Product Description
- Double circuit type of limit switch
- Highly rigid construction, consists of intensive plastic and zinccast (Head and cover snugly fit in box)
- Small volume, water-proof and oil-proof construction
- Built-in basic switch with double spring mechanism, longer mechanical life
- Smooth operation with greater OT
- Easy-to-wire circuit opening design
- Wide variety of actuators, easily use
Product characteristics
| Model No. | TZ-8108 |
| Name | Limit switch |
| Operation speed | 0.5mm-50cm/sec |
| Operating frequency | Mechanical: 120 operations/minute, Electrical: 30 operations/minute |
| Contact resistance | 25mΩ max.(initial value) |
| Insulation resistance | 100mΩ min.(at 500VDC) |
Dielectric strength | 1000VAC,50/60HZ for 1 minute between terminals of the same polarity |
1500VAC,50/60 HZ for 1 minute between currentcarrying and non-current carrying metal parts |
| 1500VAC,50/60 HZ for 1 minute between each terminal and ground |
| Vibration | 10-55HZ,1.5mm double amplitude |
Shock | Mechanical durable:1000m/Sec2;Malfunction:300m/Sec2(about 30G'S) |
| Life | Mechanical: 10,000,000 operations above;Electrical: 500,000 operations above |
| Weight | About 130-190g |
| Degree of protection | IP65 |
| Payment term | 30% deposit in advance,70% before shipment,100% T/T in advance |
| Certificate | TUV, CCC,CE,ISO9001 |
| Logo | Customized logo with Decal / Frosted / Print are available as request |
Design ability | We can supply sample,OEM&ODM is welcome (Design,Engineering, Photographing,Sample, Production)
|
Rating
Rated Voltage | Noninductive Load (A) | Inductive Load (A) |
Resistance Load | Lamp Load | Inductive Load | Motor Load |
NC | NO | NC | NO | NC | NO | NC | NO |
125VAC 250VAC 500VAC | 5 5 | 5 5 | 1.5 1 | 0.7 0.5 | 3 3 | 3 3 | 2 1.5 | 1 0.8 |
8VDC 14VDC 30VDC 125VDC 250VDC | 5 5 5 0.4 0.2 | 5 5 5 0.4 0.2 | 3 3 3 | 3 3 3 | 5 4 4 | 4 4 4 | 3 3 3 | 3 3 3 |
Inrush Current | N.C: below 24A, N.O: below 12A |
| Pertection degree | IP65 |
| Operating temperature | -20'C~60'C |
| Operating humidity | ≤ 85% |
Outline And Installation Dimension | OF Max | 1000g(9.8N) |
| RF Min | -- |
| PT Max | 30mm |
| OT Min | -- |
| MD Max | -- |
| TT | -- |
