| Prod Model: |
SL Series |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Color: |
Black.White.Grey |
| Warranty Time: |
1 Year |
| Quality: |
First Class |
| Sample: |
Available |
| Type: |
Lead-Acid Batteries |
| Usage: |
Boat |
| Nominal Voltage: |
12V |
| Discharge Rate: |
Medium Discharge Rate |
| Shape: |
Square Battery |
| Rechargeable: |
Chargeable |
Product Description
6V 225ah Deep Cycle Solar Battery with maintenance free operation
key features
1:sealed and maintenance free operation
2:advanced welding machine ,not easy shourt-circuit ,ensure batteries long life
3:Nano gel electrolyte eliminate the acid stratification and prolong cycle life
4:Accurate acid filler kept the amount of the electrolyte in each cell precisely
5:Excellent high rate of discharge performance
6:Can be put into use without charging immediately
7:flexibility design for multiple install positions
8:At good consistency, no short circuit,anti-pole or poor welding problems
9:Flow the specification or users manual for the charging and discharging of battery
10:Widely working environment: The gel battery can be used at widely difference in temperature from subzero 40ºC to 60 ºC.
main application
marine equipment,cable television ,medical equipment,Portable measuring equipment
Portable telephone sets,Emergency lighting system,Solar powered systerm equipment,Power plant transformer substation,Radio telecommunication equipment.equipment,Emergency lighting equipment,Fire alarm and security systems etc.
Technical Specification
model | nominal | capacity | external dimension | weight | terminal |
| voltage | (ah) | length | width | height | total height | approx | type |
| (v) | 10hr(20hr) | mm | inch | mm | inch | mm | inch | mm | inch | kg | pound | |
| sl1250 | 12 | 5 | 90 | 3.54 | 70 | 2.76 | 101 | 3.98 | 106 | 4.2 | 1.7 | 3.74 | t1 |
| sl1250(ii) | 12 | 5 | 90 | 3.54 | 70 | 2.76 | 101 | 3.98 | 106 | 4.2 | 1.58 | 3.48 | t1/t2 |
| sl1250(iii) | 12 | 5 | 151 | 5.94 | 51 | 2.01 | 93 | 3.66 | 99 | 3.9 | 1.92 | 4.22 | t1/t2 |
| sl1250(iv) | 12 | 5 | 151 | 5.94 | 51 | 2.01 | 93 | 3.66 | 99 | 3.9 | 1.98 | 4.36 | t1/t2 |
| sl1250(v) | 12 | 5 | 151 | 5.9 | 51 | 2 | 93 | 3.66 | 99 | 3.9 | 1.8 | 3.96 | t1 |
| sl1250(vi) | 12 | 5 | 140 | 5.5 | 48 | 1.89 | 102 | 4.02 | 103 | 4.1 | 1.68 | 3.7 | t43 |
| sl1260 | 12 | 6 | 151 | 5.94 | 65 | 2.56 | 94 | 3.7 | 100 | 3.9 | 2.2 | 4.85 | t1/t2 |
| sl1265 | 12 | 6.5 | 151 | 5.94 | 65 | 2.56 | 94 | 3.7 | 100 | 3.9 | 2 | 4.41 | t1/t2 |
| sl1265(ii) | 12 | 6.5 | 151 | 5.94 | 65 | 2.56 | 94 | 3.7 | 100 | 3.9 | 1.95 | 4.3 | t1/t2 |
| sl1270 | 12 | 7 | 151 | 5.94 | 65 | 2.56 | 94 | 3.7 | 100 | 3.9 | 2.34 | 5.16 | t1/t2 |
| sl1270(ii) | 12 | 7 | 151 | 5.94 | 65 | 2.56 | 94 | 3.7 | 100 | 3.9 | 2.2 | 4.86 | t1/t2 |
| sl1270(iii) | 12 | 7 | 151 | 5.94 | 51 | 2.01 | 94 | 3.7 | 100 | 3.9 | 2 | 4.41 | t1/t2 |
| sl1270(iv) | 12 | 7 | 151 | 5.94 | 65 | 2.56 | 94 | 3.7 | 100 | 3.9 | 2.15 | 4.75 | t1 |
| sl1275 | 12 | 7.5 | 151 | 5.94 | 65 | 2.56 | 94 | 3.7 | 100 | 3.9 | 2.47 | 5.45 | t1/t2 |
| sl1275(ii) | 12 | 7.5 | 151 | 5.94 | 65 | 2.56 | 94 | 3.7 | 100 | 3.9 | 2.38 | 5.24 | t1/t2 |
| sl1280 | 12 | 8 | 151 | 5.94 | 65 | 2.56 | 94 | 3.7 | 100 | 3.9 | 2.5 | 5.51 | t1/t2 |
| sl1290 | 12 | 9 | 151 | 5.94 | 65 | 2.56 | 94 | 3.7 | 100 | 3.9 | 2.78 | 6.13 | t2/t1 |
| sl1290(ii) | 12 | 9 | 151 | 5.94 | 65 | 2.56 | 94 | 3.7 | 100 | 3.9 | 2.45 | 5.4 | t2/t1 |
| sl12100 | 12 | 10 | 151 | 5.94 | 65 | 2.56 | 111 | 4.37 | 116 | 4.6 | 3.2 | 7.05 | t2 |
| sl12100(ii) | 12 | 10 | 151 | 5.94 | 98 | 3.86 | 94 | 3.7 | 100 | 3.9 | 3.45 | 7.6 | t1/t2 |
| sl12120 | 12 | 12 | 151 | 5.94 | 98 | 3.86 | 94 | 3.7 | 100 | 3.9 | 3.7 | 8.16 | t251/t1 |
| sl12120(ii) | 12 | 12 | 151 | 5.94 | 98 | 3.86 | 94 | 3.7 | 100 | 3.9 | 3.45 | 7.71 | t251/t1 |
| sl12140 | 12 | 14 | 151 | 5.94 | 98 | 3.86 | 94 | 3.7 | 100 | 3.9 | 4.1 | 9.02 | t2 |
| sl12150 | 12 | 15 | 181 | 7.13 | 77 | 3.03 | 167 | 6.57 | 167 | 6.6 | 5.3 | 11.68 | t3/t13 |
| sl12160 | 12 | 16 | 181 | 7.13 | 77 | 3.03 | 167 | 6.57 | 167 | 6.6 | 5.3 | 11.08 | t3/t13 |
| sl12180 | 12 | 18 | 181 | 7.13 | 77 | 3.03 | 167 | 6.57 | 167 | 6.6 | 5.3 | 11.68 | t3/t13 |
| sl12180(ii) | 12 | 18 | 181 | 7.13 | 77 | 3.03 | 167 | 6.57 | 167 | 6.6 | 5.5 | 12.11 | t3a/t13 |
| sl12200 | 12 | 20 | 181 | 7.13 | 77 | 3.03 | 167 | 6.57 | 167 | 6.6 | 5.8 | 12.76 | t3a/t14 |
| sl12220 | 12 | 22 | 181 | 7.13 | 77 | 3.03 | 167 | 6.57 | 167 | 6.6 | 6.1 | 13.43 | t3a/t14 |
| sl12240 | 12 | 24 | 166 | 6.54 | 175 | 6.9 | 125 | 4.92 | 125 | 4.9 | 7.2 | 15.87 | t4/t13 |
| sl12240(ii) | 12 | 24 | 166 | 6.5 | 125 | 4.92 | 175 | 6.89 | 182 | 7.2 | 8 | 17.6 | t66/t32 |
| sl12260 | 12 | 26 | 175 | 6.89 | 166 | 6.54 | 125 | 4.92 | 125 | 4.9 | 7.8 | 17.62 | t4/t13 |
| sl12280 | 12 | 28 | 175 | 6.89 | 166 | 6.54 | 125 | 4.92 | 125 | 4.9 | 9 | 19.82 | t4/t13 |
| sl12280(ii) | 12 | 28 | 166 | 6.5 | 125 | 4.92 | 175 | 6.89 | 182 | 7.2 | 9 | 19.82 | t66/t32 |
| sl12280(iii) | 12 | 28 | 175 | 6.9 | 166 | 6.54 | 125 | 4.92 | 125 | 4.9 | 8.7 | 19.16 | t4/t13 |
| sl1870 | 18 | 7 | 151 | 5.9 | 102 | 4.02 | 100 | 3.94 | 100 | 3.9 | 3.5 | 7.7 | tw5 |
| sl2435 | 24 | 3.5 | 180 | 7.1 | 73 | 2.87 | 70 | 2.76 | 70 | 2.8 | 2.6 | 5.73 | tw10 |
| sl24180 | 24 | 18 | 170 | 6.69 | 146 | 5.75 | 187 | 7.36 | 187 | 7.4 | 11 | 24.23 | tw10 |
| sl6360 | 6 | 36 | 162 | 6.38 | 88 | 3.46 | 164 | 6.46 | 170 | 6.7, , | 5.9 | 13.04 | t251/t16 |
| sl6420 | 6 | 42 | 162 | 6.38 | 88 | 3.46 | 164 | 6.46 | 170 | 6.7 | 5.9 | 13.04 | t251/t16 |
| sl61000 | 6 | 100 | 195 | 7.67 | 170 | 6.69 | 2.06 | 8.11 | 211 | 8.3 | 17 | 37.57 | t16 |
| sl61050 | 6 | 105 | 280 | 11.02 | 128 | 5.03 | 203 | 7.99 | 203 | 8 | 18.5 | 40.88 | t16 |
| sl61200 | 6 | 120 | 195 | 7.67 | 170 | 6.69 | 206 | 8.11 | 211 | 8.3 | 19 | 42 | t16 |
| sl61500 | 6 | 150 | 260 | 10.2 | 180 | 7.09 | 247 | 9.72 | 252 | 9.9 | 27 | 59.67 | t19 |
| sl61800 | 6 | 180 | 260 | 10.2 | 180 | 7.09 | 247 | 9.72 | 252 | 9.9 | 29 | 64.09 | t19 |
| sl61800(ii) | 6 | 180 | 323 | 12.72 | 178 | 7.01 | 224 | 8.82 | 229 | 9 | 30 | 66.14 | t85 |
| sl61900 | 6 | 190 | 306 | 12 | 169 | 6.65 | 223 | 8.78 | 228 | 9 | 28 | 61.6 | t19 |
| sl62000 | 6 | 200 | 323 | 12.72 | 178 | 7.01 | 224 | 8.82 | 229 | 9 | 29.5 | 65.19 | t19 |
| sl62250 | 6 | 225 | 243 | 9.57 | 188 | 7.4 | 275 | 10.8 | 275 | 11 | 34.5 | 76.24 | t19 |
| sl62250(ii) | 6 | 225 | 260 | 10.2 | 180 | 7.09 | 247 | 9.72 | 252 | 9.9 | 29.5 | 65.2 | t19 |
| sl81800 | 8 | 180 | 260 | 10.23 | 182 | 7.17 | 295 | 11.6 | 300 | 12 | 36.5 | 64.09 | t19 |
| sl12330 | 12 | 33 | 196 | 7.7 | 131 | 5.16 | 155 | 6.1 | 170 | 6.7 | 10 | 22.1 | t16/t64 |
| sl12330(ii) | 12 | 33 | 196 | 7.7 | 131 | 5.16 | 155 | 6.1 | 170 | 6.7 | 9.7 | 21.44 | t16/t64 |
| sl12350 | 12 | 35 | 196 | 7.7 | 131 | 5.16 | 155 | 6.1 | 170 | 6.7 | 10.5 | 23.2 | t16/t64 |
| sl12400 | 12 | 40 | 197 | 7.73 | 166 | 6.54 | 171 | 6.73 | 171 | 6.7 | 13.5 | 29.74 | t9/t16 |
| sl12400(ii) | 12 | 40 | 197 | 7.73 | 166 | 6.54 | 171 | 6.73 | 171 | 6.7 | 13 | 28.73 | t9/t16 |
| sl12400(iii) | 12 | 40 | 197 | 7.76 | 166 | 6.54 | 175 | 6.89 | 180 | 7.1 | 13 | 28.6 | t51 |
| sl12150w | 12 | 40 | 197 | 7.76 | 166 | 6.54 | 170 | 6.69 | 170 | 6.7 | 13.5 | 29.83 | t66 |
| sl12440 | 12 | 44 | 196 | 7.7 | 166 | 6.54 | 171 | 6.73 | 171 | 6.7 | 13.5 | 29.83 | t7/t9/t16 |
| sl12440(ii) | 12 | 44 | 197 | 7.76 | 166 | 6.54 | 175 | 6.89 | 182 | 7.2 | 13.5 | 29.83 | t51 |
| sl12500 | 12 | 50 | 230 | 9.1 | 138 | 5.43 | 208 | 8.19 | 232 | 9.1 | 17.2 | 38 | t9/t16 |
| sl12550 | 12 | 55 | 230 | 9.1 | 138 | 5.43 | 208 | 8.19 | 232 | 9.1 | 17.2 | 38 | t9/t16 |
| sl12550(ii) | 12 | 55 | 230 | 9.1 | 138 | 5.43 | 208 | 8.19 | 228 | 8.9 | 17.2 | 38 | t53 |
| sl12550(iii) | 12 | 55 | 230 | 9.1 | 138 | 5.43 | 211 | 8.19 | 226 | 8.9 | 17.2 | 38 | t16 |
| sl12550(iv) | 12 | 55 | 277 | 10.91 | 106 | 4.17 | 222 | 8.74 | 222 | 8.7 | 17.5 | 38.58 | t102 |
| sl12600 | 12 | 60 | 240 | 9.45 | 200 | 7.87 | 199 | 7.83 | 209 | 8.2 | 21 | 46.3 | t15 |
| sl12600(ii) | 12 | 60 | 350 | 13.78 | 167 | 6.57 | 179 | 7.05 | 179 | 7.1 | 21 | 46.3 | t9/t16 |
| sl12600(iii) | 12 | 60 | 265 | 10.43 | 190 | 7.48 | 222 | 8.74 | 222 | 8.7 | 21 | 46.3 | t |
| sl12650 | 12 | 65 | 350 | 13.8 | 166 | 6.54 | 179 | 7.05 | 179 | 7.1 | 21 | 46.4 | t9/t16 |
| sl12650(ii) | 12 | 65 | 350 | 13.8 | 166 | 6.54 | 179 | 7.05 | 179 | 7.1 | 22 | 48.5 | t9/t16 |
| sl12700 | 12 | 70 | 260 | 10.2 | 169 | 6.65 | 211 | 8.3 | 229 | 9 | 23 | 50.66 | t16/t33 |
| sl12700(ii) | 12 | 70 | 260 | 10.2 | 169 | 6.65 | 211 | 8.3 | 229 | 9 | 22.8 | 50.3 | t16/t33 |
| sl12700(iii) | 12 | 70 | 260 | 10.2 | 169 | 6.65 | 210 | 8.27 | 217 | 8.5 | 22.8 | 50.27 | t9/t16 |
| sl12700(iv) | 12 | 70 | 350 | 3.78 | 167 | 6.67 | 178 | 7.01 | 179 | 7.1 | 22.5 | 49.72 | t9/t16 |
| sl12750 | 12 | 75 | 562 | 22.13 | 114 | 4.49 | 188 | 7.4 | 188 | 7.4 | 27 | 59.52 | t102 |
| sl12800 | 12 | 80 | 260 | 10.2 | 169 | 6.65 | 211 | 8.3 | 229 | 9 | 23.5 | 51.93 | t16/t33 |
| sl12800(ii) | 12 | 80 | 350 | 13.78 | 166 | 6.54 | 179 | 7.05 | 179 | 7.1 | 23.5 | 51.7 | t16 |
| sl12800(iii) | 12 | 80 | 350 | 13.78 | 166 | 6.54 | 179 | 7.05 | 179 | 7.1 | 23 | 50.71 | t9/t16 |
| sl12900 | 12 | 90 | 307 | 12.08 | 169 | 6.65 | 211 | 8.3 | 234 | 9.2 | 28 | 61.88 | t10/t16 |
| sl12900(ii) | 12 | 90 | 307 | 12.08 | 169 | 6.65 | 211 | 8.3 | 234 | 9.2 | 27.5 | 60.77 | t10/t16 |
| sl12900(iii) | 12 | 90 | 307 | 12.1 | 168 | 6.61 | 208 | 8.19 | 214 | 8.4 | 28 | 61.88 | t10/t16 |
| sl121000 | 12 | 100 | 330 | 12.99 | 172 | 6.77 | 214 | 8.43 | 237 | 9.3 | 32 | 70.55 | t10/t16 |
| sl121000(ii) | 12 | 100 | 331 | 13 | 173 | 6.81 | 213 | 8.39 | 235 | 9.3 | 30.8 | 68.1 | t10/t16 |
| sl121000(iii) | 12 | 100 | 407 | 16 | 174 | 6.85 | 209 | 8.23 | 233 | 8.8 | 34 | 75 | t16/t11d |
| sl121050 | 12 | 105 | 508 | 20 | 110 | 4.33 | 224 | 8.82 | 239 | 9.4 | 30.6 | 67.6 | t16 |
| sl121100 | 12 | 110 | 331 | 13 | 173 | 6.81 | 213 | 8.39 | 235 | 9.3 | 33 | 72.9 | t10/t16 |
| sl121200 | 12 | 120 | 407 | 16 | 174 | 6.85 | 209 | 8.23 | 233 | 9.2 | 38 | 83.98 | t11/t16 |
| sl121200(ii) | 12 | 120 | 407 | 16 | 174 | 6.85 | 209 | 8.23 | 233 | 9.2 | 36.5 | 80.66 | t11/t16 |
| sl121340 | 12 | 134 | 341 | 13.4 | 173 | 6.81 | 283 | 11.1 | 289 | 11 | 41.5 | 91.3 | t19 |
| sl121500 | 12 | 150 | 484 | 191.1 | 171 | 6.73 | 241 | 9.49 | 241 | 9.5 | 46 | 101 | t12/t50 |
| sl121600 | 12 | 160 | 534 | 21.1 | 209 | 8.23 | 216 | 8.5 | 237 | 9.3 | 52 | 115 | t11/t60 |
| sl121600(i) | 12 | 160 | 534 | 21.1 | 209 | 8.23 | 216 | 8.5 | 237 | 9.3 | 50 | 110.5 | t11/t60 |
| sl121800 | 12 | 180 | 530 | 20.8 | 209 | 8.23 | 216 | 8.5 | 237 | 9.3 | 55.5 | 122.6 | t11/t60 |
| sl121800(ii) | 12 | 180 | 534 | 21.1 | 209 | 8.23 | 216 | 8.5 | 237 | 9.3 | 53 | 117.1 | t11/t60 |
| sl122000 | 12 | 200 | 522 | 20.6 | 240 | 9.45 | 220 | 8.66 | 244 | 9.6 | 63.5 | 140.4 | t11/t19 |
| sl122000(ii) | 12 | 200 | 522 | 20.6 | 240 | 9.45 | 220 | 8.66 | 244 | 9.6 | 60.5 | 133.7 | t11/t19 |
| sl122300 | 12 | 230 | 520 | 20.5 | 268 | 10.6 | 220 | 8.66 | 240 | 9.4 | 72.5 | 160.2 | t12/t19 |
| sl122300(ii) | 12 | 230 | 520 | 20.5 | 268 | 10.6 | 220 | 8.66 | 240 | 9.4 | 69.5 | 153.6 | t12/t19 |
| sl122500 | 12 | 250 | 520 | 20.5 | 268 | 10.6 | 220 | 8.66 | 241 | 9.3 | 76 | 174 | t12/t19 |
| sl122500(ii) | 12 | 250 | 520 | 20.5 | 268 | 10.6 | 220 | 8.66 | 241 | 9.3 | 73 | 161.3 | t12/t19 |
| *specification are subject to change without prior notice |
Shenzhen UPSEN Electronic Co., Ltd. Which is located in south of China, Shenzhen City, close to Pearl of the Orient HK, with beautiful environment and convenient transport.
We are a private high-tech enterprise integrating researching & development, production & operation and technical services as a whole, which is specialized in Electric, Electronic and Energy fields for a long time. Our main products are UPS Power, Inverter Power, Battery Power, Solar&Wind Power. We are dedicated to offer quality power and power solution for Data-center, Telecom, Bank, Hospital, Transportation, Industry, Army, Security, and civil & office area etc. Moreover, we have mastered the core technology of power products through our independent research, we are one of few domestic enterprises which can meet the customers' customized requirements, and provide professional power solutions.
We already past ISO9001 international quality system certification, and established a complete quality system ranging from material source, process, assembling to testing. All our products are with CE Certificate, which exported to more than 30 countries and areas, like Australia, Europe, Africa, North America, South America, the Middle East, central Asia, southeast Asia etc.
We will always offer excellent quality and products to customers. Hope to make Integrity and Double-Win business with you, and to be your professional power supplier and solve your any power problems. We are sure UPSEN can achieve more successes with our efforts and your support.
