7/8 Superflexible Coaxial Cable with Connector Assembly

Prod Model:	7/8"cable
Color:	Black
Inner Conductor:	CCA
Weatherproof Standard:	IP68
Jacket:	Injection Molding
Connector Applicable:	N/DIN Type
Application:	RF Cable
Conductor Material:	Copper
Cover Material:	PE
Type:	Cat 1
Certification:	VDE
Model:	Rg-58u
Brand:	OEM

Product Description

                          7/8 Superflexible RF Coaxial Cable with Connector Assembly

Company profile


Shang hai Xiaowei Equipment Co., LTD (Xiaowei) was established in 2011, Shanghai, which is a company  covering cable and accessories manufacturing, real estate, engineering  service and investment &trading.
     As a National wide wire &cable supplier Xiaowei continually provide different quality products in the telecom communication fields, the main product is 7/8 feeder cable, 1/2 feeder cable, feeder claim, feeder tools, all kind of the male, female, DIN, connector feeder connector, feeder grouding kit, grounding bar, low loss 7/8 jumper cable and 1/2 jumper cable, indoor optic jumper cable  and outdoor fiber cable, splitter and coupler, Dual and trible band antanna, GPS antenna and GPS cable all the accessories in the telecom field.  Xiaowei also supply VHF vabor phone, WLAN system.
      Xiaowei have advance manufacturing product line, stanard factory, we have long co-operation with the Chinese main telecom operators such as China Mobile, China Unicom, China Telecom. And the electric power operator such as National Electric network company, Southern Electric power company. Xiaowei provides total solution for telecommunication, power grid, railway, engineering, green energy, automobile industries, etc.
         Xiaowei particularly focused on the QoS and creating value for its clients and stakeholders, continuously invest in R&D, marketing & service networks, meeting and exceeding the precise needs of our customers national wide.  With the develop of the business, Xiaowei extend  the service to the international trading.

RG-58U Cable Assemblies / Assembly
Applicable for connecting feeder cables with 8TS equipment and antenna, unnecessary of additional waterproof measures, such as  waterproof gel or tape, meets waterproof standard IP68.

Standard lengths: 0.5m, 1m, 1.5m, 2m, 3m, customer special requiremnts on jumper length could be satisfied.
Characteristics & Applications

Electrical Spec.
Vswr	≤ 1.15 (300MHz-2500GHz)
Dielectric withstanding vlotage	≥1000V
Dielectric resistance	≥5000MΩ(500V DC)
PIM3	≤ -138dBc@2x30W
Operating temperature	- 40oC ~ + 85oC
Insert loss	It depends on leghth of cable
Weatherproofing standard	IP68
Cable length	Customized
Jacket	Heat shrink tubing
Connector applicable	N Type	DIN Type
	SMA	/



Structure and performance parameters
RG58 Cable			Connector
Material	Inner conductor	Tin plated copper wire (Φ19x0.18mm)	Inner conductor	Brass, tin phosphorus bronze, tinnedt, hickness≥3μm Orichalum plating, hickness ≥0.2μm
	Dielectri material	Polyethylene (Φ2.95mm)	Dielectri material	PTFE
	Outer conductor	Tin plated copper wire braid (Φ3.45mm)	Outer conductor	Brass, tri-alloy plated, thinkness≥2μm
	Jacket	FPE/PE/PVC(Φ4.95mm)	Nut	/
	Color	Customized	Sealing ring	/
Electrical and Mechanical Spec.	Characteristic impedance	50Ω	Characteristic impedance	50Ω
	Vswr	≤ 1.15(DC-2500GHz)	Vswr	≤ 1.15(DC-2500GHz)
	Standard capacity	101.05 pF/m	Frenquency	DC-11GHz
	Velocity	66%	Dielectric withstanding voltage	≥2500V
	Attenuation	≥120 (dB)	Contact resistance	Inner conducter ≤ 5.0mΩ Outer conducter≤ 2.5mΩ
	Insulation resistance	≥5000MΩ	Dielectric resistance	≥2500MΩ, 500V DC
	Peak voltage	1.13KV	Durability	≥500
	Peak power	40KW	Pim3	≤ -155dBc@2x20W

Detailed Images


Packing & Delivery
Packing by Reels

The wood or plywood reels will be used, when the length of cable is more than 300m.
Packing by Paper Boxes
The paper boxes will be used, when the length of cable isn't more than 300m.

For more information, please feel free to contact us!!
