Fatech Electronic (Foshan) Co., Ltd. >> 600VDC Surge Arrester Type PV SPD Surge Protector

600VDC Surge Arrester Type PV SPD Surge Protector

600VDC Surge Arrester Type PV SPD Surge Protector
Price: Negotiable/Piece
Trade Terms: FOB,CFR,EXW
Min Order: 1/Piece
Pay Type: L/C,T/T,D/P,Western Union,Paypal
Contact Supplier
Showroom Product Company Profile
Prod Model: FV20C/3-600 PV S
Markets: North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Imax: 40ka
In: 20ka
Ta: ≤ 25ns
Up: 3.6
Uc: 600VDC
Color: Grey
Brand: Fatech

Product Description


1. Product Description

FV20C/3-600 PVS is used for photovoltaic (PV) solar panel system protection.

Surge arrester for photovoltaic system 600Vdc, common & differental mode.
1.The core parts are metal oxide vristor components with high discharge capacity.
2.With Reliable control thanks to Thermo Dynamic Control disconnector.
3.With remote signaling contact for control device.
4.Fault indication via red mark in the inspection window.


 2. Specification of surge arrester FV20C/3-600PVS:

odel No.: FV20C/3-600 PV
Max.continuous DC voltage[(L+/L-)->PE]/ [L+->L-]Uc pvV600
Requirement class to DIN EN 61643-1:2005Class C
Nominal Discharge current(8/20μs)InkA20
Max. discharge current (8/20μs)ImaxkA40
Voltage protection level (at In) [(L+/L-)->PE]/ [L+->L-]UpkV≤3.6
Response timetAns<25
Operation temperature range  -40ºC~+85ºC
Degree of protectionIP20
Remote control contacts  Without

3. Company Information

FATECH ELECTRONIC CO., LTD., is located in Guangdong Provincial New Light Production Base, CHINA, which is a professional manufacturer on R&D and producing on lightning and surge protection devices. Our company gathered all kinds of high-skillled personnels, including authority technical experts and professionals, and excellent technicians with more than 10 years experience.


Our main products:
Surge arresters for protection of photovoltaic system ,
Surge protection devices for protection of power supply systems,
SPD surge protectors for protection of signal system,
Lighting rod,
Test devices.
Wide range of lighting & surge protection products assured you a one stop shopping location for all your need and professional technical support.


Our global partners:
We are now exporting more than 100 countries and areas, mainly in Europe, Asia, Latin-America, and Middle East. Our global partner including Ericsson, Sri Lanka Telecom, Telefonica-Movie and so on.
FATECH ELECTRONIC Co., Ltd., is located in Guangdong Provincial New Light Production Base, China, which is a professional manufacturer on R&D and producing on lightning and surge protection devices. Our company gathered all kinds of high-skillled personnels, including authority technical experts and professionals, and excellent technicians with more than 10 years experience.

1. Our main products:

-Surge arresters for protection of photovoltaic system,

-Surge protection devices for protection of power supply systems,

-SPD surge protectors for protection of signal system,

-Lighting rod & lightning counters,

-Test devices.

Wide range of lighting & surge protection products assured you a one stop shopping location for all your need and professional technical support.

2. Our global partners:

We are now exporting more than 100 countries and areas, mainly in Europe, Asia, Latin-America, and Middle East. Our global partner including Ericsson, Sri Lanka Telecom, Telefonica-Movie and so on.

3. Our in-house test lab.:

We established an independent testing laboratory, including reliability testing laboratory, environmental aging testing laboratory, release testing laboratory, which can be performed tests below:

-Impulse current generator (8/20 μ S/160kA and 10/350μ S/25kA)

-Thermal stability tester

-Salt Spray Chamber

-Multi-function Varistor Tester

-On-line Aging Tester

-Dielectric Voltage Withstand Tester

-1.2/50 Voltage Impulse Generator

-Environment Stimulating Tester

-Lightning Surge Counter Tester

We are looking forward to cooperate with more customers worldwide, and warmly welcome your visit and audit our factory.
