6V~12V SLA/AGM/Gel Battery Charger
| Price: |
US $ 4.5-5.5/Piece |
| Trade Terms: |
FOB |
| Min Order: |
2000/Piece |
| Pay Type: |
T/T,Paypal |
| Prod Model: |
P2012-A6/P2012-A12 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| For Use: |
Standard Battery |
| Case: |
PC+ABS Plastic |
| Color: |
Black |
| Customized: |
Yes |
| Recovery Function: |
Yes |
| MCU Controller: |
Yes |
| Short Circuit Protection: |
Yes |
| Reverse Potection: |
Yes |
| LED Dispaly: |
Yes |
| Delivery Date: |
2-3 Weeks |
| Type: |
Lead-Acid Battery |
| Charger Type: |
Lead-Acid Battery Charger |
| Charger Application: |
Electric Toy, Electric Tools, Military Station |
| Nominal Voltage: |
6.9V /13.8V |
| Compatible Battery Type: |
6V,12V |
| Size: |
83 X 43 X30mm |
| Socket Type: |
UL,VDE,PSE,UK,SAA... |
Product Description
P2012-AXX Battery Charger for 6V 12V Lead Acid Car Battery
-
| Specification |
|---|
| Input: AC 100~240V |
| OUTPUT: 6.9V 2.0A, 13.8V 1.5A |
| Suit for: 6V,12V 2~18Ah Lead Acid battery |
| Charge Process: CC+CVH+CVL(3 Stages mode) |
| LED Indicator: Bi-color LED, RED/GREEN |
| Protections: Short-circuit, Reverse Polarity |
| Safety Approval: CE cUL PSE |
| Size: 83 x 43 x 30mm |
| Note: P2012-A12 has no MOQ limitation, P2012-A6 has 1kpcs MOQ limitation. |
P2012-A12 Trickle Battery Charger for 12V Lead Acid Battery
-
| Specification |
|---|
| Input: 100~240V |
| Output: 13.8V 1.5A |
| Charge Process: CC+CVH+CVL(3 Stages mode) |
| Charger Indicator: Bi-color LED, RED/GREEN |
| Output Protections: Short-circuit, Reverse Polarity |
| Safety Approval: CE cUL PSE |
| Size: 83 x 43 x30mm |
| Suit for Battery: 12 Volt 2~8Ah Lead-Acid Battery Charger |
Feature:
Programmed 3 auto stages (CC-Bulk-Float) charging process.
Designed for all kinds of 12V 2~12Ah lead-acid battery, such as SLA, AGM and Gel battery.
With bi-color LED indicator, easily know the charging process.
Protection mode for battery polarity reversed or the output connectors shorted.
UL, CE approval (EN60335-2-29 and UL1310)
Application: Car Battery, Motorcycle Battery, Automotive Battery, motorbike battery, etc.
Specification for P2012-A12
| Input Voltage | 100-240VAC, 50-60Hz |
| Input Current | 0.2A rms |
| Back current drain | 1.3mA |
| Bulk voltage Limited | P2012- A6 | P2012-A12 |
| 7.3V | 14.5V |
| Bulk charge current | 1A or 2A, defined when order | 0.8A or 1.5A, defined when order |
| Floating voltage | 6.8V | 13.6V |
| Operate Temperature | -20ºC~40ºC |
| Cooling | Natural convection. Do not cover the charger. |
| Charge principle | Auto 3 stages: CC-CV(Bulk)--Floating |
| LED indicator | Green for full charged or idle, Red for charging |
| Battery type | All types of 12V lead-acid batteries. (SLA, Gel, AGM.) |
| Battery capacity | 4~12Ah |
| Size | 81 x 43 x 30mm |
| Output cable and plug | 1.2 meter 2xAWG22#, UL2468 wire; plug type defined when order. |
| Input plug | US or VDE |
| Enclosure | ABS+PC Plastic housing |
| Weight | 100g |
Charger of Series P2012-AXX
| Charger Models | Input | Output | Suit for Battery |
|---|
| P2012-A6 | 100~240V | 6.9V 2.0A | 6 Volt 2~12Ah |
| P2012-A12 | 100~240V | 13.8V 1.5A | 12 Volt 2~8Ah |
Green-charger's engineers have dedicated to digital control power products for 13 years, specialize in the design and manufacture many types of NiMH, NiCd, Li-ion and Lead-acid battery charger and battery meter, and also is a professional in the face of high-end clients of the battery charger and battery meter. These products have high performance microprocessor technology to power your battery safely and quickly The main products are battery chargers that can be used in the Electrical-Vehicle, wheelchair, scooters, motorcycles, RC toy, RC flight, mobile light/lamp, LED lamp and many kinds of portable electrical device. The type of chargers have NiMH NiCd charger, lithium battery charger, lead-acid battery charger, LiFePO4 battery charger and so on. All sorts of 5W to 500W power charger all have production, is one of the most professional manufacturers of battery chargers in China.
After many years experiences, Green-charger made a super technology and rich experience of senior R&D engineers. We can develop battery chargers for NiMH, NiCd, Lead-Acid and Li-ion batter pack. The Battery chargers and Battery Management is our produces family also.
Our quality policy is: Providing high reliability of the products, to provide high satisfaction service. We are equipped with the advanced production and kind of test instruments, has the rich RoHS process production management, to ensure that every batch of products satisfy customers. Our products have CCC UL cUL CE VDE CB PSE FC EMC and so on.
We can according to the specific requirements of customers, customized all kinds of non-standard products to meet the needs
