temperature soldering guaranteed250¡æfor10 seconds .Mechanical DataCase: Molded plastic case
Terminals: Plated terminals, solderable per MIL-STD-202,method 208.
Polarity : Color band denotes cathode end.
Mounting Position: Any
Weight: 1.8 grams.Automotive diodes range Series | Part No | Max Rating and Electrical Characteristics |
VRWM | IF | IFSM (A)8.3ms single half | VF | IRRM(μA) | Operation temperature |
(V) | (A) | sine-wave | (V) | @Ta=25ºC |
SOZA CELL | SC25A | 50 | 25 | 300 | 1 | 5 | -55ºC~+150ºC |
SC25B | 100 | 25 | 300 | 1 | 5 | -55ºC~+150ºC |
SC25D | 200 | 25 | 300 | 1 | 5 | -55ºC~+150ºC |
SC25G | 400 | 25 | 300 | 1 | 5 | -55ºC~+150ºC |
SC25J | 600 | 25 | 300 | 1 | 5 | -55ºC~+150ºC |
SC25K | 800 | 25 | 300 | 1 | 5 | -55ºC~+150ºC |
SC25M | 1000 | 25 | 300 | 1 | 5 | -55ºC~+150ºC |
SC35A | 50 | 35 | 400 | 1 | 5 | -55ºC~+150ºC |
SC35B | 100 | 35 | 400 | 1 | 5 | -55ºC~+150ºC |
SC35D | 200 | 35 | 400 | 1 | 5 | -55ºC~+150ºC |
SC35G | 400 | 35 | 400 | 1 | 5 | -55ºC~+150ºC |
SC35J | 600 | 35 | 400 | 1 | 5 | -55ºC~+150ºC |
SC35K | 800 | 35 | 400 | 1 | 5 | -55ºC~+150ºC |
SC35M | 1000 | 35 | 400 | 1 | 5 | -55ºC~+150ºC |
SC50A | 50 | 50 | 500 | 1 | 5 | -55ºC~+150ºC |
SC50B | 100 | 50 | 500 | 1 | 5 | -55ºC~+150ºC |
SC50D | 200 | 50 | 500 | 1 | 5 | -55ºC~+150ºC |
SC50G | 400 | 50 | 500 | 1 | 5 | -55ºC~+150ºC |
SC50J | 600 | 50 | 500 | 1 | 5 | -55ºC~+150ºC |
SC50K | 800 | 50 | 500 | 1 | 5 | -55ºC~+150ºC |
SC50M | 1000 | 50 | 500 | 1 | 5 | -55ºC~+150ºC |
BUTTON | AR2505 | 50 | 25 | 300 | 1 | 5 | -55ºC~+150ºC |
AR251 | 100 | 25 | 300 | 1 | 5 | -55ºC~+150ºC |
AR252 | 200 | 25 | 300 | 1 | 5 | -55ºC~+150ºC |
AR254 | 400 | 25 | 300 | 1 | 5 | -55ºC~+150ºC |
AR256 | 600 | 25 | 300 | 1 | 5 | -55ºC~+150ºC |
AR258 | 800 | 25 | 300 | 1 | 5 | -55ºC~+150ºC |
AR2510 | 1000 | 25 | 300 | 1 | 5 | -55ºC~+150ºC |
AR3505 | 50 | 25 | 400 | 1 | 5 | -55ºC~+150ºC |
AR351 | 100 | 25 | 400 | 1 | 5 | -55ºC~+150ºC |
AR352 | 200 | 35 | 400 | 1 | 5 | -55ºC~+150ºC |
AR354 | 400 | 35 | 400 | 1 | 5 | -55ºC~+150ºC |
AR356 | 600 | 35 | 400 | 1 | 5 | -55ºC~+150ºC |
AR358 | 800 | 35 | 400 | 1 | 5 | -55ºC~+150ºC |
AR3510 | 1000 | 35 | 400 | 1 | 5 | -55ºC~+150ºC |
AR5005 | 50 | 50 | 500 | 1 | 5 | -55ºC~+150ºC |
AR501 | 100 | 50 | 500 | 1 | 5 | -55ºC~+150ºC |
AR502 | 200 | 50 | 500 | 1 | 5 | -55ºC~+150ºC |
AR504 | 400 | 50 | 500 | 1 | 5 | -55ºC~+150ºC |
AR506 | 600 | 50 | 500 | 1 | 5 | -55ºC~+150ºC |
AR508 | 800 | 50 | 500 | 1 | 5 | -55ºC~+150ºC |
AR5010 | 1000 | 50 | 500 | 1 | 5 | -55ºC~+150ºC |
LEAD BUTTON | ARL2505 | 50 | 25 | 300 | 1 | 5 | -55ºC ~ +150ºC |
ARL251 | 100 | 25 | 300 | 1 | 5 | -55ºC ~ +150ºC |
ARL252 | 200 | 25 | 300 | 1 | 5 | -55ºC ~ +150ºC |
ARL254 | 400 | 25 | 300 | 1 | 5 | -55ºC ~ +150ºC |
ARL256 | 600 | 25 | 300 | 1 | 5 | -55ºC ~ +150ºC |
ARL258 | 800 | 25 | 300 | 1 | 5 | -55ºC ~ +150ºC |
ARL2510 | 1000 | 25 | 300 | 1 | 5 | -55ºC ~ +150ºC |
ARL2512 | 1200 | 25 | 300 | 1 | 5 | -55ºC ~ +150ºC |
ARL3505 | 50 | 35 | 300 | 1 | 5 | -55ºC ~ +150ºC |
ARL351 | 100 | 35 | 300 | 1 | 5 | -55ºC ~ +150ºC |
ARL352 | 200 | 35 | 300 | 1 | 5 | -55ºC ~ +150ºC |
ARL354 | 400 | 35 | 300 | 1 | 5 | -55ºC ~ +150ºC |
ARL356 | 600 | 35 | 300 | 1 | 5 | -55ºC ~ +150ºC |
ARL358 | 800 | 35 | 300 | 1 | 5 | -55ºC ~ +150ºC |
ARL3510 | 1000 | 35 | 300 | 1 | 5 | -55ºC ~ +150ºC |
ARL3512 | 1200 | 35 | 300 | 1 | 5 | -55ºC ~ +150ºC |
Series | Part No | Max Rating and Electrical Characteristics |
VRWM | IF | IFSM (A)8.3ms single half | VF | IRRM(μA) | Operation temperature |
(V) | (A) | sine-wave | (V) | @Ta=25ºC |
BLOCK | BD3005 | 50 | 30 | 300 | 1.1 | 5 | -55ºC~+150ºC |
BD301 | 100 | 30 | 300 | 1.1 | 5 | -55ºC~+150ºC |
BD302 | 200 | 30 | 300 | 1.1 | 5 | -55ºC~+150ºC |
BD304 | 400 | 30 | 300 | 1.1 | 5 | -55ºC~+150ºC |
BD306 | 600 | 30 | 300 | 1.1 | 5 | -55ºC~+150ºC |
BD3505 | 50 | 35 | 350 | 1.1 | 5 | -55ºC~+150ºC |
BD351 | 100 | 35 | 350 | 1.1 | 5 | -55ºC~+150ºC |
BD352 | 200 | 35 | 350 | 1.1 | 5 | -55ºC~+150ºC |
BD354 | 400 | 35 | 350 | 1.1 | 5 | -55ºC~+150ºC |
BD356 | 600 | 35 | 350 | 1.1 | 5 | -55ºC~+150ºC |
BD5005 | 50 | 50 | 500 | 1.1 | 5 | -55ºC~+150ºC |
BD501 | 100 | 50 | 500 | 1.1 | 5 | -55ºC~+150ºC |
BD502 | 200 | 50 | 500 | 1.1 | 5 | -55ºC~+150ºC |
BD504 | 400 | 50 | 500 | 1.1 | 5 | -55ºC~+150ºC |
BD506 | 600 | 50 | 500 | 1.1 | 5 | -55ºC~+150ºC |
TIN-CAN | TC2505 | 50 | 25 | 300 | 1 | 5 | -55ºC~+150ºC |
TC251 | 100 | 25 | 300 | 1 | 5 | -55ºC~+150ºC |
TC252 | 200 | 25 | 300 | 1 | 5 | -55ºC~+150ºC |
TC253 | 300 | 25 | 300 | 1 | 5 | -55ºC~+150ºC |
TC254 | 400 | 25 | 300 | 1 | 5 | -55ºC~+150ºC |
TC255 | 500 | 25 | 300 | 1 | 5 | -55ºC~+150ºC |
TC256 | 600 | 25 | 300 | 1 | 5 | -55ºC~+150ºC |
TC3505 | 50 | 35 | 400 | 1 | 5 | -55ºC~+150ºC |
TC351 | 100 | 35 | 400 | 1 | 5 | -55ºC~+150ºC |
TC352 | 200 | 35 | 400 | 1 | 5 | -55ºC~+150ºC |
TC353 | 300 | 35 | 400 | 1 | 5 | -55ºC~+150ºC |
TC354 | 400 | 35 | 400 | 1 | 5 | -55ºC~+150ºC |
TC355 | 500 | 35 | 400 | 1 | 5 | -55ºC~+150ºC |
TC356 | 600 | 35 | 400 | 1 | 5 | -55ºC~+150 |
MOTOR PRESS FIT DIODE | MP2505 | 50 | 25 | 300 | 1 | 5 | -55ºC~+150ºC |
MP251 | 100 | 25 | 300 | 1 | 5 | -55ºC~+150ºC |
MP252 | 200 | 25 | 300 | 1 | 5 | -55ºC~+150ºC |
MP253 | 300 | 25 | 300 | 1 | 5 | -55ºC~+150ºC |
MP254 | 400 | 25 | 300 | 1 | 5 | -55ºC~+150ºC |
MP255 | 500 | 25 | 300 | 1 | 5 | -55ºC~+150ºC |
MP256 | 600 | 25 | 300 | 1 | 5 | -55ºC~+150ºC |
MP3505 | 50 | 35 | 400 | 1 | 5 | -55ºC~+150ºC |
MP351 | 100 | 35 | 400 | 1 | 5 | -55ºC~+150ºC |
MP352 | 200 | 35 | 400 | 1 | 5 | -55ºC~+150ºC |
MP353 | 300 | 35 | 400 | 1 | 5 | -55ºC~+150ºC |
MP354 | 400 | 35 | 400 | 1 | 5 | -55ºC~+150ºC |
MP355 | 500 | 35 | 400 | 1 | 5 | -55ºC~+150ºC |
MP356 | 600 | 35 | 400 | 1 | 5 | -55ºC~+150ºC |
MP5005 | 50 | 35 | 400 | 1 | 5 | -55ºC~+150ºC |
MP501 | 100 | 35 | 400 | 1 | 5 | -55ºC~+150ºC |
MP502 | 200 | 35 | 400 | 1 | 5 | -55ºC~+150ºC |
MP503 | 300 | 35 | 400 | 1 | 5 | -55ºC~+150ºC |
MP504 | 400 | 35 | 400 | 1 | 5 | -55ºC~+150ºC |
MP505 | 500 | 35 | 400 | 1 | 5 | -55ºC~+150ºC |
MP506 | 600 | 35 | 400 | 1 | 5 | -55ºC~+150ºC |
BOSCH PRESS-FIT DIODE | BP2505 | 50 | 25 | 300 | 1 | 5 | -55ºC~+150ºC |
BP251 | 100 | 25 | 300 | 1 | 5 | -55ºC~+150ºC |
BP252 | 200 | 25 | 300 | 1 | 5 | -55ºC~+150ºC |
BP253 | 300 | 25 | 300 | 1 | 5 | -55ºC~+150ºC |
BP254 | 400 | 25 | 300 | 1 | 5 | -55ºC~+150ºC |
BP255 | 500 | 25 | 300 | 1 | 5 | -55ºC~+150ºC |
BP256 | 600 | 25 | 300 | 1 | 5 | -55ºC~+150ºC |
BP3505 | 50 | 35 | 400 | 1 | 5 | -55ºC~+150ºC |
BP351 | 100 | 35 | 400 | 1 | 5 | -55ºC~+150ºC |
BP352 | 200 | 35 | 400 | 1 | 5 | -55ºC~+150ºC |
BP353 | 300 | 35 | 400 | 1 | 5 | -55ºC~+150ºC |
BP354 | 400 | 35 | 400 | 1 | 5 | -55ºC~+150ºC |
BP355 | 500 | 35 | 400 | 1 | 5 | -55ºC~+150ºC |
BP356 | 600 | 35 | 400 | 1 | 5 | -55ºC~+150ºC |
BP5005 | 50 | 35 | 400 | 1 | 5 | -55ºC~+150ºC |
BP501 | 100 | 35 | 400 | 1 | 5 | -55ºC~+150ºC |
BP502 | 200 | 35 | 400 | 1 | 5 | -55ºC~+150ºC |
BP503 | 300 | 35 | 400 | 1 | 5 | -55ºC~+150ºC |
BP504 | 400 | 35 | 400 | 1 | 5 | -55ºC~+150ºC |
BP505 | 500 | 35 | 400 | 1 | 5 | -55ºC~+150ºC |
BP506 | 600 | 35 | 400 | 1 | 5 | - |
