| Prod Model: |
12V5Ah |
| Color: |
Grey or Black |
| Terminal: |
F1/F2 |
| Certificate: |
Ce/UL/ISO9001/ISO14001/Ohsas18001 |
| Weight: |
17.1kg |
| Material: |
1# Lead,Purity up to 99.994% |
| Container: |
ABS Plastic |
| Type: |
Lead-Acid Batteries |
| Usage: |
Electric Bicycle |
| Nominal Voltage: |
12V |
| Discharge Rate: |
Low Discharge Rate |
| Shape: |
Square Battery |
| Rechargeable: |
Chargeable |
Product Description
LONGWAY standard series valve regulated lead acid batteries are designed with AGM(Absorbent Glass Mat) technology and for general application purpose, such as UPS, telecom, and electrical utilities with 5 years design life, the batteries comply to the most popular international standards, such as IEC60896-21/22, BS6290-4, Eurobat Guide. The battery container and cover are available both in VO class flame retardant ABS or HBO ABS plastics.
1)Detail description
Model: 6FM55G (12V55AH/20HR)
Size: 229*138*208(total height: 216) mm
Terminal: NB
Packing Qty: 1 PCS/CTN
1, 150 PCS/Container
Weight(kg): 17.5
Terminal: B
Lead-time: 20 days for one container
OEM acceptable
2)Applications
Alarm systems, Cable television, communications equipment, control equipment,
Computers, electronic cash registers, electric test equipment,
Electric powered bicycle and wheel chair,
Emergency lighting systems, fire&security, geophysical equipment,
Marine equipment, medical equipment,
Micro processor based office machines, portable cine&video lights,
Power tools, solar powered systems,
Telecommunications systems, television&video recorders, toys,
Uninterruptible power supplies, vending machines;
General Features
Stable quality&high reliability
Sealed construction
Environmentally friendly
Maintenance-free operation
Low pressure venting system
Heavy duty grid
Low self discharge
UL component recognition(MH46789)
Excellent quality and reasonable price, welcome to contact us.
| Standby Part of LONGWAY 12Volt battery series |
| Battery Model | Internal model | Nominal Voltage (V) | Nominal Capacity (AH) 20HR | Length | Width | Height | Total Height | Weight(±3%) | Terminal |
| In | mm | In | mm | In | mm | In | mm | lbs | Kg | Type | Position |
| 6FM50G | LW12-50 | 12 | 50 | 9.02 | 229 | 5.43 | 138 | 8.19 | 208 | 8.39 | 213 | 37.04 | 16.80 | F20 | C |
| 6FM55A/G | LW12-55A | 12 | 55 | 9.02 | 229 | 5.43 | 138 | 8.19 | 208 | 8.39 | 213 | 37.92 | 17.20 | F20 | C |
| 6FM55B/G | LW12-55B | 12 | 55 | 9.02 | 229 | 5.43 | 138 | 8.19 | 208 | 8.39 | 213 | 37.92 | 17.20 | F9 | C |
| 6FM60G | LW12-60 | 12 | 60 | 13.78 | 350 | 6.54 | 166 | 6.89 | 175 | 7.05 | 179 | 44.09 | 20.00 | F16 | D |
| 6FM60A | LW12-60A | 12 | 60 | 9.84 | 250 | 6.30 | 160 | 7.01 | 178 | 7.20 | 183 | 38.14 | 17.30 | F9 | D |
| 6FM65A/G | LW12-65 | 12 | 65 | 13.78 | 350 | 6.54 | 166 | 6.89 | 175 | 6.89 | 175 | 46.30 | 21.00 | F16 | D |
| 6FM65B/G | LW12-65B | 12 | 65 | 13.78 | 350 | 6.61 | 168 | 7.09 | 180 | 7.09 | 180 | 46.30 | 21.00 | F9 | D |
| 6FM70A/G | LW12-70 | 12 | 70 | 10.20 | 259 | 6.65 | 169 | 8.31 | 211 | 9.09 | 231 | 46.96 | 21.30 | F20 | C |
| 6FM70B/G | LW12-70 | 12 | 70 | 10.20 | 259 | 6.65 | 169 | 8.31 | 211 | 8.50 | 216 | 46.96 | 21.30 | F10 | C |
| 6FM80A/G | LW12-80 | 12 | 80 | 12.09 | 307 | 6.57 | 167 | 8.27 | 210 | 8.46 | 215 | 55.12 | 25.00 | F10 | C |
| 6FM80B/G | LW12-80A | 12 | 70 | 10.20 | 259 | 6.65 | 169 | 8.19 | 208 | 8.39 | 213 | 47.40 | 21.50 | F10 | C |
| 6FM80E | LW12-80E | 12 | 80 | 12.52 | 318 | 7.13 | 181 | 6.57 | 167 | 6.77 | 172 | 49.60 | 22.50 | F9 | D |
| 6FM90 | LW12-90 | 12 | 90 | 12.09 | 307 | 6.57 | 167 | 8.19 | 208 | 8.39 | 213 | 58.42 | 26.50 | F10 | C |
| 6FM95 | LW12-95 | 12 | 95 | 12.09 | 307 | 6.57 | 167 | 8.19 | 208 | 8.39 | 213 | 59.52 | 27.00 | F10 | C |
| 6FM100A | LW12-100A | 12 | 100 | 12.99 | 330 | 6.81 | 173 | 8.62 | 219 | 8.82 | 224 | 65.04 | 29.50 | F12 | C |
| 6FM100B | LW12-100B | 12 | 100 | 12.99 | 330 | 6.81 | 173 | 8.62 | 219 | 8.82 | 224 | 67.24 | 30.50 | F12 | C |
| 6FM100C | LW12-100C | 12 | 100 | 13.03 | 331 | 6.81 | 173 | 8.62 | 219 | 9.45 | 240 | 65.04 | 29.50 | F22 | C |
| 6FM100D | LW12-100D | 12 | 100 | 15.94 | 405 | 6.81 | 173 | 8.27 | 210 | 9.33 | 237 | 70.55 | 32.00 | F17 | C |
| 6FM120 | LW12-120 | 12 | 120 | 15.94 | 405 | 6.81 | 173 | 8.27 | 210 | 9.33 | 237 | 77.16 | 35.00 | F17 | C |
| 6FM120A | LW12-120A | 12 | 120 | 15.94 | 405 | 6.81 | 173 | 8.27 | 210 | 9.33 | 237 | 76.06 | 34.50 | F17 | C |
| 6FM120B | LW12-120B | 12 | 120 | 12.99 | 330 | 6.81 | 173 | 8.62 | 219 | 8.82 | 224 | 68.34 | 31.00 | F12 | C |
| 6FM120C | LW12-120C | 12 | 120 | 12.99 | 330 | 6.81 | 173 | 8.62 | 219 | 8.82 | 224 | 70.55 | 32.00 | F12 | C |
| 6FM140 | LW12-140 | 12 | 140 | 13.43 | 341 | 6.81 | 173 | 11.14 | 283 | 11.34 | 288 | 91.49 | 41.50 | F12 | C |
| 6FM150 | LW12-150 | 12 | 150 | 19.02 | 483 | 6.69 | 170 | 9.49 | 241 | 9.49 | 241 | 98.11 | 44.50 | F18 | C |
| 6FM160 | LW12-160 | 12 | 160 | 13.43 | 341 | 6.81 | 173 | 11.14 | 283 | 11.34 | 288 | 99.21 | 45.00 | F12 | C |
| 6FM160A | LW12-160A | 12 | 160 | 13.43 | 341 | 6.81 | 173 | 11.14 | 283 | 11.14 | 283 | 99.21 | 45.00 | F11 | C |
| 6FM160B | LW12-160B | 12 | 160 | 20.94 | 532 | 8.15 | 207 | 8.46 | 215 | 9.45 | 240 | 111.66 | 50.65 | F24 | E |
| 6FM180 | LW12-180 | 12 | 180 | 20.55 | 522 | 9.45 | 240 | 8.62 | 219 | 8.82 | 224 | 127.87 | 58.00 | F19 | E |
| 6FM200 | LW12-200 | 12 | 200 | 20.55 | 522 | 9.45 | 240 | 8.62 | 219 | 8.82 | 224 | 127.87 | 58.00 | F19 | E |
| 6FM230 | LW12-230 | 12 | 230 | 20.51 | 521 | 10.59 | 269 | 7.99 | 203 | 8.19 | 208 | 143.30 | 65.00 | F24 | F |
| 6FM250 | LW12-250 | 12 | 250 | 20.47 | 520 | 10.59 | 269 | 8.66 | 220 | 9.65 | 245 | 154.32 | 70.00 | F25 | E |
| 9FM7 | LW18-7 | 18 | 7 | 5.94 | 151 | 3.98 | 101 | 3.98 | 101 | 3.98 | 101 | 8.75 | 3.97 | W | D |
Kaiying Power Supply & Electrical Equip Co., Ltd., established in 2001, is a professional valve regulated sealed lead acid battery manufacturer in China. We have a lot of experience in producing high quality products. There is a group of engineers to develop batteries as our clients required.
As the environmental readjusted, Zhangshan Long Way Battery Manufacturing Co., Ltd couldn't produce SLA batteries anymore. The technology and IQC management of Zhangshan Long Way Battery Manufacturing Co., Ltd which had merged with KAIYING GROUP, the Logo LONGWAY is also transferred to the KAIYING GROUP.
Kaiying Power Supply & Electrical Equip Co., Ltd., with a 10, 000 M² Factory space, the company has over 1000 employees and advanced development equipment and comprehensive test facilities. Attaching great importance to quality, our management comply with ISO9001-2000 standard. Our batteries have UL and CE approvals.
During the past several years, the company has gained a very high reputation in the industry with excellent development, production, sales capability and premium quality. So, we got very good market share both in the domestic and foreign markets in the past. OEM orders acceptable.
