| Prod Model: |
Halogen-free and low-smoke Cables |
| Standard: |
IEC 60502-1 |
| Rated Voltage: |
600/1000 Volts |
| Armored: |
Steel Tape Armor |
| Suitable For: |
Public |
| Application: |
Power Plants |
| Voltage: |
Low and Medium Voltage Cable |
| Current: |
DC Cable |
| Insulation Material: |
XLPE |
| Certification: |
SGS |
| Model: |
U-1000 RO2V, Ar2V |
| Brand: |
Hongda |
Product Description
600 Volts Halogen-free and low-smoke Notox XCS CS LS0H Cables
Cable - Construction  |
Cover Notox (LSOH)
XLPE insulation
Copper Conductor |
Manufacturing Standard
NCh-2014/1. Of 2002;
IEC 60502-1;
NCh-2740. Of 2002;
ICEA S-95-658;
NCh-2741. Of 2002;
IEC 60332.
characteristics
Operating voltage: 0.6 / 1 KV.
Operating temperature: 90 ºC.
Halogen-free and low-smoke compounds (LS0H) NOTOX.
Driver Description
Single-conductor power cables, from 1.5 mm2 to 500 mm2 section and from 16 AWG to 1000 MCM gauges.
Building
Conductor: Soft tempered electrolytic copper.
Insulation: Halogen-free and low-smoke-free compound (LS0H) NOTOX.
Office
Single-conductor power cables: Section 1.5 mm2 to 10 mm2, in rolls.
Section greater than 10 mm2, on reels.
Marking:
Printed on the cover, with the following characteristics: Henan Hongda cable Co., Ltd Cu/XLPE/LSOH, Cable, 0.6 / 1 KV.
Applications
In places where there is a large influx of public, such as hospitals, airports, railways, underground mines, marine platforms, ships, power plants, etc.
Low Voltage Power Cable (0.6/1 kV)XLPE insulated, copper conductor, PVC / LSOH outer sheath cable
Electrical and mechanical characteristics
| | construction | THICKNESS | Approx. Cable Diameter
mm | Approximate Weight
kg/km |
SECTION
mm2 | Number of Conductor wire | Wire diameter | Insulation
mm | Sheath
mm |
| 1,5 | 7 | 0,5 | 0,7 | 1,4 | 5,7 | 46 |
| 2,5 | 0,67 | 6,5 | 61 |
| 4 | 0,85 | 6,9 | 79 |
| 6 | 1,04 | 7,5 | 57 |
| 10 | 1,35 | 8,5 | 149 |
| 16 | 1,7 | 9,5 | 210 |
| 25 | 2,14 | 0,9 | 11 | 320 |
| 35 | 2,52 | 12,5 | 425 |
| 50 | 1,83 | 1 | 14 | 585 |
| 70 | 19 | 2,14 | 1,1 | 1,5 | 15,9 | 795 |
| 95 | 2,52 | 1,6 | 17,8 | 1.050 |
| 120 | 2,03 | 1,2 | 20 | 1.315 |
| 150 | 37 | 2,25 | 1,4 | 1,7 | 22,1 | 1.628 |
| 185 | 2,52 | 1,6 | 1,8 | 24 | 1.987 |
| 240 | 61 | 2,24 | 1,7 | 1,9 | 28,1 | 2.565 |
