6V150ah Gel Deep Cycle Battery for Power System

Prod Model:	6V150ah
Operating Temperature:	-20c~50c
Design Time:	10-12 Years
Separator:	AGM
Charge Voltage (Cycle):	2.40~2.50V
Container Material:	ABS(UL94-Hb) *Flammability Resistance of (UL94-V0)
Material Lead:	#1 Lead Top Quality in China
Terminal:	Nb or B
Color:	Grey or Black
Self Discharge:	Less Than 3% Per Month
Certificate:	ISO, UL, Ce
Type:	Lead-Acid Batteries
Usage:	Electric Bicycle
Nominal Voltage:	6V
Discharge Rate:	Low Discharge Rate
Shape:	Square Battery
Rechargeable:	Chargeable

Product Description

6V150ah gel deep cycle battery for power system

LONG WAY 3-EVF-150 is one of the Deep Cycle series of Kaiying Power Supply & Electrical Equip
Co.,Ltd.The series adopt new materiel,new technology,new process,with higher weight ratio of
energy and good resistance to vibration performance ,a good consistency,high charge rate,deep
discharge recovery,low self discharge,sealed and maintenance free.It is quiet suitable for using as
electrical system of electric road vehicles, applications widely in low speed electric vehicles,golf cart,
travel car,old scooter,electrical wheel chair,electric sanitation vehicles and police patrol car etc.

Specification:
Nominal Voltage(V) 6V
The Open Circuit Voltage(V) 6.45-6.66V
Cells per Unit 3
Discharge
Capacity
at 25 ºC
Average weight/kg 30.0kg
Container material ABS(UL94-HB)
Charge
voltage/V
Float charge(V) 6.90----7.05V
Cycle(V) 7.20---7.50V
Maximum discharge current/A 750A
Reasonable charge current/A 30.0A
Terminal type F12
Screw stem M8 stem
25ºC Self discharge rate
Less than3% per
month
Operate temperature range
Discharge:-15~50ºC
Charge: -15ºC~40ºC
Storage: -15ºC~40ºC

Gel Battery
LONGWAY gel series battery is manufactured silica gel to immobilize the electrolyte inside the battery. The proven silica gel technology improves battery cycle life and performance at cold ambient temperatures. The deep discharge cycles is increased by 30% as compared with the AGM battery.

General Features
Environmentally friendly
Longer Service Life
High reliability and quality
High power density
Excellent recovery from Deep Discharge
Living up to Prevailing Standards
Non-sensitive-to Occasional deep discharges
International leading technology

Applications
Solar and wind systems
Cable TV
Telecommunications
Wheelchair
Marine equipment
Military equipment
Emergency lighting

If get interest, just contact me freely.



6V150ah gel deep cycle battery for power system
