6V260ah UPS EPS Solar Lead Acid Traction Deep Cycle VRLA Battery

Name: 6V260ah UPS EPS Solar Lead Acid Traction Deep Cycle VRLA Battery
Brand: all-electronics-online.com
SKU: 831070725
Availability: InStock
Rating: 5 (20 reviews)

Price:	US $ 196/Piece
Min Order:	1/Piece
Pay Type:	L/C,T/T,D/P

Contact Supplier

Showroom Product Company Profile

Prod Model:	GE260-6DM
Type:	Lead-Acid Batteries
Usage:	Solar Power
Nominal Voltage:	6V
Discharge Rate:	Medium Discharge Rate
Shape:	Square Battery
Rechargeable:	Chargeable

Product Description

Golf Cart Series Batteries are maintenance free sealed lead-acid batteries

composed of flat plates, high porosity AGM separator and ABS container.

The cycle life is longer rather than conventional flooded batteries

because of better vibration and impact resistant. Better deep discharge

performance and quick recharge are also the key features of these

batteries.

Advantages:

1. Design life: 15 years(25ºC);

2. EUROBAT Classification: Long life;

3. High discharge performance;

4. 99%+ gas recombination efficiency;

5. Maximum charge efficiency;

6. Low self-discharge rate;

7. Easy installation and handling;

Standards:

You can expect our batteries meet with the standards JIS, DIN, IEC60896-21/22. We have obtained ISO9001 & ISO14001 certification.

1. GB/T19638.1-2014

2. YD/T799-2010

3. DL/T637-1997

4. JIS C8704-1:2006

5. JIS C8704-2:2006

6. IEC60896-21/22:2004

7. Eurobat guide

8. Installation compliant with EN50272-2

General Features:

Maintenance-free sealed construction, spill proof--safe and reliable.

Strength-enhanced ABS container and compressed plate groups--better vibration and impact resistant.

Special Lead-Calcium grid design--better corrosion resistant, deep discharge performance, higher capacity and longer cycle life.

High porosity AGM separator--high oxygen recombination rate to ensure minimum gassing.

Brass insert terminals--superior conductivity and high rate discharge performance.

Low internal resistance--high charge acceptance and quick recharge.

Low self discharge--longer shelf life than conventional batteries

Typical Applications:

Golf cart.

Electric sightseeing car.

Electric vehicle.

Electric scooter.

Marine.

Solar.

Electric forklift.

Portable Medical device.

Scraper.

Wheelchair.

Model	Nominal Voltage(V)	Rated Capacity@25ºC(AH)		Approx Dimensions								Approx Weight		Terminals Type	Layout
		20HR 1.75V/Cell	10HR 1.70V/Cell	Length		Width		Hight		Total Hight		Approx Weight
		20HR 1.75V/Cell	10HR 1.70V/Cell	mm	in.	mm	in.	mm	in.	mm	in.	kgs.	lbs.
GE105-12DM	12	105	100	306	12.05	168	6.61	208	8.19	214	8.43	27.3	60.19	F	1
GE145-12DM	12	145	138	340	13.39	172	6.77	280	11.02	286	11.26	42.0	92.59	F	1
GE200-8DM	8	200	190	260	10.24	182	7.17	295	11.61	298	11.73	41.0	90.39	F	1
GE170-8DM	8	170	160	260	10.24	182	7.17	267.5	10.53	272	10.71	35.0	77.16	F	2
GE260-6DM	6	260	247	262	10.31	180	7.09	270	10.63	274	10.79	34.5	76.06	F	6
GE245-6DM	6	245	233	243	9.57	188	7.40	275	10.83	275	10.83	32.0	70.55	G	6
GE225-6DM	6	225	214	260	10.24	180	7.09	246	9.69	269	10.59	30.5	67.24	F	6
GE210-6DM	6	210	200	323	12.72	178	7.01	226	8.90	230	9.06	30.2	66.58	F	5
GE190-6DM	6	190	180	306	12.05	168	6.61	220	8.66	225	8.86	29.0	63.93	F	6

15.08

155.5

342.82

Guangdong JIYI General Electric Co. Ltd started in 1986, originated from American lead acid battery company BHNGE BATTERIES Ltd. We are the earliest company who obtained American technology of VRLA, and we are the only one manufacturer of GERCH brand VRLA battery. Guangdong JIYI invested RMB200, 000, 000 to build factories in China, a manufacture base of 190, 000 square meters. With the development of GERCH brand, we are going deeper and deeper into international market, providing lead acid batteries in high quality and good price.

Guangdong JIYI General Electric Co. Ltd is the first battery company certified with the ISO9001 quality system in 1996. We also got certification of CE and UL (first one in battery industry in China) in 1997, and become the member of American Battery Industry Association in 1999 (only one in China). In 2003 GERCH was ranked international famous brand, the first one in China, and at the same time we got certification of IEC, the only one member from China.

Guangdong JIYI General Electric Co. Ltd imported full set of equipment from America and Germany, set test and research center. We are equipped with German test device "BAIRD"spectrometer, shaking test machine, universal battery test device, high current discharging test machine and other equipment. Our quality monitoring is on each step of production, raw material, semi-product and final product. The application of our battery covers many industries such as aviation, ship, military, plant, transformer, solar system, UPS, EPS, telecommunication, medical device, meters, engine, vehicle, truck and power tool etc.

Our company philosophy is work in scientific way, provide high quality product, satisfy customer and environment friend. Each of our products will strictly be built complying with domestic and international standard, and will be inspected by authorized organization.

Guangdong JIYI General Electric Co. Ltd produce all series of lead acid battery covering 1) Nano battery, 2)Silicon energy battery, 3)Lead crystal battery, 4)Deep cycle solar battery, 5)Gel solar battery, 6)GFM VRLA fattery, 7)Deep cycle motive battery, 8)OPzS battery, 9)OPzV maintenance free battery, 10)battery for boat, 11)Long life battery, 12)BS & DIN standard motive battery, 13)Aviation, nuclear station and rare earth battery, 14)High rate battery, 15)Lead carbon battery, 16)Polymer battery. Other relative products include 1)UPS, 2)solar panel, inverter, 3)DC system, 4)recharge device, 5)charging equipment, 6)monitor, 7)battery box. Our annual capacity is up to 1.20 million KVAH, one of the biggest production capacity in China.

Guangdong JIYI General Electric Co. Ltd we have a large group of respectable customer from all over the world. We are shipping to European countries, America, Australia, Africa, Japan, South Korea, Middle East, South east Asia market. We cooperate with GE, China aviation department, China military, State grid, Nuclear power station, hydro power station, BAO steel group, HUAWEI, Delix, National bank, ship manufacturing group etc.
