6kw/48V DC Power Home Pure Sine Wave Inverter

Name: 6kw/48V DC Power Home Pure Sine Wave Inverter
Brand: all-electronics-online.com
SKU: 714848292
Availability: InStock
Rating: 4.7 (21 reviews)

Price:	US $ 256/Piece
Min Order:	10/Piece
Pay Type:	L/C,T/T,D/P,Western Union,Paypal

Contact Supplier

Showroom Product Company Profile

Output Wave Form:	Pure Sine Wave
Input Voltage:	155-265VAC
Application:	Home Application
Max Charge Current:	Max 70AMP
Transformer:	Pure Copper
Charge Current Adjustable:	25%, 50%, 75%, 100%
Phase:	Single
Power Source:	Electric Power

Product Description

6kw/48V DC Power Home Pure Sine Wave Inverter
Main features:

1.Pure sinewave output,can be used withdifferent domestic appliance like TV, refrogerator ,fan,air conditioner.cooker,mirco-wave oven,etc.

2.Superior performance from CPU control technology.

3.Wide range of input voltage,accruate output,AVR function.

4.Inner-equipped protection for over-load,short-circuit,over-voltage,low-voltage,over-heating,etc.

5.Easy to check with inverter with consice LED indication that can be upgrade to LCD.

6. Generator compatibly and external battery connection achievable.

7.Intelligent battery management with protection against over-charged and over-discharged etc.

Typical Application:

Main for home and office Appliance,TV,refrigerator,fan,air conditioner,induction cooker,computer etc.

MODEL		115V Models	230V Models
OUTPUT
Power Levels crated at nominal inputs		1KW;2KW;3KW;4KW	1KW;2KW;3KW;4KW;5KW;6KW
Output Voltage		110V/115V/120V Selectable	220V/230V/240V Selectable
Voltage Waveform		Pure Sine wave
Crest Factor		3:'1
Output Frequency		Auto Select for 50/60Hz,47Hz ~55Hz for 50Hz nominal,56Hz ~ 65Hz for 60Hz nominal
(Synchronized to Mains)
Regulation (Nominal)		±20% typical of nominal voltage
Regulation		±3% of selected output voltage
(Battery mode)
INPUT
Nominal Voltage		110V/115V/120V Selectable	220V/230V/240V Selectable
Input Frequency		47Hz ~ 65Hz, 50/60Hz auto-sensing
Efficiency (Normal mode)		99%
Noise Filtering		Full time EMI/RFI filtering
Voltage Range		85V ~ 145V	155V ~ 265V
SOLAR CHARGER
Rating voltage		12V / 24V / 48V	12V / 24V / 48V
DC input range		12V model : 12 ~ 21Vdc;24V model : 24 ~ 42Vdc;48V model : 48 ~ 84Vdc
Charging method		Constant voltage with current limiting by PWM control
Charging voltage		12V model:13.5Vdc;24V model: 27.0Vdc;48V model: 54.0Vdc
Protection		DC input polarity protection, DC input short circuit protection( when battery is
		connected), DC output over current protection
PHYSICAL
Appearance	Size(mm)LxWxH	442218179
	Weight(Kg)	1000W/18kg ;2000W/19.5kg ;3000W/23.5kg
	Size(mm)LxWxH	630219179
	Weight(Kg)	4000W/35kg ;5000W/38kg ;6000W/40kg

Shenzhen Must Power Limited established in 2010, with the headquarter in Hongkong, which is a professional hi-tech enterprise specialized in UPS, Power Inverter, Solar Power, VRLA Battery development, manufacturing, sales and after-service.

Our comprehensive product lines include:
Off-line UPS, line interactive UPS, On-line UPS, Solar inverter, Power inverters, Stabilizers and Solar battery.

Most of products from MUST applied with CE, FCC certificates. The main markets are Ukraine, Russia, Vietnam, Thailand, Pakistan, India, etc. Must Power Limited is one of the authorized suppliers for China Citic Bank, Ministry of Information Industry of China, Ministry of Power Industry of China, Ministry of Transportations of China.

With an excellent R & D team formed by over 30 engineers and a skilled, dedicated workforce, together 10, 000 square meter in-house manufacturing facilities in Guangdong China, Shenzhen Must Power Limited has innovated, developed and improved the products to meet the demands of customers and keep pace with changing demands of the industries. With 'close to customer' notion, we have aligned most of its resources to support our Original Equipment Manufacturer (OEM) customers, and work with our customers as power partners. Our mission is to be the best supplier of power solutions, and to accomplish this, we will continue to tailor products for market needs while maintaining high quality, integrated customer service and prompt delivery.
