| Prod Model: |
SLT-42BL03 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Voltage: |
24V |
| No Load Speed: |
5300 R/Min |
| Rated Torque: |
0.063nm |
| Rated Speed: |
4000r/Min |
| Rated Current: |
1.6A |
| Environment Conditions: |
-10-40 |
| Magnet Material: |
Bonded NdFeB |
| Insulation Class: |
B |
| Weight: |
0.29kg |
| Length: |
43mm |
| Application: |
Medical Equpiments |
| Operating Speed: |
Constant Speed |
| Excitation Mode: |
Compound |
| Structure And Working Principle: |
Brushless |
| Certification: |
CE |
| Brand: |
Slt |
Product Description
Product description
Model:SLT42BL03
Voltage:24V
No Load Speed:5000rpm
Rated torque:0.185Nm
Rated Speed:4000rpm
Rated Current:0.5Nm
Stall torque:250mNm
Stall current:0.73A
Weight:0.65Kg
The specification of 6V-36V BLDC Electric Geared Brushless DC Motor for Electric Tool| 42BLF-Brushless DC Motor |
| Technique Specification |
| Model | SLT42BLF20 | SLT42BLF40 | SLT42BF60 | SLT42BLF80 |
| Number of poles | | 8 |
| Voltage | V | 24 |
| No load speed | RPM | 5300 | 5400 | 5200 | 5200 |
| Rated torque | N.m | 0.063 | 0.125 | 0.185 | 0.24 |
| Rated Speed | RPM | 4000 | 4000 | 4000 | 4000 |
| Rated power | W | 25 | 50 | 75 | 100 |
| Rated Current | A | 1.6 | 3.2 | 4.7 | 6.5 |
| Peak torque | N,m | 0.18 | 0.37 | 0.54 | 0.72 |
| Back-EMF constant | V/KRPM | 3.3 | 3.23 | 3.38 | 3.36 |
| Weight | Kg | 0.29 | 0.47 | 0.65 | 0.87 |
| Length | mm | 43 | 63 | 93 | 113 |
Applications of 6V-36V BLDC Electric Gear Brushless DC Motor for electric tool
A.Car (Fan,View mirror,wiper blade,car seat adjustment and so on.)
B.Home Applicance ( Electric cooker, Electric mop and other products.)
C.Medical equipments and beauty products.
D.Office products (such as printer, scanner......)
E.Other Fields.
Equipments of 6V-36V BLDC Electric Gear Brushless DC Motor for electric toolCompany & certifications
a.Modern office building, we warmly welcome your visiting.
b.We attend exhibitions domestic and overseas. Rich activities to improve work enthusiasm
c.ISO, CE, GS, Rohs certificates. We have been making good progress.
Shipment and Packagea.Strong packaging to ensure safty during transportation.
b.This supplier supports Trade Assurance.
C.Our products are transported to many countries
Follow the Trade Assurance process and get:
1.On-time shipment and pre-shipment product quality safeguards
2.Refund up to the covered amount agreed with your supplier
3.Supplier's Trade Assurance Limit:
FAQ
(1) Q: What kind of motors can you provide?
A:For now,we mainly provide DC Brushed Motor, DC Brushless motor, Gear Motor, Fan Motor, BLDC Motor, Synchronous Motor, Stepping Motor etc.
(2) Q: Is it possible to visit your factory
A: Sure. But please kindly keep us posted a few days in advance. We can arrange it for you then.
(3) Q: Can I get some samples
A: Yes, welcome to take samples to test our quality and service.
Personal Information
if you need more information.
please contact with us, our contact information:
Changzhou sunlight Co., Ltd
Contact Person: Ariana Wang
Tel.: 86-519-83825998
Fax.: 86-519-83823899
Mobile: 86-13407564218
Website: www.czsunlight.com or www.sunlightmotor.com
Changzhou Sunlight Motor is the subsidiary company of the Jiangsu Woersen Electronics Technology Co., Ltd. It also contains Wenwei tube, Rongda Electronics, Woersen motor.
There are almost two hundred people in this group, including twenty technical engineers, eight R&D engineers. Annual value of production is about 0.16 billion.
The main products are DC motor, brushless DC motor, linear actuator and DC fan.
At present, our products have been exported to the United States, Germany, Britain, Russia, Japan, South Korea and so on. And we have received the high praise from our customers.
Currently, our company has passed ISO9000 and TS16949 certifications. The factory also has been audited by the authority SGS.
We welcome all the global companies to visit our factory and negotiate with us!
Sunlight is a young and dynamic team. Our slogan is " Where there is power supply, there is Sunlight"
We can not only meet our clients` mass production order, but also be flexible to provide the small quantity order for our clients too.
Meanwhile, the professional OEM services could be provided by us according to the customers'requests. The main brushless DC motor's series are: 42BLDC, 57BLDC, 86BLDC 110BLDC motor and so on
The main brush DC motor's series are: 130DC, 365DC, 370DC, 477DC motor and so on;
The main linear actuator's series are: ST01, PT01, YT01 and so on;
The main fan's series are: 16inch, 12inch, and so on
So that, If you give us a chance, Sunlight Motor will not let you disappoint.
