70cm Detection Range Infrared Diffuse Photo Proximity Sensor IP 65

Name: 70cm Detection Range Infrared Diffuse Photo Proximity Sensor IP 65
Brand: all-electronics-online.com
SKU: 840370585
Availability: InStock
Rating: 4.5 (72 reviews)

Price:	US $ 2-10piece/pieces
Min Order:	1piece/pieces
Pay Type:	T/T,Western Union,Paypal

Contact Supplier

Showroom Product Company Profile

Prod Model:	M30

Product Description

70cm Detection range infrared diffuse photo proximity sensor IP 65

PRODUCT DISPLAY

PRODUCT DESCRIPTION

Feature

We sincerely welcome agents from all over the world

Power supply reversal connection protection; short-circuit protection, can directly connect with PLC

Used in common places witch medium environment resistance

Red LED indicates that it's available to detect the sensor operating state

IP65 protection structure (IEC specification)

Read the "Matters needing attention" of the Product Instruction before use

Type and Specification
We sincerely welcome agents from all over the world

Dimension				M30
Mounting way				Diffuse type
Type	DC type	NPN	NO	AE3F3-DS50N1	AE3F3-DS70N1
			NC	AE3F3-DS50N2	AE3F3-DS70N2
			NO+NC	AE3F3-DS50N3	AE3F3-DS70N3
		PNP	NO	AE3F3-DS50P1	AE3F3-DS70P1
			NC	AE3F3-DS50P2	AE3F3-DS70P2
			NO+NC	AE3F3-DS50P3	AE3F3-DS70P3
	AC type	Two wire	NO	AE3F3-DS50A1	AE3F3-DS70A1
			NC	AE3F3-DS50A2	AE3F3-DS70A2
Detection distance				50cm+/-10%	10-70cm+/-10%
Detection target				transparent/opaque object
Standard detection object				sensitivity adjuster
Response time				DC:1ms; AC:30ms

Connection delay	1.5ms
Light Source	Infrared light 660nm
Supply voltage	DC type: DC12-24V(6-36V) Impulse(p-p) 10% below Ac type: AC110-220V (36-250V) 50/60Hz
Consumption current	N.P type:20mA below A type:1.7mA below
Control output	N.P type:300mA below A type:400mA below J type: A below contact service life: 0.1 million times
Loop protection	N.P.D type: reversal connection protection, surge absorption, load short-circuit protection A type: surge absorption
Ambient temperature humidity	During operation,storage: individually-30~+65(No freeze,no drew), During operation,storage: Individually35~95%RH
Insulation resistance	50 MΩ about(DC500 megameter) between charging and housing
Withstand voltage	AC1000V50/60Hz 1 min between charging and housing
Temperature influence	Temperature range-30~+65,at+23,+/-15% detection distance Temperature range-25~+60,at+23,+/-10% detection distance
Voltage influence	Inside+/-15%rated supply voltage range, at rated supply voltage value; Inside +/-10% detection distance
Protection sturcture	IP65 ICE specification
material	ABS; Detection surface(lens)PMMA
