| Prod Model: |
CS6-330 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Model: |
AGM Battery 6V200ah |
| Size: |
295*178*360mm |
| Rated Capacity: |
330ah |
| Weight Apporox: |
46.6kg |
| Terminal: |
T5 |
| Warranty: |
2years |
| OEM: |
Available |
| Export Market: |
Global |
| Certificate: |
ISO, UL, Ce, Vds |
| Brand Name: |
Cspower |
| Usage: |
Boat |
| Nominal Voltage: |
6V |
| Discharge Rate: |
Low Discharge Rate |
| Shape: |
Square Battery |
| Rechargeable: |
Chargeable |
| Type: |
AGM Battery 6V225ah |
Product Description
CE Approval AGM Battery 6V330ah for Electric Power
Basic Info.
Model NO.: CS6-330
Type:Lead-Acid Batteries
Chargeable:Chargeable
Discharge Rate:Low Discharge Rate
Shape:Square Battery
Nominal Voltage:6V
Usage:Electric Power
Color:Black
Export Markets: Global
CE Approval AGM Battery 6V330ah for Electric Power
Additional Info.
Trademark:CSPOWER
Packing:Carton
Origin:Guangdong, China
HS Code:8507200000
Production Capacity:100000pcs/month
Standard:JIS, DIN,
Product Description
Deep Cycle Battery
Deep Cycle AGM Battery
Motive power battery
Electric Vehicle battery
Sealed Maintenance Free AGM Battery
AGM Batteries for Deep Cycle Services
Description
Deep-cycle batteries typically feature thick plates with a high-density active material. The thick battery
Plates allow for reserve energy to be stored deep within the battery plate and released during slow
Discharge such as trolling or electronic instrument use. The high-density active material remains
Within the batteries 'plate/grid structure longer, resisting the normal degradation found in cycling
Conditions. They are typically used where the battery is discharged to great extent and then
Recharged.
Deep Cycle refers to applications that typically discharge 60 to 70% or more of the battery
Capacity. An automotive battery is an SLI battery (Starting, Lighting & ignition.)Its plates are designed
to deliver maximum power for a short duration.
Starting an engine typically discharges an SLI battery 3% or less. When an SLI battery is used
in a deepcycle application or in a vehicle with heavy accessory loads, the battery life will be
shortened proportionally to how deeply and frequently it is discharged.
The Deep Cycle battery uses a different chemistry for the plates 'active paste material, and
a slightly stronger acid. This chemistry allows for a much longer life in deep cycle applications with
Only a slight reduction in maximum power output.
Features
-Superior Deep Cycle Design
-High Power Density
-Thick Plates and High-density Active Material
- Excellent energy storage capacity combined with high reliability
-Designed in accordance with IEC 60254-1
-700 Cycles at 75%DOD
Applications:
-Golf/NEV/Utility Vehicles
-Aerial Work Platforms/Access
-Floor Machine
-Material Handing
Certificates: ISO9001 ISO14001 CE UL
Specification
Model No.:CS6-200
Nominal Voltage: 6V
Nominal capacity: 200Ah
Dimension: L295*W178*H354*TH360
Weight: 46.6kgs
Terminal: Threaded Post
Factory photos
Package photo
Model NO. | Nominal
Voltage
(V) | Rated Capacity(AH) 10hrs/25ºC | Approx. Weight | Dimensions(mm) | Terminal Type |
| kg | lbs | Length | Width | Height | Total Height |
| mm | inch | mm | inch | mm | inch | mm | inch |
| CS6-2.8D | 6 | 2.8 | 0.53 | 1.17 | 67 | 2.64 | 34 | 1.34 | 100 | 3.64 | 103 | 4.06 | T1 |
| CS6-1.3D | 6 | 1.3 | 0.30 | 0.66 | 98 | 3.86 | 25 | 0.98 | 52 | 2.05 | 56 | 2.20 | T0 |
| CS6-3.3D | 6 | 3.3 | 0.63 | 1.39 | 134 | 5.28 | 34 | 1.34 | 61 | 2.40 | 66 | 2.60 | T0 |
| CS6-3.5D | 6 | 3.5 | 0.66 | 1.45 | 70 | 2.76 | 48 | 1.89 | 101 | 3.98 | 106 | 4.17 | T1 |
| CS6-4D | 6 | 4 | 0.69 | 1.52 | 70 | 2.76 | 48 | 1.89 | 101 | 3.98 | 106 | 4.17 | T1 |
| CS6-4.2D | 6 | 4.2 | 0.71 | 1.56 | 70 | 2.76 | 48 | 1.89 | 101 | 3.98 | 106 | 4.17 | T1 |
| CS6-4.5D | 6 | 4.5 | 0.78 | 1.72 | 70 | 2.76 | 48 | 1.89 | 101 | 3.98 | 106 | 4.17 | T1 |
| CS6-5D | 6 | 5 | 0.85 | 1.87 | 70 | 2.76 | 48 | 1.89 | 101 | 3.98 | 106 | 4.17 | T1 |
| CS6-6D | 6 | 6 | 1.00 | 2.20 | 151 | 5.94 | 34 | 1.34 | 94 | 3.70 | 100 | 3.94 | T1 |
| CS6-7D | 6 | 7 | 1.10 | 2.42 | 151 | 5.94 | 34 | 1.34 | 94 | 3.70 | 100 | 3.94 | T1 |
| CS6-8D | 6 | 8 | 1.28 | 2.82 | 151 | 5.94 | 34 | 1.34 | 94 | 3.70 | 100 | 3.94 | T1 |
| CS6-10D | 6 | 10 | 1.65 | 3.63 | 151 | 5.94 | 50 | 1.97 | 94 | 3.70 | 100 | 3.94 | T1 |
| CS6-100D | 6 | 100 | 15.30 | 33.66 | 195 | 7.68 | 170 | 6.69 | 207 | 8.15 | 210 | 8.27 | T16 |
| CS6-14D | 6 | 14 | 1.96 | 4.31 | 151 | 5.94 | 50 | 1.97 | 94 | 3.70 | 100 | 3.94 | T1/T2 |
| CS6-12D | 6 | 12 | 1.81 | 3.98 | 151 | 5.94 | 50 | 1.97 | 94 | 3.70 | 100 | 3.94 | T1 |
| CS6-35D | 6 | 35 | 10.20 | 22.44 | 196 | 7.70 | 131 | 5.16 | 155 | 6.10 | 180 | 7.09 | T16 |
| CS6-160D | 6 | 160 | 25.00 | 55.00 | 307 | 12.09 | 170 | 6.69 | 220 | 866 | 225 | 8.86 | T19 |
| CS6-180D | 6 | 180 | 29.00 | 63.80 | 260 | 10.24 | 180 | 7.09 | 246 | 9.69 | 250 | 9.84 | T19 |
| CS6-200D | 6 | 200 | 30.50 | 67.10 | 322 | 12.68 | 178 | 7.01 | 227 | 8.94 | 230 | 9.06 | T10 |
| CS6-220D | 6 | 220 | 31.50 | 69.30 | 322 | 12.68 | 178 | 7.01 | 226 | 8.90 | 251 | 9.88 | T19 |
| CS6-225D | 6 | 225 | 31.50 | 69.30 | 322 | 12.68 | 178 | 7.01 | 226 | 8.90 | 251 | 9.88 | T9 |
