75W 12V Switching Power Supply with CE and RoHS (SP-75-12)

Name: 75W 12V Switching Power Supply with CE and RoHS (SP-75-12)
Brand: all-electronics-online.com
SKU: 683172395
Availability: InStock
Rating: 4.8 (128 reviews)

Price:	Negotiable/Piece
Trade Terms:	FOB
Min Order:	1/Piece
Pay Type:	T/T,Paypal,Western Union

Contact Supplier

Showroom Product Company Profile

Prod Model:	BSP-75-12
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Shell Material:	Aluminum
Color:	Silver
Size:	1799933
Output Type:	Single
Output Power:	51 - 100W
Input Voltage:	Full Range
Certification:	ISO
Brand:	Chnbest

Product Description

100% full load burn-in test
Universal AC input: 100-264VAC
Fixed switching frequency at 47-63Hz
Protections: Short circuit/Overload/Over voltage
PF>0.96@115VAC PF>0.93@230VAC
Approvals: CE RoHS
Size: 179*99*33mm

Specification	BSP-75-12
DC output	12V 6.3A
Wave and noise	100mVp-p
Inlet stability	± 0.5%
Load stability	± 0.5%
Efficiency	84%
Adjustable range for DC voltage	± 10%
AC input voltage range	85-264VAC 47-63Hz 240-370VDC
AC Inrush current	Cold-start current 25A/115V 40A/230V
OverLoad protection	105%-150% hiccup mode, auto-recovery
Over-Voltage protection	115%-140% rated output voltage
Setup, rise, hold up time	1500ms, 50ms, 20ms at full load and 230VAC
Withstand voltage	I/P-O/P: 3Kv I/P-FG: 1.5KV O/P-FG: 0.5KV 1minute
Isolation resistanc	I/P-O/P IP/FG OP-FG: 500VDC/100MΩ
Working temperature	-10º C_ +50º C
Safety Standards	Design refer to GB4943, UL60950, EN60950
EMC Standards	Design refer to GB9254, EN55022 Class B
Weight	0.78Kg

Zhejiang Best Electric Co., Ltd. Founded in 2000. Our factory is located in Wenzhou Zhejiang.

With over 16 years of experience in design and manufacture of switching power supplies, we have established long-term relationship with hundreds of big customers in the field of industrial control, telecom, LED, display & lighting of buildings, elevator, laser equipment, TV & broadcasting, computer system, medical equipment, safety control, automotive system, banking equipment

The products include Single output series, Waterproof Series, Rainproof Series, DIN-Rail Series, With PFC Function Series, With Battery Charger Series, DC to DC series, Open Frame Series, Dual Output Series, Triple Output series, Quad Output Series, and custom-design switching power supplies, over 5, 000 models showing great flexibility.

The company is certified by SGS. Over 100 models power supply have acquired CE, RoHS approval, and more are underway. We have various advanced equipment, such as wave soldering and reflow soldering machine, AI component insertion machine, auto chip mounter, ATE, ICT, RoHS testing, environmental testing, EMC testing system, burn-in test room, data acquisition Only top brand international components are adopted for the key parts to ensure long lifetime and high reliability. Each unit is given full load burn-in test. With high quality and market reputation,

We were honored to become main SMPS supplier for Beijing Olympic Games, and Shanghai Expo 2010.

We are confident to offer you total power solutions and become our trustworthy power partner.
