| Prod Model: |
SLT-487WD |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Voltage: |
12V |
| No Load Speed: |
3950rpm |
| No Load Current: |
0.11A |
| Load Speed: |
3508rpm |
| Load Current: |
0.518A |
| Load Torque: |
220g.Cm |
| Output: |
7.97W |
| Stall Torque: |
1975g.Cm |
| Stall Current: |
6.920A |
| Application: |
Medical Equipments |
| Operating Speed: |
Adjust Speed |
| Excitation Mode: |
Excited |
| Structure And Working Principle: |
Brush |
| Certification: |
CE |
| Brand: |
Slt |
Product Description
1,Normal Voltage:6V-36V
2,No load speed:3000-10000 r/min
3,At Max Efficiency speed:3000-1000 r/min
4,At Max Efficiency torque:3-60 mN.m
5,Product range: diameter 13mm-130mm
Advantages of Micro DC Motor
A:Save cost, price is low
B:Better reliability.
C:Low energy consumption.
D:Speed is steady.
E:Easy to run and adjust the speed.
F:Small size, easy to carry.
G:Application range is super wide.
| Model | RH-487WD-3036 | RH-487WD-4016 | RH-487WD-2172 | RH-487SD-2548 |
| Voltage | Operating Range (V) | 6.0-15.0 | 6.0-12.0 | 15.0-28.0 | 6.0-15.0 |
| Nominal (V) | 12.00 | 9.00 | 9.00 | 13.50 |
| NO Load | Speed | r/min | 3950 | 6700 | 6700 | 4616 |
| Current | A | 0.11 | 0.3 | 0.06 | 0.11 |
| At Max Efficiency | Speed | r/min | 3508 | 5950 | 3488 | 3907 |
| Current | A | 0.87 | 2.37 | 0.45 | 0.62 |
Torque | mN.m | 21.56 | 25.38 | 22.64 | 14 |
| g.cm | 220 | 259 | 231 | 142 |
| Output | W | 7.97 | 15.84 | 8.28 | 8.37 |
| Stall | Torque | mN.m | 193.55 | 226.38 | 193.55 | 90.59 |
| g.cm | 1975 | 2310 | 1975 | 924 |
| Current | A | 6.920 | 18.780 | 3.420 | 3.400 |
Applications
A:Car (Fan,View mirror,wiper blade,car seat adjustment and so on.)
B.Home Applicance ( Electric cooker, Electric mop and other products.)
C.Medical equipments and beauty products.
D.Office products (such as printer, scanner......)
E.High efficiency for power saving
Why choose us ?
A:Quality in sure.
Quality is our culture!
Our company has passed ISO9001 and CCC International Quality Authentication System, so we can totally guarantee the excellent quality for you
B.Price is competitive.
Our Company has competitive raw materials,in the consequence we also have competitive price in the market.
C.Service is excellent.
With solid researching and developing strength,well-trained employees and strict inner management,our service is humanized and considerate.
D.Delivery on time.
Honesty is our Principle
Our company has formed our own distinctive enterprise manner-researching intensively,producing professionally and serving devotedly,so we will keep highly appointment with all our customers.
About Sunlight
1,The company covers an area of 5000 square meters;
2,Modern workshops have advanced production lines and professional knowledge of assembly.
3,Excellent sales team and after-sales service
4,Professional technical team
5,Broad market:Europe(Germany....)America(America,Canada...)
Asian( Korea, Japan...)
Our services
Need products in hurry?
We are a professional manufacturer of electronic components and 3D printer parts and flight control parts etc product in China. So we can make your order into reality in the shortest time!
Immediate response to your request!
We know time is money.Pls don't hesitate to contact us with phone,email or live chat.We'll do our best to reply you within 24 hours!
Shipment and Package
a.Strong packaging to ensure safty during transportation.
b.This supplier supports Trade Assurance.
Follow the Trade Assurance process and get:
1.On-time shipment and pre-shipment product quality safeguards
2.Refund up to the covered amount agreed with your supplier
3.Supplier's Trade Assurance Limit
4.Inner packing(Waterproof plastic bag packing)+Outer packing(Carton packing)
5.Export wooden box packaging for products.
6.Other package as you required
Personal Information
Changzhou sunlight Co., Ltd
Contact Person: Mary Wang
Tel.: 86-519-83825998
Fax.: 86-519-83823899
Mobile: 86-13915006892
Website: www.czsunlight.com or www.sunlightmotor.com
Made in China website :czsunlightmotor.en.made-in-china.com
Changzhou Sunlight Motor is the subsidiary company of the Jiangsu Woersen Electronics Technology Co., Ltd. It also contains Wenwei tube, Rongda Electronics, Woersen motor.
There are almost two hundred people in this group, including twenty technical engineers, eight R&D engineers. Annual value of production is about 0.16 billion.
The main products are DC motor, brushless DC motor, linear actuator and DC fan.
At present, our products have been exported to the United States, Germany, Britain, Russia, Japan, South Korea and so on. And we have received the high praise from our customers.
Currently, our company has passed ISO9000 and TS16949 certifications. The factory also has been audited by the authority SGS.
We welcome all the global companies to visit our factory and negotiate with us!
Sunlight is a young and dynamic team. Our slogan is " Where there is power supply, there is Sunlight"
We can not only meet our clients` mass production order, but also be flexible to provide the small quantity order for our clients too.
Meanwhile, the professional OEM services could be provided by us according to the customers'requests. The main brushless DC motor's series are: 42BLDC, 57BLDC, 86BLDC 110BLDC motor and so on
The main brush DC motor's series are: 130DC, 365DC, 370DC, 477DC motor and so on;
The main linear actuator's series are: ST01, PT01, YT01 and so on;
The main fan's series are: 16inch, 12inch, and so on
So that, If you give us a chance, Sunlight Motor will not let you disappoint.
