0.6/1kv Copper or Aluminum Conductor 4 Core 185mm2 Armoured Power Cable

Name: 0.6/1kv Copper or Aluminum Conductor 4 Core 185mm2 Armoured Power Cable
Brand: all-electronics-online.com
SKU: 711226652
Availability: InStock
Rating: 4.6 (70 reviews)

Price:	US $ 2-100/Meter
Min Order:	1000/Meter
Pay Type:	L/C,T/T,Western Union,Money Gram

Contact Supplier

Showroom Product Company Profile

Prod Model:	LV-BE55
Application:	Underground
Current:	AC Cable
Certification:	CE
Voltage:	0.6/1kv
Insulation Material:	XLPE PVC
Wire Core Material:	Aluminum or Copper
Model:	Yjv Yjlv Yjv22 Yjlv22 Yjv32 Yjlv32
Brand:	Yifang

Product Description

AL CU XLPE PVC Insualtion Armoured Non-armoured 1 core 2core 3core 3+1core 4core 5 core 0.6/1kv Power Cable

1.Manufactured according to the shandard of IEC,BS,DIN or ICEA upon requst.

2.Suitable for use in power transmission and distribution lines with rated power frequency voltage 0.6/1kV.

3.The ambient temperature for installation: ≥0°C

4.Maximun conductor temperature in normal operation:≤90°C

5.Max operating temperature of conductor when cable short-circuited(5s maximun duration): 250°C

6.Permissible bending radius:

Single cable: [20(D+d)±5%]mm

Multi cable: [15(D+d)±5%]mm

Type		Description	Main Application
Cu core	Al core	Description	Main Application
(ZR)YJV or (ZR)YJY	(ZR)YJLV or (ZR)YJLY23	(Flame retardant) Cu, Al core XLPE insulated, PVC or PE sheathed power cable.	For laying indoor, tunnel, underground and canal. Unable to bear external mechanical pulling force and pressure during laid.
(ZR)YJV22 or (ZR)YJY23	(ZR)YJLV22 or (ZR)YJLV23	(Flame retardant) Cu, Al core XLPE insulated, steel armoured, PVC or PE sheathed power cable.	For laying indoor, tunnel, underground and canal. Able to bear external mechanical pulling force , but unable to bear large pulling force.
(ZR)YJLV32 or (ZR)YJLV33	(ZR)YJLV32 or (ZR)YJLV33	(Flame retardant) Cu, Al core XLPE insulated, fine steel wire armoured, PVC or PE sheathed power cable	For laying in shaft, water under ground and large difference of level, able to bear mechanical pressure and moderate pulling force.
(ZR)YJLV42 or (ZR)YJLV43	(ZR)YJLV42 or (ZR)YJLV43	(Flame retardant) Cu, Al core XLPE insulated, thick steel wire armoured, PVC or PE sheathed power cable	For laying in the water, seabed and large difference of level, able to bear large mechanical pressure and pulling force.

7. Suitable for under ground,can bear mechanical stress.

8. Products Parameter (structure, weight and current rating)

Type	Dia. of conductor	XLPE insulation thickness	Inner sheath thickness	Steel tape thickness	PVC jacket thickness	Approx. dia. of cable	Approx. weight of cable	Current rating of cable
mm²	mm	mm	mm	mm	mm	mm	kg/km	in the air	under ground
4*4	2.25	0.7	1.2	0.2	1.8	16	402	28	35
4*6	2.76	0.7	1.2	0.2	1.8	17	488	37	46
4*10	4.05	0.7	1.2	0.2	1.8	21	688	47	56
4*16	5.10	0.7	1.2	0.2	1.8	23	927	64	76
4*25	6.00	0.9	1.2	0.2	1.8	27	1367	84	98
4*35	7.00	0.9	1.2	0.2	1.8	30	1558	115	126
4*50	6.81	1.0	1.2	0.5	1.9	33	2163	141	152
4*70	8.23	1.1	1.2	0.5	2.1	36	2485	172	181
4*95	9.71	1.1	1.2	0.5	2.2	41	2813	218	222
4*120	10.95	1.2	1.3	0.5	2.4	44	2945	269	267
4*150	12.16	1.4	1.4	0.5	2.5	49	3533	313	305
4*185	13.61	1.6	1.5	0.5	2.7	54	4236	359	344
4*240	15.65	1.7	1.6	0.5	3.0	60	5625	405	383
4*300	17.53	1.8	1.7	0.5	3.1	66	6286	451	422

Zhengzhou Yifang Cable Co., Ltd is a large joint-stock\hi-tech enterprise established in 1988. We are specialized in wires & cables, including designment, production and sales.

There are more than 500 staffs in our factory including over 50 technical personnel, 5 senior engineers. With complete advanced cable producing equipments over 150 sets, complete testing equipments, a national level fire-resistant & flame retardant cable laboratory. Our technology has reached advanced levels at home and abroad.

Our main products include: Power Cable for voltage up to 220KV, Overhead insulated cable, ABC Cable, Building Cable and flexible cord, Control Cable, Rubber Cable, Bare Conductor(ACSR, AAC, AAAC, BCC), Welding Cable, Galvanized Steel Wire(Stay wire), flame retardant mining cable, etc

We have own IM/EX right, our products have been exported to Europe, Australian, Middle-east, South-east Asia, Africa, American, South American etc., being subjected to consistent good opinion of customers.
