51.8V 11.6ah 14s4p Hl01 Lithium Battery Pack

Name: 51.8V 11.6ah 14s4p Hl01 Lithium Battery Pack
Brand: all-electronics-online.com
SKU: 790633595
Availability: InStock
Rating: 5 (146 reviews)

Price:	US $ 265/Piece
Min Order:	5/Piece
Pay Type:	L/C,T/T,Western Union,Paypal

Contact Supplier

Showroom Product Company Profile

Prod Model:	BB-EB-HL0114S4P
Application:	E-Bike, E-Scooter
Structure:	Panasnoic 18650PF 14s4p
Case Dimension:	3619290mm
Indicator:	4 Levels Indicator
Working Current:	15-30A
Peak Current:	60A
Type:	Lithium-Ion Battery Pack
Connection Mode:	Series and Parallel
Standard Voltage:	48V
Usage:	E-Bike, E-Scooter
Electrolyte:	Li-ion

Product Description

51.8V 11.6Ah 14S4P HL01 lithium battery pack

Features
1. 51.8V 11.6Ah HL01 lithium-ion battery
2. 600-800 times cycles
3. Stable performanc
4. No memery effect
5. High energy density
6. Panasonic 18650PF 2900mAh 13S4P

Details

NO	Item	General Parameter				Remark
1	Model	BB-EB-HL0114S4P
2	Standard capacity(0.5C)	11.6Ah
3	Rated voltage	51.8V
4	Max. charge voltage	58.8V				Single Ave. charge Voltage: 4.2V
5	Over charge protection	Over charge detection voltage		4.40±0.025V
		Over charge release voltage		4.3±0.025V
6	Standard charge current	2A				0.2C
7	Charging time	About 300 minutes				X C
8	Discharge cut-off voltage	38.5V				Single Ave. Discharge Voltage: 2.75V
9	Over discharge Protection	Over discharge detection voltage			2.5±0.05V
		Over discharge release voltage			2.75±0.05V
10	Max. continuous discharge current	15-30A(adjustable)
11	Peak discharge current	60A
12	Short circuit protection	Detetion delay time			XXμs	Release condition	Cut-off load
12	Battery dimension	3619290mm
13	Total weight(Approx.)	About 3.58kg
14	Operation temperature	Standard	0ºC~45ºC
		Discharge	-20ºC~65ºC
		Storage	-20ºC~65ºC

More pictures:

Payment Terms
1.We accept bank transfer(T/T) ,PayPal,Cash.
2.If you prefer other payment method,please contact us by email.

Shipping Terms
1.Samples order: sending by Express ( DHL/ UPS/ FEDEX/ TNT )
2.Bulk order: sending out by air/express/sea.

Warranty Instructions
1.We provide 2 years Warranty.
2.Warranty code: quality problems, defective goods can be fixed or replacement; Man-made damage, inflowing water, fault operation leading to short circuit or burning, damaged by carrier is out of our warranty.
3.Goods should be returned in original condition to qualify for a replacement or repair.

Advantages
1.OEM&ODM manufacture, design any of special shape, dimension and other requirements battery packs.
2.Good quality, competitive price, fast delivery, excellent service.
3. Wonderful package, stable shipment, 100% testing and inspection before shipment to insure the quality.
4.CE, RoHS, UN38.3, UL, MSDS certificates.
5. Quick action&response,every inquires will be relied within 24 hours.

SHENZHEN BATTERYBUILDING INDUSTRY Co., Limited is a profestional hi-tech industry company. We are specialized in different kinds of lithium batteries and engaged in the related products, include Lithium batteries, LiFePO4 batteries, BMS/PCM/CMB, RC/Lipo Batteries, and related battery chargers.

Various lithium battery cells models are provided, and can be customized the battery packs according to customers' Detailed requirements and applications. With a wide range, good quality, reasonable prices and stylish designs, our products are widely used in E-bikes, backup power, laptop, electrical toys, helicopter models, electrical cars, power tools and so on.

Our products are exported to all over the world, like Europe, USA, Canada etc. Our company focuses on the development of battery quality with our own research centre and technical team in battery developing, quality controlling and producing. Our aim is "to keep improving new product technology, to take Environment Protection as our responsibility; To provide customers with excellent service and technical support; To make our products much more environment-friendly and safer. "

If you hany any inquiry and question, please just contact us.

We are looking forward to establishing relationships with you in the near future.
