7.0mm 12 MPO to FC Singlemode Breakout Kits Waterproof Optical Patch Cable
| Price: |
US $ 30-40/Meter |
| Min Order: |
1/Meter |
| Pay Type: |
L/C,T/T,Western Union,Paypal,Money Gram |
| Prod Model: |
002 |
| Cable Diameter: |
7.0mm |
| Fiber Count: |
12 |
| Fiber Type: |
Singlemode |
| Connector 1: |
MPO |
| Connector 2: |
FC |
| Jacket: |
PVC |
| Color: |
Orange |
| Polish Type: |
APC |
| Application: |
Probe |
| Type: |
Single-mode Fiber |
| Connection Structure: |
FC |
| Certification: |
ISO9001 |
Product Description
7.0mm 12 MPO to FC Singlemode Breakout Kits Waterproof Optical Patch Cable
PUNO's harsh environment fiber optic connector is designed with rugged and robust housing which fulfills IP68 environmental sealing requirement, which support virtually any extreme environments. Sealed to IP68 rating, the highest ingress protection level for all of its kinds, our ruggedized IP connector delivers distinguished performance in robustness and reliability to deal with those typical challenges like extreme temperature, humidity, vibration, as well as chemicals corrosive gasses. We offer this ruggedized IP connectivity solution in forms of pre-terminated assemblies and connector kit to fit for each unique installation needs. Our factory terminated assemblies are custom built to your specific requirements include connector type (LC, MTP, Elite-MTP), fiber type (OS1/2, OM1~OM4) in different length options. This high precision factory terminated solution helps you to enhance network reliability by achieving low loss optical performance, while eliminating on-site termination cost and supporting faster network deployment.
Keyed Characteristics:
√ IP-68 harsh environment connector is available in LC Duplex, MTP®, Elite-MTP;
√ Sealed to IP68 for utmost protection;
√ Bayonet locking design makes ease of mating even in inconvenient locations;
√ Receptacle of different flange styles to fit for different installation needs;
√ Fiber optic connector compliant to Telcordia GR-326-CORE and TIA/EIA standard;
√ Comprehensive assemblies solutions reduce cost of site termination while enhanced performance;
√ 100% factory-tested for excellent reliability and optical performance.
Application:
√ FTTx in passive optical network;
√ Base station / FTTA;
√ Transportation and railway system;
√ Ethernet and Industrial networking system;
√ Broadcasting networks;
√ Mining;
√ Any extreme environments.
Specifications of Connector:| Mating Mechanism | Bayonet |
| Ingress Protection | IP-68 |
| Operating Temperature | -40°C ~ +70°C |
| Mechanical Performance | Straight pulling force 25 Kgs |
| Mating Durability | 500 mating cycles |
Specifications of Assemblies:| Performance Connector | Insertion Loss (IL) | Return Loss (RL) |
| Standard LC | <= 0.30dB (Typical 0.10dB) | SM/UPC >= 55dB
MM/PC >= 25dB |
| MTP | SM <= 0.75dB (Typical 0.25dB)
MM <= 0.60dB (Typical 0.20dB) | SM >= 60dB
MM >= 20dB |
| Elite-MTP | <= 0.35 dB (Typical 0.1dB) | SM >= 60dB
MM >= 20dB |
| Singlemode APC | | |
| Singlemode UPC | | |
Features:
√ Connector kit for convenient on-site termination;
√ Offered in LC Duplex, MTP, Elite-MTP for options;
√ Plug housing sealed to fulfill IP68 ingression protection rating;
√ Options of different connector housing colors for identifying fiber mode;
√ Options of Regular Boot and Short Boot to fit for different installation needs;
√ Suitable for terminating with cables with outer diameter 5.5mm (+/-05.mm);
√ Cable outer diameter less than 3.5mm: Heat Shrink Tube will be used;
√ Cable outer diameter over 6mm: contact our sales team for solutions.
