60W 90mm AC Induction Gear Motor

Name: 60W 90mm AC Induction Gear Motor
Brand: all-electronics-online.com
SKU: 743460685
Availability: InStock
Rating: 4.4 (94 reviews)

Price:	US $ 11.3-15.7/Piece
Trade Terms:	FOB,CIF,DAP
Min Order:	1/Piece
Pay Type:	T/T,Paypal

Contact Supplier

Showroom Product Company Profile

Prod Model:	5IK60GN-AF (5IK60A-AF)
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Motor Size:	60/70/80/90/100mm
Power:	10/15/20/25/40/60/90/120/140/180W
All Technical Data:	Can Be Customized
Function:	Driving
Number Of Stator:	Single-Phase
Brand:	GS
Certification:	UL, RoHS, CE, SGS

Product Description

60W 90mm ac induction motor

Specifications
1. Dimensions of device: 90mm
2. Rated Power: 60W
3. Voltage: 110V / 120V / 220V / 230V
4. Rated Speed: 1250RPM / 1550 RPM
5. Rated Torque: 380mN. M / 470 mN. M

FOR OTHER MODEL:

Size: 60 / 70 / 80 / 90 / 100mm
Power: 10 / 15 / 20 / 25 / 40 / 60 / 90 / 120 / 140 / 180W
Voltage: 1ph100 / 1ph110 / 1ph120 / 1ph220 / 1ph230 / 3ph220 (50/60Hz)
Gear Ratio: 3/ 3.6/ 5/ 6/ 7.5/ 9/ 12.5/ 15/ 18/ 25/ 30/ 36/ 50/ 60/ 75/ 90/ 100/ 120/ 140/ 180/ 200

Note: Motor voltage, power and speed will be customized according to your request under the allowed circumstance of adoptable dimension.

If you have any other questions, please feel free to contact us.

Model		Output power W	Voltage V	Frequency Hz	Current A	Starting Torque mN.m	Rated Torque mN.m	Rated Speed r/min	Capacitor μF
Lead Wire Type	Terminal Box Type
5IK60GN-AF (5IK60A-AF)	5IK60GN-AFT (5IK60A-AFT)	60	1ph100	50	1.00	320	470	1250	20.0
				60	1.10		380	1550
5IK60GN-EF (5IK60A-EF)	5IK60GN-EFT (5IK60A-EFT)	60	1ph110	60	0.80	300	380	1550	12.0
			1ph120		0.85
5IK60GN-CF (5IK60A-CF)	5IK60GN-CFT (5IK60A-CFT)	60	1ph220	50	0.50	340	470	1250	4.0
			1ph230		0.55
5IK60GN-HF (5IK60A-HF)	5IK60GN-HFT (5IK60A-HFT)	60	1ph220	60	0.50	340	380	1550
			1ph230		0.55
5IK60A-SF (5IK60A-SF)	5IK60G-SFT (5IK60A-SFT)	60	3ph220	50	0.45	1000	470	1250	_
				60	0.40	800	380	1550
