| Prod Model: |
VVG VVGng |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Color: |
Red, Yellow,Green, Black |
| Certificate: |
CE, ISO 9001 |
| Popular Size: |
4X35mm, 4X50mm, 4X70mm |
| Key Word: |
Vvg |
| Key Word 2: |
Vvgng |
| Key Word 3: |
Vvg Cable |
| Key Word 4: |
Vvgng Cable |
| Application: |
Power Station |
| Voltage: |
Low and Medium Voltage Cable |
| Current: |
DC Cable |
| Insulation Material: |
PVC |
| Certification: |
CE |
| Model: |
Vvg Vvgng |
| Brand: |
Jytop |
Product Description
Company Description
1. CE, ISO 9001 Certificaes
2. More than 23 years experiences
3. Professional Manufacturer for VVG Cable,VVGNG cable,with Factory located in Henan Province.
4. Quick response and fast delivery.
5. Serve everyone with heart and soul.
0.6/1kV VVG VVGng CABLE Copper cable, PVC Jacket Power Cable 1. Operating Characteristics
Rated voltage: 0.6/1(1.2)kV
Max. Permissible continuous operating temperature of conductor: 70° C
Max. Temperature of conductor during short-circuit (5s max. Duration) shall not exceed:
Nominal cross section of conductor ≤ 300mm2: 160° C;
Nominal cross section of conductor >300mm2: 140° C
The ambient temperature under installation should not be lower than: 0 ° C
The bending radius of cable is recommended as following:
For single core cable: Not less than 20 times of the diameter of cable
For multi-core cable: Not less than 15 times of the diameter of cable
2. Application
The cable is used for fixed installations such as electric power distribution networks or industrial installations, which is laid indoors, in tunnel, in cable trench or in conduit, unable to bear external mechanical force.
3. Manufacturing Standards
IEC 60502-1 & Chinese national standard GB/T 12706-2008 We can produce above cables according to popular international standards such as ASTM, BS, DIN, NF &AS/NZ also. Main technical data of 0.6/1KV, four cores, Copper conductor, PVC insulated and PVC or PE sheath cablesCABLE CONSTRUCTION: 0.6/1KV CU/PVC/PVC or PE
Cable size |
Conductor type | Nominal
thickness of PVC
insulation(mm) | Nominal
thickness of PVC
sheath(mm) | Approx. cable
overall diameter
(mm) | Max. D.C resistance
@ 200C (Ω/km) |
| 4x1.5mm2 | RE or RM | 0.8 | 1.8 | 11.0 | 12.1 |
| 4x2.5mm2 | RE or RM | 0.8 | 1.8 | 11.9 | 7.41 |
| 4x4mm2 | RE or RM | 1.0 | 1.8 | 14.0 | 4.61 |
| 4x6mm2 | RE or RM | 1.0 | 1.8 | 15.3 | 3.08 |
| 4x10mm2 | RM | 1.0 | 1.8 | 18.4 | 1.83 |
| 4x16mm2 | RM | 1.0 | 1.8 | 20.9 | 1.15 |
| 4x25mm2 | SM | 1.2 | 1.8 | 21.9 | 0.727 |
| 4x35mm2 | SM | 1.2 | 1.8 | 24.1 | 0.524 |
| 4x50mm2 | SM | 1.4 | 1.9 | 27.6 | 0.387 |
| 4x70mm2 | SM | 1.4 | 2.1 | 31.4 | 0.268 |
| 4x95mm2 | SM | 1.6 | 2.2 | 36.1 | 0.193 |
| 4x120mm2 | SM | 1.6 | 2.3 | 39.3 | 0.153 |
| 4x150mm2 | SM | 1.8 | 2.5 | 43.5 | 0.124 |
| 4x185mm2 | SM | 2.0 | 2.7 | 48.4 | 0.0991 |
| 4x240mm2 | SM | 2.2 | 2.9 | 54.6 | 0.0754 |
| 4x300mm2 | SM | 2.4 | 3.1 | 60.4 | 0.0601 |
Why Choose us?
For over 20 years, Zhengzhou Jinyuan Wire and Cable Co., Ltd., as a professional cable manufacturer has been producing customized cable for a wide range of applications based on high quality, excellent service and competitive market prices. This is an elite team with experienced personnel and strong technical support. Our achievements benefit by having access to the largest market for cheap labor and abundant resources in China and our determination to exceed our clients' expectations.
PRODUCTS & STANDARDS
We can produce all kinds of cables and wires, such as
Bare Conductor: AAC, AAAC, ACSR, ACSR/AW, ACAR, ACSS, ACSS/AW, Aluminum Clad Steel Wire/Strand, Bare Copper Conductors, Copper Clad Steel Wire/Strand, Copper Clad Aluminum(CCA), Galvanized Steel Wire/Strand, etc.
Overhead Insulated Cable: Covered Line Single Core Cable and Aerial Bundled Cable (ABC). ABC includes Duplex, Triplex, Quadruplex and more Cores Service Drop Cable.
PVC Insulated Wire up to 450/750V
PVC or XLPE Insulated Power Cable from 1kV to 36kV
Control Cable
Welding Cable
Rubber Cable
We can produce cables according to the standards of IEC, ASTM, EN (BS, DIN, NF, etc.), AS/NZ and meet customers' special requirements.
ACHIEVEMENTS & COMMITMENT
Our cable has been exported to South-East Asia, South Asia, Middle-East, Europe, North and South America, Africa, Australia & New Zealand and so on. Zhengzhou Jinyuan Wire and Cable Co., Ltd.'s commitment is to be recognized as a zero-defect world class manufacturer in cable industry through continuous improvement of our quality, processes, and products, and by our determination to exceed our clients' expectations.
Welcome to contact us for more information about the VVG cable VVGNG Cable or other cables.
