63 AMP Circuit Breaker, 3 Phase Circuit Breaker

Name: 63 AMP Circuit Breaker, 3 Phase Circuit Breaker
Brand: all-electronics-online.com
SKU: 781884905
Availability: InStock
Rating: 4.5 (130 reviews)

Price:	Negotiable/Piece
Trade Terms:	FOB,CIF,others
Min Order:	100/Piece
Pay Type:	L/C,T/T

Contact Supplier

Showroom Product Company Profile

Prod Model:	NS
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Rated Current:	12.5A to 630A
Rated Circuit:	AC 690V 50/60Hz
Rated Insulation Voltage:	690V
Standards:	IEC60947-2
Breaking Capacity:	High Voltage Circuit Breakers
Operation:	Electric Type
Speed:	High-Speed Circuit Breaker
Arc-extinguishing Medium:	Air
Installation:	Fixed
Structure:	MCCB
Certification:	CE
Poles Number:	3,4

Product Description

Application
NS moulded case circuit breaker is one of the most advanced type breakers in the world, which adopts international advanced design and manufacture technology. They are suitable for short circuit and overload protection for circuit of AC 690V 50/60Hz, rated current from 12.5A to 630A. Its rated insulation voltage is 690V. It can make and break the non-frequently circuit in the normal conditions. It takes protect effect when mouse cage motors non-frequent start, breaking off working and protecting overload, short circuit and lacking voltage. It complies with IEC60947-2.

Type	Rated current (A)	Poles	Rated insulation voltage (V)	Rated operating voltage (V)	Arcing over distance (mm)	Ultimate short circuit breaking capacity	Servies short circuit breaking capacity	Operating performance (times)
								ON		OFF
NS-100D	12.5,16,20, 25,32,40, 50,63,80,100	3,4	950	690	0	18	18	1500	8500
NS-100N						25	25
NS-100H						70	70
NS-160D	16,20,25, 32,40,50,63, 80,100,125, 160					25	25	1500	7000
NS-160N						36	36
NS-160H						70	70
NS-250D	160,180,200, 225,250					25	25	1000	7000
NS-250N						36	36
NS-250H						70	70
NS-400D	200,225,250, 300,315,400					35	35	1000	4000
NS-400N						45	45
NS-400H						70	70
NS-630D	315,350, 400,500,600, 630					35	35	1000	4000
NS-630N						45	45
NS-630H						70	70
